INSTALLATION, OPERATION,
INSTALLATION, OPERATION,
AND SERVICE MANUAL
AND SERVICE MANUAL
DISHSTAR SERIES UNDERCOUNTER DISHMACHINES
DISHSTAR
SERIES UNDERCOUNTER DISHMACHINES
DishStar HT-E/HT-E-SEER Manual • 07610-004-43-79-Q

Advertisement

Table of Contents
loading

Related Manuals for Jackson DISHSTAR HT-E

Summary of Contents for Jackson DISHSTAR HT-E

  • Page 1 INSTALLATION, OPERATION, INSTALLATION, OPERATION, AND SERVICE MANUAL AND SERVICE MANUAL DISHSTAR DISHSTAR SERIES UNDERCOUNTER DISHMACHINES SERIES UNDERCOUNTER DISHMACHINES DishStar HT-E/HT-E-SEER Manual • 07610-004-43-79-Q...
  • Page 2 ONE YEAR LIMITED PARTS AND LABOR WARRANTY For a period of one (1) year from date of original installation of a new Jackson Dishmachine (but in no event to exceed eighteen (18) months from date of shipment from Jackson’s factory), Jackson WWS, Inc. (Jackson) will repair or replace, at its discretion, any original part that proves defective in materials or workmanship at the time the Dishmachine was purchased;...
  • Page 3 MANUFACTURER'S LIMITED WARRANTY (CONT.) (APPLICABLE ONLY IN THE UNITED STATES AND CANADA) PRODUCT CHANGES: Jackson reserves the right to make changes in design and specification of any component of the Dishmachine as engineering or necessity requires. DISCLAIMER OF WARRANTIES: THERE ARE NO WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE OR MERCHANTABILITY, THAT ARE NOT SET FORTH HEREIN, OR THAT EXTEND BEYOND THE DURATION HEREOF.
  • Page 4 REVISION HISTORY Revision Date Made by Process Details 4-11-17 Initial release of the manual. Corrected pg. 2. Updated pg. 4 due to heaters not running simultaneously. Added description of the three cycles to the Operation section. Replaced item #14 on pg. 27 with new P/N. Added 1/4" 4-27-17 brass plug to the rinse tank.
  • Page 5 NOMENCLATURE DishStar HT-E ® Undercounter dishmachine; high-temperature, hot-water sanitizing, with a booster tank and detergent and rinse-aid chemical feeder pumps. DishStar HT-E-SEER ® Undercounter dishmachine; high-temperature, hot-water sanitizing, with a booster tank and detergent and rinse-aid chemical feeder pumps. Equipped with Steam Elimination and Energy Recovery System (SEER).

  • Page 6: Table Of Contents

    TABLE OF CONTENTS GUIDES Symbols ............................1 Abbreviations & Acronyms ....................... 1 SPECIFICATIONS HT-E Dimensions ..........................2 HT-E-SEER Dimensions ........................3 HT-E Operating Parameters ......................4 HT-E-SEER Operating Parameters ....................5 Electrical Requirements ........................6 INSTRUCTIONS Installation Instructions ........................7 Inspection.........................
  • Page 7 TABLE OF CONTENTS MAINTENANCE Preventative Maintenance ......................19 TROUBLESHOOTING Programming ..........................21 Fault Codes ............................ 23 Troubleshooting ..........................26 PARTS Terminal Block Box, 208/230 V ...................... 28 Terminal Block Box, 460 V ......................29 Kick Panel ............................30 Control Panel, 208/230 V ....................... 31 Chemical Feeder Pumps, 208/230 V .....................

  • Page 8: Symbols

    GUIDES SYMBOLS - Risk of Injury to Personnel WARNING - Risk of Damage to Equipment CAUTION - Risk of Electrical Shock - Caustic Chemicals - Reference Data Plate - Lockout Electrical Power - Important Note NOTICE  - Instructions Hyperlink ABBREVIATIONS &...

  • Page 9: Specifications

    HT-E DIMENSIONS SPECIFICATIONS LEGEND A - Electrical Connection C - Drain Hose All dimensions from the floor (5/8" ID, install into 1 1/2" MIN Drain with Air-gap) can be increased 1” using the B - Water Inlet (with 6' Hose) machine’s adjustable feet.

