Operating instructions
Chlorine Electrolysis System
CHLORINSITU
V
®
EN
P_PMA_ECA_0016_SW
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.
983754
Original Operating Instructions (2006/42/EC)
BA CI 011 04/16 EN
