Page 1: Digital Camera
Digital Camera User’s Guide Thank you for purchasing this CASIO product. • Before using it, be sure to read the precautions contained in this User’s Guide. • Keep the User’s Guide in a safe place for future reference. • For the most up-to-date information about this product, visit the official EXILIM Website at http://www.exilim.com/...
Page 2: Unpacking
Unpacking As you unpack your camera, check to make sure that all items shown below are included. If anything is missing, contact your original retailer. Digital camera * The shape of the power cord plug varies according to country or geographic area.
Page 3: Read This First
CASIO COMPUTER CO., LTD. is forbidden under copyright laws. • CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost profits suffered by you or any third party due to the use or malfunction of this product.
Page 4: Table Of Contents
What is a digital camera? ........12 What you can do with your CASIO camera ......13 First, charge the battery prior to use..
Page 5 Recording Movie Images and Audio To record a movie ..........47 Shooting a Snapshot while Shooting a Movie .
Page 6 Controlling Image Sharpness ......(Sharpness) . . . 80 Controlling Color Saturation ......(Saturation) . . . 80 Adjusting Image Contrast .
Page 7 Printing Printing Snapshots..........109 Connecting Directly to a PictBridge Compatible Printer .
Page 8 Configuring Monitor Screen Settings Using the On-screen Histogram to Check Exposure ....144 How to Use the Histogram ........145 Appendix Precautions during Use .
Page 9: General Guide
General Guide The numbers in parentheses indicate the pages where each item is explained. . Camera Front Zoom controller (pages 21, 42, 85, 86) Shutter button (page 21) [ON/OFF] (Power) (page 20) Microphone (pages 48, 103) Front lamp (pages 24, 65, 71) Lens Flash (page 32) Ô...
Page 10: Monitor Screen Contents
Monitor Screen Contents The monitor screen uses various indicators, icons, and values to keep you informed of the camera’s status. • The sample screens in this section are intended to show you the locations of all the indicators and figures that can appear on the monitor screen in various modes. They do not represent screens that actually appear on the camera.
Page 11: Movie Recording
. Movie Recording 1 2 3 . Snapshot Viewing blbk . Movie Playback Flash (page 32) Recording mode (page 47) White balance setting (page 78) Remaining movie memory capacity (page 47) Movie recording time (page 47) Exposure compensation (page 41) Battery level indicator (page 16) Histogram (page 144) File type...
Page 12: Quick Start Basics
Quick Start Basics What is a digital camera? A digital camera stores images on a memory card, so you can record and delete images a countless number of times. Record Delete Play You can use the images you record in a variety of different ways.
Page 13: What You Can Do With Your Casio Camera
What you can do with your CASIO camera Your CASIO camera is packed with a powerful selection of features and functions to make recording of digital images easier, including the following three main functions. Dynamic Photo Extract a moving subject out of a series of Continuous Shutter images you have shot and insert them into another image to create a Dynamic Photo image that features the moving subject.
Page 14: First, Charge The Battery Prior To Use
Note that the battery of a newly purchased camera is not charged. Perform the steps under “To charge the battery” to bring the battery to a full charge. • Your camera requires a special CASIO rechargeable lithium ion battery (NP-90) for power. Never try to use any other type of battery.
Page 15: To Load The Battery
Other Charging Precautions • Use the special charger (BC-90L) to charge the special lithium ion battery (NP-90). Never use any other type of charger device. Attempting to use a different charger can result in unexpected accident. • A battery that is still warm due to normal use may not charge fully. Give the battery time to cool before charging it.
Page 16 Checking Remaining Battery Power As battery power is consumed, a battery indicator on the monitor screen indicates remaining power as shown below. Remaining Power Battery Indicator Indicator Color indicates battery power is low. Charge the battery as soon as possible. Recording is not possible when •...
Page 17: Configuring Basic Settings The First Time You Turn On The Camera
Configuring Basic Settings the First Time You Turn On the Camera The first time you load a battery into the camera, a screen appears for configuring the display language, date, and time settings. Failure to set the date and time correctly will cause the wrong date and time data to be recorded with images.
Page 18: Preparing A Memory Card
NOTE • Each country controls its local time offset and the use of summer time, and so they are subject to change. • Removing the battery from the camera too soon after configuring time and date settings for the first time can cause the settings to be reset to their factory defaults. Do not remove the battery for at least 24 hours after configuring settings.