  • Page 10: Ht-E-Seer Dimensions

    HT-E-SEER DIMENSIONS SPECIFICATIONS LEGEND A - Electrical Connection C - Drain Hose All dimensions from the floor (5/8" ID, install into 1 1/2" MIN Drain with Air-gap) can be increased 1” using the B - Water Inlet (with 6' Hose) machine’s adjustable feet.

  • Page 11: Ht-E Operating Parameters

    HT-E OPERATING PARAMETERS SPECIFICATIONS DishStar HT-E Operating Capacity: Racks per Hour 36 (27)* Dishes per Hour Glasses per Hour 1296 Tank Capacity (Gallons): Wash Tank Rinse Tank 1.66 NOTICE Always refer to machine data plate for specific electrical and water requirements.

  • Page 12: Ht-E-Seer Operating Parameters

    HT-E-SEER OPERATING PARAMETERS SPECIFICATIONS DishStar HT-E-SEER Operating Capacity: Racks per Hour 24 (20)* Dishes per Hour Glasses per Hour Tank Capacity (Gallons): Wash Tank Rinse Tank 1.66 NOTICE Always refer to machine data plate for specific electrical and water requirements. The material provided on this page is for reference only and is subject to change without notice.

  • Page 13: Electrical Requirements

    ELECTRICAL REQUIREMENTS SPECIFICATIONS NOTICE DishStar HT-E/HT-E-SEER Electrical Characteristics All electrical ratings provided in this manual are for reference VOLTS only. Always refer to machine data plate to get exact electrical information for this machine. All electrical work performed on machines should be done in accordance with applicable local, PHASE state, territorial, and national codes.

  • Page 14: Instructions

    INSTRUCTIONS INSTALLATION INSPECTION Before installing machine, check packaging and machine for damage. Damaged packaging might be an indication of damage to machine. If there is any type of damage to both packaging and unit, do not throw away the packaging. The machine Do not throw away has been inspected at the factory before shipping and is expected to arrive in new, packaging if damage...

  • Page 15: Pressure Regulator

    INSTRUCTIONS INSTALLATION WATER SUPPLY If water hardness tests at 3 GPG or lower, connect machine water line (installed at the factory) to the facility water line. A water shut-off valve should be installed in the CONNECTIONS: water line between the facility supply and machine to allow access for service. The WATER HARDNESS water supply line must be capable of a minimum of 10 PSI “flow”...

  • Page 16: Electrical Power Connections

    INSTRUCTIONS INSTALLATION ELECTRICAL POWER Electrical and grounding conductors must comply with the applicable portions of the National Electric Code ANSI/NFPA 70 (latest edition) and/or other electrical codes. CONNECTIONS The data plate is located on the left-front of the dishmachine. Refer to the data plate for machine operating requirements, machine voltage, total amperage, and serial number.

  • Page 17: Voltage Check

    INSTRUCTIONS INSTALLATION VOLTAGE CHECK Apply power to machine. Check incoming power at the terminal block and ensure it corresponds with voltage listed on the data plate. If not, contact a qualified service agency to examine the problem. Do not run machine if voltage is too high or too low. Advise all proper personnel of the location of the breaker and any problems.

  • Page 18: Preparing Chemical Feeder Pumps

    INSTRUCTIONS INSTALLATION PREPARING This machine is supplied with detergent and rinse-aid chemical feeder pumps. CHEMICAL Locate open ends of chemical tubes with tube stiffeners and place each one in FEEDER PUMPS appropriate container. • Red Tubing = Detergent • Blue Tubing = Rinse-aid PRIMING CHEMICAL Chemical feeder pumps need priming when machine is first installed or if chemical lines have been removed and air was allowed to enter.

  • Page 19: Operating Instructions

    OPERATING INSTRUCTIONS OPERATION PREPARATION 1. Verify strainers are in place and clean. CAUTION CAUTION! Preparation section must be followed before operating machine! 2. Ensure wash and rinse arms are screwed securely in place and end-caps are tight. 3. Verify wash and rinse arms rotate freely. 4.

  • Page 20: Ware Preparation

    OPERATING INSTRUCTIONS OPERATION WARE Proper ware preparation helps ensure good results and fewer re-washes. If not done properly, ware might not come out clean and efficiency of the dishmachine will be PREPARATION reduced. Scraps should always be removed from ware before being loaded into a rack.
  • Page 21 OPERATING INSTRUCTIONS OPERATION WASHING A RACK 6. Press Start button and machine will begin wash cycle. OF WARE 1 5 5 F Temperature shown W A S H I N G is minimum required temperature. C Y C L E 1 7.

