Time Electronics 5011 User Manual

Resistance and temperature calibrator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
5011
Resistance and Temperature Calibrator
Revision 2206-1
Time Electronics Ltd
Unit 5, TON Business Park, 2-8 Morley Road,
Tonbridge, Kent, TN9 1RA, United Kingdom.
T: +44 (0) 1732 355993 | F: +44 (0) 1732 350198
mail@timeelectronics.co.uk | www.timeelectronics.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5011 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Time Electronics 5011

Summary of Contents for Time Electronics 5011

  • Page 1 User Manual 5011 Resistance and Temperature Calibrator Revision 2206-1 Time Electronics Ltd Unit 5, TON Business Park, 2-8 Morley Road, Tonbridge, Kent, TN9 1RA, United Kingdom. T: +44 (0) 1732 355993 | F: +44 (0) 1732 350198 mail@timeelectronics.co.uk | www.timeelectronics.com...
  • Page 2 All rights reserved. Nothing from this manual may be multiplied, or made public in any form or manner, either electronically or hard copy, without prior written consent from Time Electronics Ltd. This also applies to any schematics, drawings and diagrams contained herein.

  • Page 3: Table Of Contents

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Contents Introduction ............................ 4 Overview ..............................4 Important Information ..........................5 Installation ............................. 6 Front Panel Controls ........................8 Keypad and Display ..........................8 Keypad Buttons ............................. 9 Display Readout ..........................10 Rotary Knob ............................

  • Page 4: Introduction

    A versatile, high accuracy calibrator that can be used in a wide range of testing applications. Primarily used as a programmable resistance and RTD source, the 5011 provides precision resistance with a best accuracy of 0.01 % and 1 mΩ resolution (50 Ω to 1 kΩ).

  • Page 5: Important Information

    Revision 2206-1 Important Information Warning: The 5011 is a heavy instrument and care should be taken when lifting to prevent injury. Use both handles to carry. Warning: If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.

  • Page 6: Installation

    When cleaning the 5011 use an alcohol-free wipe such as a ‘durable screenclean 50’. Packaging The 5011 is supplied in a carton with protective inserts. Retain the shipping box and internal packaging for future use. If the unit is returned to Time Electronics for calibration, please use this original packaging to avoid possible damage in transit.
  • Page 7 Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 1.3.2 Mains (Line) Power Supply The supply power is connected via a standard IEC Euro connector on the rear panel. The standard voltage supply is 100 to 230 V 50/60 Hz. There are two protection fuses mounted in the IEC connector assemble, both are T3.15 A slow blow.

  • Page 8: Front Panel Controls

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Front Panel Controls Keypad and Display Display readout 0.0.0.4.0.0..0.0 ° C P T 1 0 0 Function Polarity button button Rotary knob mode LEDs Output on button Function DC I indicators...

  • Page 9: Keypad Buttons

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Keypad Buttons 2.2.1 Function Selection Buttons Function selection is initiated by pressing the “Function/Range” button. The function indicators flash to prompt a selection. This informs the user that the buttons adjoining the indicators are now function selectors:...

  • Page 10: Display Readout

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 2.2.2 Output Value Setting Buttons Setting an output value is performed by using the up/down buttons for the following functions: Resistance, DC Voltage (option), DC Current (option), Frequency (option). The buttons are in-line with the numerical readout to the as shown below: -.0.0.2.3.4.5.6...

  • Page 11: Rotary Knob

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Rotary Knob The rotary knob is used to select ranges, settings and options. It is adjusted clockwise or anti-clockwise to the required selection. The “Deviation” or “Option/Range” LEDs illuminate to prompt usage of the rotary knob for the required operation. Ranges, options and settings are activated by pressing the “OK”...

  • Page 12: Terminals

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Terminals The terminal configuration for the 5011. Resistance / RTD DC V / Thermocouple Auxiliary Output Earth Terminal Terminal LED Indicators LED indicates active terminal: ON when outputting • FLASHING when in standby (no output) •...