Page 19: To Format (Initialize) A New Memory Card
• Should water or any foreign object ever get into the card slot, immediately turn off the camera, remove the battery, and contact your retailer or nearest CASIO authorized service center. To format (initialize) a new memory card You need to format a new memory card before using it for the first time.
Page 20: Turning The Camera On And Off
Turning the Camera On and Off To turn power on To enter the REC Mode, press [ON/OFF] (Power) or [r] (REC). To enter the PLAY mode, press [p] (PLAY). The back lamp will light (green) momentarily and the camera will turn on. If you are entering the REC mode, the lens will extend from the camera at this time.
Page 21: To Shoot A Snapshot
To shoot a snapshot Press [r] (REC) to turn on the camera. Make sure R is on the display. If it isn’t, see page 51. Snapshot mode icon Remaining Snapshot Memory Capacity (page 170) Point the camera at the subject. You can zoom the image, if you want.
Page 22 Half-press the shutter button to focus the image. When focus is complete, the camera will beep, the back lamp will light green, and the focus frame will turn green. Half-press Press lightly until the button stops. Beep, beep (Image is in focus.) Continuing to keep the camera still, press the shutter button the rest of the way down.
Page 23: Using Quick Shutter
. Using Quick Shutter Fully pressing the shutting button without waiting for Auto Focus to operate will record using Quick Shutter (page 73). • With Quick Shutter, the camera focuses faster than normal Auto Focus, which means you can capture quick moving action more easily. Note, however, that some images may be out of focus when Quick Shutter is used.
Page 24: Holding The Camera Correctly
Holding the Camera Correctly Your images will not come out clearly if you move the camera when you press the shutter button. When pressing the shutter button, be sure to hold the camera as shown in the illustration below, and keep it still by pressing your arms firmly against your sides as you shoot.
Page 25: Viewing Snapshots
Viewing Snapshots Use the following procedure to view snapshots on the camera’s monitor screen. • For information about how to play back movies, see page 81. Press [p] (PLAY) to enter the PLAY mode. • This will display one of the snapshots currently stored in memory.
Page 26: Deleting Images
Deleting Images If memory becomes full, you can delete images you no longer need to free up storage and record more images. IMPORTANT! • Remember that a file (image) delete operation cannot be undone. • Deleting an audio snapshot (page 103) deletes both the snapshot and the audio file.
Page 27: Snapshot Shooting Precautions
Snapshot Shooting Precautions Operation • Never open the battery cover while the back lamp is flashing green. Doing so can result in the image you just shot being saved incorrectly, damage to other images stored in memory, malfunction of the camera, etc. •...
Page 28: Snapshot Tutorial
Snapshot Tutorial Using the Control Panel The Control Panel can be used to configure camera settings. In the REC mode, press [SET]. This will select one of the Control Panel icons and display its settings. [8] [2] [4] [6] [SET] Use [8] and [2] to select the setting you want to change.
Page 29: Specifying Control Panel Items
143). Changing the Image Size (Size) . Pixels A digital camera image is a collection of small dots called “pixels”. The more pixels there are in an image, the more detail there will be. However, you generally can do with fewer...
Page 30 . About image sizes The size of an image indicates how many pixels it contains, and is expressed as horizontal pixels vertical pixels. 8M (3264 2448) size image = Approximately 8 million pixels VGA (640 480) size image = Approximately 300,000 pixels Image Size Selection Tips Note that larger images have more pixels, so they take up more memory space.
Page 31 . To select the image size In the REC mode, press [SET]. Use [8] and [2] to select the top Control Panel option (Image Size). Use [ ] and [6] to select an image size and then press [SET]. Suggested Image Size Print Size and (Pixels)
Page 32: Using Flash
Using Flash (Flash) In the REC mode, press [2] ( Use [4] and [6] to select the flash setting you want and then press [SET]. Flash fires automatically in accordance with exposure Auto Flash > (amount of light and brightness) conditions. Flash Off Flash does not fire.
Page 33 NOTE • Take care so your fingers and the strap do not block the flash. • The desired effect may not be obtained when the subject is too far away or too close. • Flash charging time (page 173) depends on operating conditions (battery condition, ambient temperature, etc.).
Page 34: Specifying The Auto Focus Area
Specifying the Auto Focus Area (AF Area) This mode takes readings of a small area in the center of the Spot Í image. This setting works well with focus lock (page 64). When you half-press the shutter button while this setting selected, the camera will select the optimum Auto Focus area from among Multi È...