  • Page 22: Operational Inspection

    OPERATING INSTRUCTIONS OPERATION OPERATIONAL Based on use, strainers might become clogged with soil and debris as the workday progresses. Operators should regularly inspect strainers to ensure they've not INSPECTION become clogged. Clogged strainers will reduce washing capability of machine. Instruct operators to clean out strainers at regular intervals or as required by workload.
  • Page 23 OPERATING INSTRUCTIONS OPERATION SHUTDOWN & 6. Replace end-caps and use a screwdriver to ensure they are tight. CLEANING Use a screwdriver to ensure end-caps are tight. 7. Ensure float (located under left strainer) is free of debris. 8. Spray or wipe out interior of machine. 9.

  • Page 24: Deliming

    OPERATING INSTRUCTIONS OPERATION DELIMING In order to maintain machine at its optimum performance level, lime and corrosion deposits must be removed. The frequency for deliming will be based on water conditions. A deliming solution is available from your chemical supplier. Read and follow all instructions on the label.

  • Page 25: Detergent Control

    OPERATING INSTRUCTIONS OPERATION DETERGENT Detergent usage and water hardness are two factors that greatly contribute to the machine's operating efficiency. Using the proper amount of detergent can become a CONTROL source of substantial savings. A qualified water-treatment specialist can determine what is needed for maximum efficiency from the detergent.

  • Page 26: Preventative Maintenance

    1. Ensure water temperatures match those listed on machine data plate (on front- left of machine). SERIAL NO.: XXXXXXXXX 60Hz 1 PH 2 WIRE MODEL: DISHSTAR HT-E 208 VOLT 230 VOLT WASH MOTOR 1 HP 5.0 A 1 HP 5.0 A WASH HEATER 3.3 KW...
  • Page 27 PREVENTATIVE MAINTENANCE MAINTENANCE PREVENTATIVE 5. Do not overfill racks. MAINTENANCE 6. Ensure glasses are placed upside-down in the rack. 7. Ensure all chemicals being injected into machine have been verified at correct concentrations. 8. Clean machine at end of every workday (see Shutdown and Cleaning section). 9.

  • Page 28: Troubleshooting

    PROGRAMMING TROUBLESHOOTING MODEL To access programming mode, machine should be on and not in cycle. CONFIRMATION The machine's program number must be correct to ensure machine works properly. To confirm program number: 1. Press and hold I and III buttons until “Program” flashes (2–3 seconds). P R O G R A M 2.
  • Page 29 PROGRAMMING TROUBLESHOOTING USER SETUP To access programming mode, machine should be on and not in cycle. Programming buttons (Up-arrow, Down-arrow, and Select) are hidden on display A transparent guide to and are shown below outlined with red dots. locating the programming buttons is included with 1.

  • Page 30: Fault Codes

    FAULT CODES TROUBLESHOOTING DISPLAY SHOWS POSSIBLE CAUSES REMEDY 1. Verify incoming water pressure is 10 ± 2 PSI. 1. Low or no water pressure. 2. Verify that fill relay is supplying voltage to fill solenoid. Replace faulty component. 2. Faulty inlet valve or fill relay. 3.
  • Page 31 FAULT CODES TROUBLESHOOTING DISPLAY SHOWS POSSIBLE CAUSES REMEDY 1. Verify incoming water pressure is 10 ± 2 PSI. 1. Low or no water pressure. 2. Verify that fill relay is supplying voltage to fill solenoid. 2. Faulty inlet valve or fill relay. Replace faulty component.
  • Page 32 FAULT CODES TROUBLESHOOTING DISPLAY SHOWS POSSIBLE CAUSES REMEDY "F12 Service needed," "Check booster Faulty temperature probe (T3). Replace probe that connects to P13. thermostat" 1. Fully disconnect 6-pin cable at each end, and reconnect 1. Loose connection in 6-pin cable between each end until a click is heard.

