Figure1-1 Airflow through the switch (S12516X-AF switch)
(1) Chassis air intake direction

Space

For easy installation and maintenance, follow these space requirements:
•
Reserve a minimum of 1.2 m (3.94 ft) of clearance between the rack and walls or other devices.
•
Make sure the rack has enough space to accommodate the switch.
For more information about chassis dimensions, see "Device dimensions and rack
requirements."

Installation accessories

Make sure you have all the required installation accessories ready for the installation.
Table1-5 Installation accessories
Product code
2150A08S
2
2
2
Description
S12516X-AF mounting brackets
1
1
1
(2) Chassis air exhaust direction
Quantity
1 pair
1-5
Applicable
device models
S12516X-AF