Page 35: Optimizing Image Brightness
IMPORTANT! • “È Multi” cannot be selected for the Auto Focus area while you are using Face Detection (page 39). • When “Ë Tracking” is selected, simply press [4] or [6]. The focus frame will track the movement of the subject, even if you do not half-press the shutter button. •...
Page 36: Specifying Iso Sensitivity
Specifying ISO Sensitivity (ISO) ISO sensitivity is a measure of sensitivity to light. In the REC mode, press [SET]. Use [8] and [2] to select the fifth Control Panel option from the top (ISO Sensitivity). Use [4] and [6] to select the setting you want and then press [SET]. AUTO Adjusts sensitivity automatically according to conditions ISO 64...
Page 37: Using Continuous Shutter
Using Continuous Shutter (CS) Your camera has four continuous shutter modes. CS speed Depends on Normal memory card Speed CS capacity 4 images per CS: 4 fps second images CS: 10 fps per second 3 images per CS: Flash second •...
Page 38: Specifying The Method For Saving Continuous Shutter Images
Specifying the Method for Saving Continuous Shutter Images Specify the method to use for saving images recorded with the following continuous shutter (CS) modes. CS: 4 fps/10 fps After continuous shutter shooting is finished, use [8] and [2] to select the save method you want and then press [SET]. Save Selected The shot images are played back at slow speed so you can select the images you want to save.
Page 39: Using Face Detection
IMPORTANT! • If there is not enough available capacity on the memory card, you may not be able to record the number of CS images indicated on the monitor screen. Make sure your memory card has sufficient remaining capacity before shooting with using continuous shutter.
Page 40 Use [4] and [6] to select “G Face Detection: On” and then press [SET]. Point the camera at the subject(s). The camera will detect human faces and display a frame around each one. Half-press the shutter button. The camera will focus and the frames around the faces it focuses on will turn green.
Page 41: Correcting Image Brightness
Correcting Image Brightness (EV Shift) You can manually adjust an image’s exposure value (EV value) before shooting it. • Exposure Compensation Range: –2.0EV to +2.0EV • Unit: 1/3EV In the REC mode, press [SET]. Use [8] and [2] to select the second Control Panel option from the bottom (EV Shift).
Page 42: Changing The Control Panel Date/Time Style
Changing the Control Panel Date/Time Style In the REC mode, press [SET]. Use [8] and [2] to select the bottom Control Panel option (Date/Time). Use [4] and [6] to select the date or time. NOTE • You can select either of two display style (page 139) for the date: Month/Day or Day/Month.
Page 43: Optical Zoom And Digital Zoom Switch Point
NOTE • The higher the digital zoom factor, the coarser the recorded image. Note that the camera also has a function that lets you record using digital zoom without image deterioration (page 44). • Use of a tripod is recommended to protect against image blur due to camera movement when shooting with telephoto.
Page 44: Shooting With The Make-Up Mode
• The image deterioration point depends on the image size (page 29). The smaller the image size, the higher the zoom factor you can use before reaching the image deterioration point. • Though digital zoom generally causes a deterioration of image quality, some digital zoom without image deterioration is possible with image sizes of “8M”...
Page 45: Shooting Beautiful Scenery Images
Point the camera at the subject(s). The camera will detect human faces and display a frame around each one. Half-press the shutter button. The camera will focus on the face, which will cause frames around it to turn green. When you are ready to shoot, press the shutter button all the way down.
Page 46 Use [4] and [ ] to select the Landscape Mode setting you want. Vivid Enhances colors to produce a clearer, more vivid landscape Landscape image. Corrects for misty and cloudy conditions for scenery images Mist Removal that appear as if they were shot on a clear day. •...
Page 47: Recording Movie Images And Audio
Recording Movie Images and Audio To record a movie Configure the quality setting for the movie (page 77). The length of the movie you can record will depend on the quality setting you select. In the REC mode, point the camera at the subject and then press [0] (Movie).
Page 48 NOTE • Spending a long time using movie recording will cause the camera to become slightly warm to the touch. This is normal and does not indicate malfunction. • The camera also records audio. Note the following points when shooting a movie. –...
Page 49: Shooting A Snapshot While Shooting A Movie
Shooting a Snapshot while Shooting a Movie While a movie is being recorded, press the shutter button. Movie recording continues after the snapshot is recorded. NOTE • You can use [2] ( ) while shooting a movie to change the flash mode setting. •...
Page 50: To Play Back An Audio Recording
NOTE • You can use [8] (DISP) during audio recording to toggle the monitor screen on and off. • When monitor screen contents are turned off, selecting the “Voice Recording” scene will cause the monitor screen to turn off immediately (page 144). About audio data •...
