Welcome to use ECO-03 infrared motion sensor!
The product adopts good sensitivity detector, integrated circuit. SMT. It gathers automatism,
convenience, safety, saving-energy and practicality functions. The wide detection field is
consisting of detectors. It works by receiving human motion infrared rays. When one enters the
detection field, it can start the load at once and identify automatically day and night; its
installation is very convenient and its using is very wide. It has functions of power indication and
the detection indication.
SPECIFICATION:
Power Sourcing: 220V/AC-240V/AC
Power Frequency: 50Hz
Ambient Light: 3-2000LUX (Adjustable)
Time-Delay: min: 10sec±3sec
Max: 8min±2min
Rated Load: 1200W (incandescent lamp)
300W (energy-saving lamp)
Detection Distance: 2-6m (<24℃) adjustable
FUNCTION:

Can identify day and night: The consumer can adjust work ambient light. It can work in the
daytime and at night when it is adjusted on the "sun" position (max). It can work in the
ambient light less than 3LUX when it is adjusted on the "moon" position (min). As for the
adjustment pattern, please refer to the testing pattern.

SENS adjustable: It can be adjusted according to using location; low sensitivity with 3m for
detection distance; high sensitivity with 6m, it fits for large room.

Time-Delay is added continually: When it receives the second induction signals after the first
induction, it will compute time once more on the basic of the first time-delay rest.
 Time–Delay is adjustable. It can be set according to the consumer's desire. The minimum
time is 10sec±3sec. The maximum is 8min±2min.
INSTALLATIION (see the diagram)

Switch off the power.

Please move the upper cover with anti-clockwise whirl as per
the diagram in the crust.
Detection Range: 360°
Working Temperature: -20~+40℃
Working Humidity: <93%RH
Installing Height: 2.2m~4m
Power Consumption: 0.45W (work)
0.1W (static)
Detection Motion Speed: 0.6~1.5m/s