  • Page 33: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING WARNING! Inspection, testing, and repair of electrical equipment should only be performed by qualified service personnel. Certain procedures in this section require electrical tests or measurements while power is applied to machine. Exercise extreme caution at all times. If test points are not easily accessible, disconnect WARNING power, attach test equipment, and reapply power to test.
  • Page 34 TROUBLESHOOTING TROUBLESHOOTING WARNING! Inspection, testing, and repair of electrical equipment should only be performed by qualified service personnel. Certain procedures in this section require electrical tests or measurements while power is applied to machine. Exercise extreme caution at all times. If test points are not easily accessible, disconnect WARNING power, attach test equipment, and reapply power to test.

  • Page 35: Parts

    TERMINAL BLOCK BOX, 208/230 V PARTS ITEM DESCRIPTION PART NUMBER Power Connection Decal 09905-011-47-35 Terminal Block Box 05700-004-36-47 Terminal Box Cover (Not Shown) 05700-003-27-70 Strain Relief 05975-003-37-56 Terminal Block Track 05700-000-43-60 Terminal Block 05940-500-02-19 Locknut, 10-24 Hex with Nylon Insert 05310-373-01-00 Decal, L1, N 09905-011-62-72...

  • Page 36: Terminal Block Box, 460 V

    TERMINAL BLOCK BOX, 460 V PARTS ITEM DESCRIPTION PART NUMBER Power Connection Decal 09905-011-47-35 Terminal Block Box 05700-004-44-79 Terminal Box Cover (Not Shown) 05700-004-44-80 Strain Relief 05975-210-03-00 Terminal Block Track 05700-004-44-72 Terminal Block 05940-500-02-19 Locknut, 8-32 Low Profile 05310-004-23-83 Decal, L1, L2, L3 09905-101-12-66 Ground Lug 05940-200-76-00...

  • Page 37: Kick Panel

    KICK PANEL PARTS ITEM DESCRIPTION PART NUMBER Complete Kick Panel Assembly 05700-004-41-87 Kick Panel 05700-004-41-86 Locknut, 6-32 Hex with Nylon Insert 05310-373-03-00 P-clamp, 1/4" ID 05975-002-61-42 Bushing, Snap 05975-210-09-00 Locknut, 10-24 Hex with Nylon Insert 05310-373-01-00 Cover, Display 05700-004-46-05 Nut, Thumb 6-32 Nylon 05310-002-83-12 PCB, Digital Display 05700-004-19-47...

  • Page 38: Control Panel, 208/230 V

    CONTROL PANEL, 208/230 V PARTS NOTICE 208-230 V machines with serial numbers before 22E406186 have a universal timer. Click here to open earlier manual. 07610-004-43-79-Q...
  • Page 39 CONTROL PANEL, 208/230 V PARTS ITEM DESCRIPTION PART NUMBER Contactor, 30 A, 240 VAC 05945-002-74-20 I/O Module 05945-004-44-63 End Bracket, Terminal 05999-004-90-66 Separator, Terminal Block 05999-004-90-67 Terminal Block, Single Level 05999-004-90-68 Tag, Marking 05999-004-90-72 Power Supply 05950-004-81-79 Peri-pump Assembly, 14 RPM 05700-004-71-63 Din Rail, 5 3/4"...

  • Page 40: Chemical Feeder Pumps, 208/230 V

    CHEMICAL FEEDER PUMPS, 208-230 V PARTS Part numbers for complete assemblies on previous page. NOTICE 208-230 V machines with serial numbers before 22E406186 have different pumps. Click here to open earlier manual. ITEM DESCRIPTION PART NUMBER Motor, 14 RPM 04320-011-63-33 Pump Housing, Clear 04320-004-59-41 Washer, Thrust, Peri-pump...

  • Page 41: Ht-E Control Panel, 460 V

    HT-E CONTROL PANEL, 460 V PARTS ITEM DESCRIPTION PART NUMBER Complete HT-E Electrical Panel Assembly, 460 V 05700-004-44-50 Electrical Panel 05700-004-40-63 Contactor, 460 V 05945-111-60-07 End-cap, Contactor 05940-111-60-30 Dinrail, 7 3/4" 05700-002-79-13 Screw, 10-32 x 5/8" 05305-003-02-12 Motor Overload, 1.35–2 A 05945-111-60-08 Screw, 10-32 x 1”...