Page 51: Using Best Shot
Using BEST SHOT What is BEST SHOT? BEST SHOT provides you with a collection of sample “scenes” that show a variety of different types of shooting conditions. When you need to change the setup of the camera, simply find the scene that matches what you are trying to achieve, and the camera sets up for it automatically.
Page 52 Press [SET] to configure the camera with the settings for the currently selected scene. This returns to the REC mode. • The settings of the scene you selected remain in effect until you select a different scene. • To select a different BEST SHOT scene, repeat the above procedure from step 1.
Page 53 . BEST SHOT Precautions • The following BEST SHOT scenes cannot be used while recording a movie: Dynamic Photo, Multi-motion Image, ID Photo, Business cards and documents, White board, etc., Self-portrait (1 person), Self-portrait (2 people) • The following BEST SHOT scene cannot be used while shooting a snapshot: For YouTube.
Page 54: Creating Your Own Best Shot Setups
Creating Your Own BEST SHOT Setups You can save up to 999 camera setups as user BEST SHOT scenes for instant recall whenever you need them. On the BEST SHOT scene menu, select the scene named BEST SHOT (Register User Scene). Use [4] and [6] to select the snapshot or movie whose setup you want to save.
Page 55: Shooting With Auto Best Shot
Shooting with AUTO BEST SHOT With AUTO BEST SHOT, the camera automatically selects the BEST SHOT scene that suits your subject and shooting conditions, and configures its settings accordingly. The following are the scenes selected automatically by AUTO BEST SHOT. Portrait, Scenery, Night Scene, Night Scene Portrait, Macro, Sports, etc.
Page 56: Shooting Id Photographs
Shooting ID Photographs You can use this procedure to shoot a portrait and then print it out in the following standard ID photo sizes: 30 Press [BS] and then select the “ID Photo” scene. Press the shutter button to shoot a portrait of the person for whom you want to create an ID photo.
Page 57: Shooting Images Of Business Cards And Documents
Shooting Images of Business Cards and Documents A process called “keystone correction” makes lines straight and natural, even if rectangular subjects are shot from an angle. BEST SHOT has two scenes. Press [BS] and then select the “Business cards and documents” or “White board, etc.”...
Page 58: Recording A Self-Portrait
NOTE • When composing an image like the ones shown above, make sure that the entire outline of the object you are trying to shoot is enclosed within the monitor screen. • Make sure the object is against a background that allows its outline to stand out. •...
Page 59: Isolating Moving Subjects
NOTE • To shoot with the self-portrait feature in combination with a continuous shutter (CS) mode (page 37), turn off the Make-up Mode (page 44). Operation is the same as that when a continuous shutter (CS) mode is used in combination with Auto Shutter.
Page 60: Advanced Settings
Advanced Settings The following are menu operations you can use to configure various camera settings. • You also can use the Control Panel (page 28) to configure some of the settings that appear on the menu screen. Refer to the page references provided in this section for information about configuring settings using the Control Panel.
Page 61 Use [8] and [2] to select the menu item you want, and then press [6]. Use [8] and [2] to change the setting. After the setting is the way you want, press [SET]. • Pressing [ ] registers the selected setting and returns to the menu.
Page 62: Rec Mode Settings
REC Mode Settings (REC) Selecting a Focus Mode (Focus) Procedure [r] (REC) * [MENU] * REC Tab * Focus Type of Settings Shot Q Auto General Focus recording ´ Close ups Macro Scenery and other distant Infinity subjects When you Manual want to focus Focus...
Page 63 To focus with manual focus On the monitor screen, compose the image so the subject you want to focus on is within the yellow boundary. Watching the image on the monitor screen use [4] and [6] to adjust focus. • At this time the image that is within the boundary will enlarge and fill the monitor screen, which aids in focusing.
Page 64: Using Continuous Shutter
Using Focus Lock “Focus lock” is a technique you can use when you want to compose an image in which the subject you want to focus on is not within the focus frame in the center of the screen. • To use focus lock, select “Í Spot” or “Ë Tracking” for the Auto Focus area (page 34).
Page 65: Using The Self-Timer
Using the Self-timer (Self-timer) Procedure [r] (REC) * [MENU] * REC Tab * Self-timer With the Self-timer, pressing the shutter button starts a timer. The shutter is released and the image is shot after a fixed amount of time. 10 sec 10-second Self-timer „...
