Summary of Contents for Howard Miller 615096
- Page 1 615096 FLOOR CLOCK SET UP AND OPERATING INSTRUCTIONS CLOCK ASSEMBLY PARTS Head Assembly Mid-Collar Assembly Lower Wood Post Base 2321581-r1 07/2018...
- Page 2 615096 FLOOR CLOCK SET UP AND OPERATING INSTRUCTIONS CLOCK SET UP INSTRUCTIONS Twist Ties Ball Detents Twist Ties 2. Remove Front Grill from Head Assembly by 1. Remove Twist Ties from Head Assembly. gently pulling away from the Ball Detents.
- Page 3 615096 FLOOR CLOCK SET UP AND OPERATING INSTRUCTIONS Mid-Collar Assembly Mid-Collar Assembly Lower Wood Post Lower Wood Post Base Base 6. Slide Mid-Collar Assembly into Lower Wood Post. 7. Screw Mid-Collar Assembly into the Base by turning clockwise. Head Assembly...
- Page 4 615096 FLOOR CLOCK 615096 FLOOR CLOCK SETUP AND OPERATING INSTRUCTIONS SETUP AND OPERATING INSTRUCTIONS Time Setting Dial Thumb Screw 11. Install one “AA” size alkaline battery according to the +/- symbols in the battery holders. Turn the 10. To access Clock Movement, remove (2) Thumb Time Setting Dial to rotate the hands to the Screws at the 3 o’clock and 9 o’clock position on...