  • Page 42: Ht-E-Seer Control Panel, 460 V

    HT-E-SEER CONTROL PANEL, 460 V PARTS ITEM DESCRIPTION PART NUMBER Complete HT-E-SEER Electrical Panel Assembly, 460 V 05700-004-51-92 Electrical Panel 05700-004-40-63 I/O Module 06401-004-76-15 Terminal Board 05940-002-78-97 Terminal Board 05940-004-21-34 Fastener 05340-111-58-10 Nut, Plated 05340-118-04-00 Screw, 10-32 x 1” 05305-002-19-42 Screw, 10-32 x 5/8"...

  • Page 43: Chemical Feeder Pumps, 460 V

    CHEMICAL FEEDER PUMPS, 460 V PARTS Complete Peri-pump Panel Assembly, 460 V 05700-004-44-45 07610-004-43-79-Q...
  • Page 44 CHEMICAL FEEDER PUMPS, 460 V PARTS ITEM DESCRIPTION PART NUMBER Stiffener, Chemical Tube 05700-002-66-49 Chemical Port Assembly 05700-004-30-86 Tubing, Red, 1/4" x 120" 05700-011-37-15 Tubing, Red, 1/4" x 80" 05700-011-37-14 Tubing, Clear, 1/8" x 120" 05700-002-76-14 Tubing, Clear, 1/8" x 48" 05700-002-76-15 Complete Peri-pump Assembly, 05700-004-71-60...

  • Page 45: Door

    DOOR PARTS Complete Door Assembly 05700-004-36-53 07610-004-43-79-Q...
  • Page 46 DOOR PARTS ITEM DESCRIPTION PART NUMBER Outer Door Weldment 05700-004-52-86 Screw, 10-32 x 1/4" 05305-173-01-00 Bolt, 1/4-20 x 3/8" Hex 05305-274-20-00 Washer, 1/4-20 ID 05311-174-01-00 Gasket, Door 20" 05330-003-58-35 Gasket, Door 17 1/8" 05330-003-58-36 Fastener, 10-32 05340-111-58-10 Door Handle 05700-003-26-62 Stop, Door Hinge 05700-003-32-55 Hinge, Left...

  • Page 47: Miscellaneous Door Components

    MISCELLANEOUS DOOR COMPONENTS PARTS Parts are not shown to scale in relation to each other. ITEM DESCRIPTION PART NUMBER Switch Mounting Plate Assembly 05700-003-33-54 Door Spring 05700-003-32-85 Cover, Left Hinge Weldment 05700-004-36-80 Cover, Right Hinge Weldment 05700-004-36-81 Hinges secured with Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00 O-ring 05330-003-32-34...

  • Page 48: Ht-E-Seer Door Interlock, 208-230 V

    HT-E-SEER DOOR INTERLOCK, 208-230 V PARTS Complete Door Interlock Assembly, 208-230 V 05700-004-99-58 NOTICE 208-230 V machines with serial numbers before 22E406186 have a different door interlock. Click here open earlier manual. ITEM DESCRIPTION PART NUMBER Screw, 6-32 x 5/8" 05305-011-39-85 Locknut, 6-32 Hex with Nylon Insert 05310-373-03-00...

  • Page 49: Ht-E-Seer Door Interlock, 460 V

    HT-E-SEER DOOR INTERLOCK, 460 V PARTS Complete Door Interlock Assembly, 115 V (for 460 V Machine) 05700-004-52-89 ITEM DESCRIPTION PART NUMBER Solenoid, Door Interlock, 115 V (for 460 V Machine) 05999-004-52-88 Solenoid Stop 05700-004-47-51 Bearing, Dry Running Sleeve, 1/4" ID 03120-004-47-52 Locknut, 1/4-20 Low Profile with Nylon Insert 05310-374-02-00...

  • Page 50: Wash

    WASH PARTS 07610-004-43-79-Q...
  • Page 51 WASH PARTS ITEM DESCRIPTION PART NUMBER Wash Arm Assembly 05700-021-39-23 Motor Support 05700-004-40-61 Wash Halo 05700-004-42-21 Pipe Clamp 05700-000-35-06 Wash Arm End-cap 05700-003-31-59 Screw, 1/4-20 x 1/2" 05307-011-36-96 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00 Manifold Gasket 05330-002-34-77 Wash Hub 05700-004-43-04 Wash Motor See Motors page.