Page 66: Using Auto Shutter
Using Auto Shutter (Auto Shutter) Procedure [r] (REC) * [MENU] * REC Tab * Auto Shutter With Auto Shutter, the camera releases the shutter automatically when it detects that certain conditions are present. Camera releases the shutter automatically when it detects Detect Blur image blur to camera and subject movement are ¸...
Page 67 . To use Detect Panning to minimize image blur (Detect Panning) Point the camera at location where the subject will pass and then half- press the shutter button to adjust exposure and focus. Press the shutter button the rest of the way down.
Page 68 . To change Auto Shutter trigger sensitivity (Sensitivity) Use [8] and [2] to select “Sensitivity” and then press [6]. Use [4] and [6] to select the sensitivity setting you want, and then press [SET]. • You can select any one of three sensitivity levels, from ø (Lowest) to œ...
Page 69: Shooting With Face Detection
IMPORTANT! • If the camera remains in Auto Shutter standby without releasing the shutter, you can record an image by pressing the shutter button all the way down again. • Detect Blur and Detect Panning may not produce the desired effect when shooting in an area where dim lighting requires a slow shutter speed, or when the subject is moving extremely quickly.
Page 70: Shooting With Continuous Auto Focus
Your digital camera is equipped with a CCD shift type camera shake correction feature and a high-sensitivity anti image blur feature. These two features work in concert to minimize the effects of hand and subject movement.
Page 71: Specifying The Auto Focus Area
NOTE • Only Camera Stabilizer can be used during movie recording. • ISO sensitivity, aperture, and shutter speed do not appear on the monitor screen when you half-press the shutter button while “D Auto” or “S Image AS” is selected. These values will appear briefly, however, in the preview image that is displayed immediately after you shoot a snapshot.
Page 72: Changing The Focus Frame Shape
Changing the Focus Frame Shape (Focus Frame) Procedure [r] (REC) * [MENU] * REC Tab * Focus Frame You can use this procedure to select from among five different shapes, including a heart shape, for the focus frame. Settings NOTE •...
Page 73: Assigning Functions To The [4] And [6] Keys
Assigning Functions to the [ Procedure [r] (REC) * [MENU] * REC Tab * L/R Key You can assign one of the five functions listed below to the [ Setting ] key operation Metering Changes the Metering Mode (page 79) EV Shift Adjusts the EV shift value (page 41) White Balance Changes the white balance setting (page 78)
Page 74: Displaying The On-Screen Grid
Displaying the On-screen Grid (Grid) Procedure [r] (REC) * [MENU] * REC Tab * Grid The on-screen grid can be displayed on the REC mode monitor screen for easy vertical and horizontal alignment when composing images. Turning on Image Review (Review) Procedure [r] (REC) * [MENU] * REC Tab * Review While Review is turned on, the camera will display a image for about one second...
Page 75: Configuring Power On Default Settings
Configuring Power On Default Settings (Memory) Procedure [r] (REC) * [MENU] * REC Tab * Memory When you turn off the camera, it remembers the current settings of all enabled memory items and restores them when you turn it back on. Any memory item that is disabled will be returned to its initial default setting whenever you turn off the camera.
Page 76: Image Quality Settings
Image Quality Settings (Quality) Specifying Snapshot Size (Size) Procedure [r] (REC) * [MENU] * Quality Tab * Size For details, see the Control Panel procedure on page 31. Specifying Snapshot Image Quality (Quality (Snapshot)) Procedure [r] (REC) * [MENU] * Quality Tab * T Quality (Snapshot) Fine Gives image quality priority Normal...
Page 77: Specifying Movie Image Quality
Specifying Movie Image Quality (Quality (Movie)) Procedure [r] (REC) * [MENU] * Quality Tab * » Quality (Movie) Movie image quality is a standard that determines the detail, smoothness, and clarity of a movie during playback. Shooting with the high-quality (HD) setting will result in better image quality, but it also shortens the amount of time you can shoot.
Page 78: Controlling White Balance
Controlling White Balance (White Balance) Procedure [r] (REC) * [MENU] * Quality Tab * White Balance You can adjust white balance to match the source of light available where you are shooting and avoid the blue cast that results when shooting outdoors when it is cloudy, and the green cast that results when shooting under fluorescent lighting.
Page 79: Specifying Iso Sensitivity
Specifying ISO Sensitivity (ISO) Procedure [r] (REC) * [MENU] * Quality Tab * ISO For details, see the Control Panel procedure on page 36. Specifying the Metering Mode (Metering) Procedure [r] (REC) * [MENU] * Quality Tab * Metering The metering mode determines what part of the subject is metered for exposure. Multi-pattern metering divides the image into sections and measures the light in each section for a balanced exposure reading.