  • Page 13: Display Leds

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Display LEDs Data and Remote LEDs Used to indicate remote mode activity. See “Remote Operation” section of this manual for more details. Error LED Flashes to indicate an output error condition, e.g.

  • Page 14: Front Panel Operation

    User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Front Panel Operation Unit start-up After switching on, the 5011 goes through a start-up routine that includes: • Instrument self-test and health check routine. • Relay cleaning routine: A sequence of contacts ‘buzzing’.

  • Page 15: How To Select A Function

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 How to select a Function Press the “Function” button. DC I 2. The function indicators will then flash to prompt a selection. DC I 3. Select the desired function by pressing adjacent button. In this example Resistance.

  • Page 16: Resistance Res

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Resistance RES To select the resistance function, press the “Function” button followed by “RES” button. The variable resistance ranges are indicated by the flashing ohms units on the display readout. Select the range using the rotary knob.

  • Page 17: Using Deviation Mode Dv

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Using Deviation Mode DV% This feature allows the output to be deviated in percentage steps. There are 3 options: • Fine deviation: 0.001% • Medium deviation: 0.01% Coarse deviation: 0.1% •...
  • Page 18 Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Deviation mode is highlighted by illumination of the “Deviation” LED. This prompts the use of the rotary knob. 3. To adjust the deviation, turn the rotary knob clockwise to increase, and anticlockwise to decrease.

  • Page 19: Pt100 Simulation Rtd

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Pt100 Simulation RTD To select the Pt100 function, press the “Function” button followed by “RTD” button. 0.0.0.2.0.0.0.0 °C PT100 DC I Then set the required temperature value using the “Up (∆) / Down (∇)” buttons.

  • Page 20: Thermocouple Simulation (Option) Tc

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Thermocouple Simulation (option) TC To select the thermocouple simulation function, press the “Function” button followed by “TC” button. The 8 thermocouple types are indicated by the flashing on the display readout. Select the range using the rotary knob.

  • Page 21: Dc Voltage Or Current (Option) Dcv Dci

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 DC Voltage or Current (option) DCV DCI DC Voltage and DC Current have common operation steps. Shown here is DC V. To select the DC Voltage function, press the “Function” button followed by “DCV” button.

  • Page 22: Digital Frequency (Option) Freq

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Digital Frequency (option) FREQ Variable output setting 0.1 to 10MHz. Select function AUX. Using the rotary knob, choose either Freq or Period. The display flashes to prompt selection of either frequency or period.

  • Page 23: Setup Options Set

    Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Setup Options SET 1. Press the “Function” button. DC I 2. The function indicators will then flash to prompt a selection. Press the “SET” button. DC I Once pressed, you will access the Setup Menu.
  • Page 24 Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 3.9.2 Deviation Resolution (Dev Rsln) Deviation Resolution is the first menu shown when you enter the setup menu. It can be used with resistance, TC, DC V, DC I, and frequency functions.
  • Page 25 Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 3.9.4 Rotary Knob Scroll Sound (Click) The Click option is a feature that can be set so that an audible click/beep is heard when the rotary knob scrolls from one setting/option to another. It is a user preference feature.

  • Page 26: Remote Operation

    The RS-232 communication settings are 9600 to 115200 baud rate, no parity, 8 data bits and 1 stop bit. When using the USB adaptor, connect this to the RS-232 port on the 5011. After installing the driver and connecting the device to a PC, check ‘Device Manager’ to see which comm.
  • Page 27 Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 4.1.3 Entering Remote Mode The unit will automatically enter remote mode as soon as it receives a command on the remote interface. While in remote mode, the keypad will be disabled apart from the Confirm/Local key.