  • Page 52: Motors

    MOTORS PARTS ITEM DESCRIPTION PART NUMBER Pump and Motor, 208/230 V 06105-004-35-22 Pump and Motor, 460 V 06105-003-52-78 Seal Plate, 208/230 V 05700-002-81-87 Seal Plate, 460 V 05700-002-06-22 Case O-ring, 208/230 V 05330-002-81-83 Case O-ring, 460 V 05330-002-87-02 Mechanical Seal, 208/230 V 05330-002-34-22 Mechanical Seal, 460 V 05330-002-87-16...

  • Page 53: Rinse

    RINSE PARTS Rinse Arm Bearing Kit 06401-004-57-50 ITEM DESCRIPTION PART NUMBER Complete Rinse Manifold Assembly 05700-004-40-58 Pipe Clamp 05700-000-35-06 Rinse Arm End-cap (includes o-ring) 05700-004-34-62 Complete Rinse Arm Assembly 05700-004-39-39 Rinse Arm 05700-004-38-75 Bearing Assembly, Rinse Arm 05700-004-54-71 O-ring (included in item #5) 05330-002-60-69 Retaining Ring 05340-112-01-11...

  • Page 54: Plumbing Options

    PLUMBING OPTIONS PARTS SHOCK ABSORBER (WATER ARRESTOR) OPTION Water Arrestor, 1/2” 06685-100-05-00 NOTICE HT-E-SEER has a water arrestor as standard equipment. See the HT-E-SEER Plumbing page. Tee, 1/2” x 1/2” x 1/2” 04730-211-27-00 Nipple, 1/2” NPT, Brass 04730-207-15-00 Water Arrestor Repair Kit (Plunger &...

  • Page 55: Ht-E Plumbing

    HT-E PLUMBING PARTS Complete Inlet Plumbing Assembly, 208/230 V 05700-004-09-03 Complete Inlet Plumbing Assembly, 115 V (for 460 V Machine) 05700-004-44-40 *Item not included in part number of complete plumbing assembly and must be ordered separately. 07610-004-43-79-Q...
  • Page 56 HT-E PLUMBING PARTS ITEM DESCRIPTION PART NUMBER Valve, 1/2", 208/230 V 04810-003-71-56 04810-003-71-55 Valve, 1/2", 115 V (for 460 V Machine) Union, 1/2" x 1/2" Brass 04730-003-62-44 Nipple, 1/2" Close Brass 04730-207-15-00 Nipple, 1/2" x 4" NPT Brass 04730-207-04-00 Adapter, 1/2" Fitting, Male 04730-011-59-53 Elbow, 1/2"...

  • Page 57: Ht-E-Seer Plumbing

    HT-E-SEER PLUMBING PARTS Complete SEER Plumbing Assembly, 208/230 V 05700-004-63-79 Complete SEER Plumbing Assembly, 460 V 05700-004-78-45 CONNECTS TO COLD WATER INLET ON SEER SYSTEM CONNECTS TO HOT WATER OUTLET ON SEER SYSTEM *Item not included in part number of complete SEER plumbing assembly and must be ordered separately.
  • Page 58 HT-E-SEER PLUMBING PARTS ITEM DESCRIPTION PART NUMBER Inlet Plumbing Assembly, 208/230 V 05700-004-53-98 Inlet Plumbing Assembly, 115 V (for 460 V Machine) 05700-004-78-48 Pressure Regulating Valve, Dial-set 05700-004-94-35 Booster Tank Discharge Assembly 05700-004-55-97 Tee, 1/2" Brass 04730-211-27-00 Nipple, 1/2" Close Brass 04730-207-15-00 Water Hammer Arrestor, 1/2"...

  • Page 59: Rinse Plumbing

    RINSE PLUMBING PARTS Complete Rinse Plumbing Assembly 05700-004-43-02 07610-004-43-79-Q...
  • Page 60 RINSE PLUMBING PARTS ITEM DESCRIPTION PART NUMBER Vacuum Breaker, 1/2" Brass 04820-003-06-13 Hose, Red, 1/2" ID, 19" 05700-004-33-84 Nipple, 1/2" x 3", Brass 04730-004-20-10 Elbow, 1/2", 90-degree, Brass 04730-011-42-96 Elbow, 90-degree 04730-406-32-01 Pipe, 4 3/4", Copper 05700-002-91-02 Adapter, 1/2" 04730-002-64-68 Complete Rinse Injector Assembly 05700-004-43-86 Rinse Injector Only...