Page 80: Using Built-In Color Filters
Using Built-in Color Filters (Color Filter) Procedure [r] (REC) * [MENU] * Quality Tab * Color Filter Settings: Off, B/W, Sepia, Red, Green, Blue, Yellow, Pink, and Purple Controlling Image Sharpness (Sharpness) Procedure [r] (REC) * [MENU] * Quality Tab * Sharpness You can specify one of five sharpness settings from +2 (sharpest) to –2 (least sharp).
Page 81: Viewing Snapshots And Movies
Viewing Snapshots and Movies Viewing Snapshots See page 25 for the procedure for viewing snapshots. Viewing a Movie Press [p] (PLAY) and then use [4] and [6] to display the movie you want to view. Press [SET] to start playback. Movie Playback Controls [4] [6] Fast forward/...
Page 82: Viewing Continuous Shutter Images
Viewing Continuous Shutter Images Each time you perform a continuous shutter (CS) operation, the camera creates a CS group that includes all of the images for that particular CS session. You can use the following procedure to play back the images in a particular CS group. Press [ ] (PLAY) and then use [ whose images you want to view.
Page 83: Deleting Continuous Shutter Images
NOTE • Multiple images shot using “CS: Normal Speed CS” are stored individually and are not grouped. This means they can be displayed individually (page 25) but not as a CS group. Deleting Continuous Shutter Images You can use the following procedures to delete images while playback is in progress or paused.
Page 84: Dividing Up A Cs Group
Dividing Up a CS Group Use the following to divide up a CS Group into individual images. . Dividing Up a Specific CS Group While a CS group folder is displayed, press [MENU]. Use [ ] and [ ] to select “PLAY” tab. Use [ ] and [ ] to select “Divide Group”...
Page 85: Zooming An On-Screen Image
Zooming an On-screen Image In the PLAY mode, use [4] and [6] to scroll through the images until the one you want is displayed. Slide the zoom controller towards z ( zoom. You can use [8], [2], [4], and [6] to scroll the zoomed image on the monitor screen.
Page 86: Displaying The Image Menu
Displaying the Image Menu In the PLAY Mode, slide the zoom controller towards w (]). Use [8], [2], [4] and [6] to move the selection boundary around the image menu. To view a particular image, use [8], [2], [4], or [6] to move the selection boundary to the image you want and then press [SET].
Page 87: Viewing Snapshots And Movies On A Tv Screen
Viewing Snapshots and Movies on a TV Screen Use the AV cable that comes with the camera to connect it to the TV. Yellow Video Audio AUDIO IN jacks (white) VIDEO IN jack (yellow) Making sure that the 6 mark on the camera is aligned with the 4 mark of the AV cable connector, connect the cable to the camera.
Page 88 Now you can display images and play back movies as you normally do. IMPORTANT! • Before connecting to a TV to display images, be sure to configure the camera’s [r] (REC) and [p] (PLAY) buttons for “Power On” or “Power On/Off” (page 141). •...
Page 89: Other Playback Functions (Play)
Other Playback Functions (PLAY) This section explains menu items that you can use to configure settings and perform other playback operations. For information about menu operations, see page 60. Playing a Slideshow on the Camera (Slideshow) Procedure [p] (PLAY) * [MENU] * PLAY Tab * Slideshow Start Starts the slideshow Images...
Page 90: Saving Music From Your Computer To Camera Memory
Effect Select the effect you want. Pattern 1 to 5: Plays background music and applies an image change effect. • Patterns 1 through 4 have different background music, but they all use the same image change effect. • Pattern 5 can be used for playback of snapshots only, and the “Interval” setting is ignored.
Page 91 Connect the camera to your computer (pages 117, 126). If you plan to save the music files to the camera’s memory card, make sure the card is loaded in the camera. Perform one of the following operations to open the memory card or built-in memory.
Page 92: Laying Out Snapshots With Layout Print
Laying Out Snapshots with Layout Print (Layout Print) Procedure [p] (PLAY) * Spnapshot Screen * [MENU] * PLAY Tab * Layout Print You can use the following procedure to insert existing snapshots into the frames of a layout and produce a new image that contains multiple snapshots.
Page 93: Creating A Snapshot Of Movie Frames
Creating a Snapshot of Movie Frames (MOTION PRINT) Procedure [p] (PLAY) * Movie Screen to be Used * [MENU] * PLAY Tab * MOTION PRINT Use [4] and [6] to scroll through the movie frames and display the one you want to use as the image of the MOTION PRINT image.