  • Page 28: Remote Commands

    Remote Commands 4.1.5 Introduction to SCPI The 5011’s remote commands follow the SCPI standards. If you are already familiar with SCPI, then you can skip this section. SCPI commands are based on a tree-like hierarchy. Associated commands are grouped together under a common node (or root), into “subsystems”.
  • Page 29 Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Triangle brackets (<,>) are used to indicate a value you need to specify for the parameter. For example, with the command above a valid command would be: SOUR:VOLT:RANG 10 If a parameter or command keyword is enclosed in square brackets ([,]) then it is optional and can be omitted.
  • Page 30 Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 Parameter Types Numerical Parameters Commands that accept numerical values as parameters also allow units to be specified, e.g. mV, uA, C (deg C), kR (kilo-ohms). For instance all of these are valid:...
  • Page 31 Query the present resistance output. Example: sres? > 2500000 [:SOURce]:RTD:TYPE {PT100} Select the RTD simulation function and set the type of RTD to be simulated (PT100 on 5011). Example: rtd:type pt100 selects the rtd simulation function type PT100 [:SOURce]:RTD:TYPE? Query the type of RTD simulation selected.
  • Page 32 Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 VOLTAGE [:SOURce]:VOLTage:RANGe <volts> Select the voltage function and a range. <volts> may be 20mv, 200mv, 2V, 20V, 200V or 1kV. Example: volt:rang 20 selects the voltage function and 20V range [:SOURce]:VOLTage:RANGe? Query the present voltage range.
  • Page 33 Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 CURRENT [:SOURce]:CURRent:RANGe <amps> Select the current function and a range. <current> may be 200ua, 2ma, 20ma, 200ma Example: curr:rang 2ma selects the current function and 2mA range [:SOURce]:CURRent:RANGe? Query the present current range.
  • Page 34 Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 [:SOURce]:THERmocouple[:LEVel][:IMMediate][:AMPLitude] <temperature> Set the temperature to be simulated by the thermocouple function. <temperature> can be any temperature value supported by the selected thermocouple simulation. Units can be c (Celsius), f (Fahrenheit) or K (Kelvin) Example: ther 75.8...
  • Page 35 Time Electronics User Manual 5011 Resistance/Temperature Calibrator Revision 2206-1 :SYSTem:LOCal Puts the unit into local operation mode. The unit’s keypad is enabled. Note also that the unit is automatically switched from local to remote operation if it receives a command over the GPIB/RS232 port.
  • Page 36 Make the unit perform a complete reset. All output is turned off and unit returns to Ready state. *WAI Waits for the last command to complete before continuing. Since all commands to the 5011 are treated sequentially, this command is redundant, but is kept for SCPI-compatibility.
  • Page 37 5011 Resistance/Temperature Calibrator Revision 2206-1 9811 /19 / & 20 Legacy Commands The 5011 supports the older Time Electronics 98 series command set. RESISTANCE 1000.1 Sets the output level to 1000.1 <ohms> can be any value from 1 to 120MR.

  • Page 38: Fault Diagnosis

    PC. Mains-generated Interference It is recommended that the 5011 be operated from a clean AC mains power supply. It is strongly recommended that a filtered mains stabiliser is used. The effects of interference entering the 5011 are crashing of one of more of the many microcontrollers located inside the unit.

  • Page 39: Re-Calibration

    Revision 2206-1 Re-Calibration The 5011 should be re-calibrated at recommended intervals in order to ensure its outputs remain within specification. Normally re-calibration is done at 12 month intervals. The 5011 calibration software and manual are supplied separately and only available by request from Time Electronics.

  • Page 40: Warranty And Servicing

    Time Electronics’ total liability is limited to repair or replacement of the product. Note that if Time Electronics determine that the fault on a returned product has been caused by the user, we will contact the customer before proceeding with any repair.
  • Page 41 Revision 2206-1 Returning Instruments Prior to returning your product please contact Time Electronics. We will issue a return merchandise authorization (RMA) number that is to accompany the goods returning. Further instructions will also be issued prior to shipment. When returning instruments, please ensure that they have been adequately packed, preferably in the original packing supplied.