  • Page 61: Rinse Tank

    RINSE TANK PARTS 07610-004-43-79-Q...
  • Page 62 RINSE TANK PARTS ITEM DESCRIPTION PART NUMBER Rinse Tank, 208/230 V 05700-004-41-88 Rinse Tank, 460 V 05700-004-44-46 Heater Gasket 05330-011-47-79 Rinse Heater, 5.45 kW, 208-230 V 04540-004-45-12 Rinse Heater, 5.45 kW, 460 V 04540-121-65-99 Lockwasher, Split 5/16" 05311-275-01-00 Nut, Hex 5/16-18 05310-275-01-00 Cable, Temperature Probe 05700-004-33-23...

  • Page 63: Seer System

    SEER SYSTEM PARTS Complete SEER System Assembly, 208/230 V 05700-004-63-06 Complete SEER System Assembly, 115 V (for 460 V Machine) 05700-004-64-72 here Machines with serial numbers before 19G376587 have an older version of the SEER System. Click NOTICE open manual with the older version. STICKY SIDE 07610-004-43-79-Q...
  • Page 64 SEER SYSTEM PARTS ITEM DESCRIPTION PART NUMBER Motor, Fan, 208/230 V 05999-004-63-31 Motor, Fan, 115 V (for 460 V Machine) 05999-004-64-71 Wheel, Blower 05999-004-59-13 Bracket, Bearing Boot 05700-004-50-94 Bushing and Housing Assembly 03120-004-50-88 Locknut, 10-24 Hex with Nylon Insert 05310-373-01-00 Bracket, Motor Adjustment 05700-004-58-81 Grommet, Push-in, 3/4"...

  • Page 65: Stands & Panels

    STANDS & PANELS PARTS 6" Stand Install Instructions  18" Stand Install Instructions  ITEM DESCRIPTION PART NUMBER 6” Stand Assembly 05700-003-34-24 Stand 05700-002-88-82 6” Leg 05700-021-61-10 Bullet Foot 05340-108-01-03 18” Stand Assembly 05700-003-34-25 Stand 05700-002-88-82 Bullet Foot 05340-108-01-03 18” Leg 05700-002-89-47 Cross Brace 05700-003-25-90...

  • Page 66: Frame

    FRAME PARTS ITEM DESCRIPTION PART NUMBER Shroud, Left 05700-003-37-04 Frame, Left 05700-003-31-91 Adjustable Foot 05340-002-71-71 Shroud, Top 05700-003-37-06 Frame, Right 05700-003-31-90 Plug, Shroud 05700-003-32-50 Panel, Bottom 05700-004-44-54 Support, Strainer Left 05700-004-40-52 Support, Strainer Right 05700-004-40-53 Strainer 05700-004-09-43 Shroud, Right 05700-004-36-82 07610-004-43-79-Q...

  • Page 67: Miscellaneous Parts

    MISCELLANEOUS PARTS PARTS Parts are not shown to scale in relation to each other. Wash Heater Replacement Instructions  208-230 V Drain Water Tempering Kit Install Instructions  460 V Drain Water Tempering Kit Install Instructions  ITEM DESCRIPTION PART NUMBER Rail, Left Rack 05700-031-37-88 Rail, Right Rack...

  • Page 68: Schematics

    208/230 V, 50/60 HZ, 1-PHASE SCHEMATICS NOTICE 208-230 V machines with serial numbers before 22E406186 have a different here schematic. Click open earlier manual. 07610-004-43-79-Q...

  • Page 69: 460 V, 60 Hz, 3 Phase

    460 V, 60 HZ, 3-PHASE SCHEMATICS Connection Diagram for IO Module Input Assignments Programming I1 Wash header I2 Cycle I3 Float I4 Rinse I5 Door/Chemicals VDC OUT Temperature Analog input AC signals DC RTN L1  L2/N Sensor inputs VDC OUT LOGIC INPUT AC power in DC RTN 24 VDC OUT / RS‐232 Relay Assignments K1 Power BLK (DC RTN) K2 Booster heater  K3 Wash heater RED (+24 VDC) K4 Varies by model K5 Varies by model...