Page 94: Editing A Movie On The Camera
Editing a Movie on the Camera (Movie Editing) Procedure [p] (PLAY) * Movie Screen of Movie to be Edited * [MENU] * PLAY Tab * Movie Editing The Movie Editing feature lets you use one of the following procedures to edit out a specific part of a movie.
Page 95 Use [8] and [2] to select “Yes” and then press [SET]. The selected cut operation will take considerable time to complete. Don’t try to perform any camera operation until the “Busy... Please wait...” message disappears from the monitor screen. Note that a cut operation can take a long time if the movie being edited is long.
Page 96: Optimizing Image Brightness
Optimizing Image Brightness (Lighting) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Lighting You can use this setting to optimize the balance between bright areas and dark areas in existing images. Performs a higher level of brightness correction than the “+1” setting. Performs brightness correction.
Page 97: Adjusting White Balance
Adjusting White Balance (White Balance) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * White Balance You can use the white balance setting to select a light source type for a recorded image, which will affect the colors of the image. Daylight Outdoors, fair weather ¤...
Page 98: Adjusting The Brightness Of An Existing Snapshot
Adjusting the Brightness of an Existing Snapshot (Brightness) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Brightness You can select one of five brightness levels, from +2 (brightest) to –2 (least bright). NOTE • The original snapshot is retained in memory and not deleted. •...
Page 99: Using Color Correction To Correct The Color Of An Old Photograph
Using Color Correction to Correct the Color of an Old Photograph (Color Correction) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Color Correction Color Correction lets you correct the color of an old photograph. The corrected image is saved as 2M (1600 1200 pixels) size.
Page 100: Selecting Images For Printing
Selecting Images for Printing (DPOF Printing) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * DPOF Printing See page 112 for details. Protecting a File Against Deletion (Protect) Procedure [p] (PLAY) * [MENU] * PLAY Tab * Protect Protects specific files.
Page 101: Editing The Date And Time Of An Image
Editing the Date and Time of an Image (Date/Time) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Date/Time [8] [2] Changes the setting at the cursor location [4] [6] Moves the cursor between settings [BS] Toggles between 12-hour and 24-hour format When the date and time settings are what you want, press [SET] to apply them.
Page 102: Resizing A Snapshot
Resizing a Snapshot (Resize) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Resize You can reduce the size of a snapshot and save the result as a separate snapshot. The original snapshot is also retained. You can select resize an image to one of three image sizes: 8M, 5M, VGA.
Page 103: Adding Audio To A Snapshot
Adding Audio to a Snapshot (Dubbing) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Dubbing You can add audio to a snapshot after you shoot it. You can re-record a snapshot’s audio whenever you want. You can record up to about 30 seconds of audio for a single snapshot.
Page 104: Copying Files
Voice Recording Playback Controls Fast forward/fast reverse Play/pause Volume adjustment Display content switching Stop playback • Audio of an Audio Snapshot also can be played back on a computer with Windows Media Player or QuickTime. Copying Files (Copy) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Copy Files can be copied from the camera’s built-in memory to a memory card or from a memory card to built-in memory.
Page 105: Dynamic Photo
Dynamic Photo You can use the procedures in this section to crop either a moving subject or a still subject out of a snapshot and then insert it into another snapshot. Moving Subject To create a subject image to be inserted (Dynamic Photo) Press [BS] and then select the “Dynamic Photo”...
Page 106 First, shoot an image that includes the subject you want to extract. • Shoot an image in which the subject is as large as possible. Also, the image should include some easily identifiable reference point that you can use for later alignment in step 4, below.
Page 107: Inserting A Subject Into A Background Image
Inserting a Subject into a Background Image (Dynamic Photo) Use the following procedure to insert a subject into a new background image. A Dynamic Photo with a moving subject is saved as a 2M (1600 smaller size image. A Dynamic Photo with a still subject is saved as a 6M (2816 2112 pixels) or smaller size image.
Page 108: To View A Dynamic Photo
NOTE • The camera comes with a number of extracted sample subjects in its built-in memory, which you can use to create Dynamic Photos, if you like. • Performing a delete or format operation will delete the sample subjects in built-in memory.
Page 109: Printing
Printing Printing Snapshots Professional Print Service You can take a memory card that contains the images you want to print to a professional print service and have them printed. Printing on a Home Printer Printing Images on a Printer with Memory Card Slot You can use a printer equipped with a memory card slot to print images directly from a memory card.
Page 110: Connecting Directly To A Pictbridge Compatible Printer
Connecting Directly to a PictBridge Compatible Printer You can connect the camera directly to a printer that supports PictBridge and print images without going through a computer. . To set up the camera before connecting to a printer Turn on the camera and press [MENU]. On the “Set Up”...
Page 111 . To print Turn on the printer and load paper. Turn on the camera. This will display the print menu screen. Use [8] and [2] to select “Paper Size”, and then press [6]. Use [8] and [2] to select a paper size and then press [SET].
Page 112: Using Dpof To Specify Images To Be Printed And The Number Of Copies
Using DPOF to Specify Images to be Printed and the Number of Copies . Digital Print Order Format (DPOF) DPOF is a standard that allows you to include image type, number of copy, and time stamp on/off information on the memory card with the images. After configuring settings, you can use the memory card to print on a home printer that supports DPOF or take the memory card to a professional print service.
Page 113 . Configuring the Same DPOF Settings for All the Images Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * DPOF Printing * All images Use [8] and [2] to specify the number of copies. You can specify a value up to 99. Specify 00 if you do not want to print the image. •...
Page 114: Date Stamping
. Date Stamping You can use one of the following three methods to include the recording date in the printout of an image. Configuring camera settings Configure DPOF settings (page 112). You can turn date stamping on and off each time you print. You can configure settings so some images include the date stamp and some don’t.
Page 115: Using The Camera With A Computer
Using the Camera with a Computer Things you can do using a computer... You can perform the operations described below while the camera is connected to a computer. Save images to a computer and view them there Transfer images stored on your computer to camera memory Playback and...
Page 116: Using The Camera With A Windows Computer
View the User’s Vista / XP (SP2/SP3) / Guide 2000 (SP4) Photo Transport and YouTube Uploader for CASIO will not run under 64-bit versions of Windows Vista. Install this software: Installation not required. Installation not required. • Windows Media Player,...
Page 117: Computer System Requirements For Bundled Software
. Computer System Requirements for Bundled Software Computer system requirements are different for each of the applications. See the “Read me” file that comes with each application for details. Information about computer system requirements also can be found under “Computer System Requirements for Bundled Software (Bundled CD-ROM)”...
Page 118: Your Computer
Turn off the camera and then use the USB cable that comes with the camera to connect it to your computer. • The camera does not draw power over the USB cable. Make sure the camera’s battery is sufficiently charged before connecting.
Page 119 Right-click the “DCIM” folder. On the shortcut menu that appears, click “Copy”. Windows Vista users: Click “Start” and then “Documents”. Windows XP users: Click “Start” and then “My Documents”. Windows 2000 users: Doubleclick “My Documents” to open it. • If you already have a “DCIM” folder in “My Documents”, the next step will overwrite it.
Page 120: Playing Movies
Double-click the image file you want to view. • For information about file names, see “Memory Folder Structure” on page 133. • An image that was rotated on the camera will be displayed on your computer screen in its original (unrotated) orientation. Never use your computer to modify, delete, move, or rename any image files that are in the camera’s built-in memory or on its memory card.
Page 121: Uploading Movie Files To Youtube
Uploading Movie Files to YouTube Installing YouTube Uploader for CASIO from the CD-ROM that comes with your camera simplifies uploading of movie files you recorded with the “For YouTube” BEST SHOT scene to YouTube.
Page 122 . To upload a movie file to YouTube • Before you can use YouTube Uploader for CASIO, you need to go to the YouTube website (http://www.youtube.com/) and register as a user there. • Do not upload any video that is copyrighted (including neighboring copyrights) unless you yourself own the copyright or you have obtained the permission of the applicable copyright holder(s).
Page 123: Transferring Images From Your Computer To Camera Memory
. To transfer images to the camera Connect the camera to your computer (page 117). On your computer, click the following: Start * All Programs * CASIO * Photo Transport. This starts up Photo Transport. Drag the file(s) you want to transfer to the [Transfer] button.
Page 124 . To transfer computer screen captures to the camera Connect the camera to your computer (page 117). On your computer, click the following: Start * All Programs * CASIO * Photo Transport. This starts up Photo Transport. Display the screen whose screen capture you want to transfer.
Page 125: Viewing User Documentation
On the menu screen, click the “Language” down arrow button and then select the language you want. Click “Manual” to select it and then click “Digital Camera”. IMPORTANT! • You must have Adobe Reader or Adobe Acrobat Reader installed on your computer in order to view the contents of a PDF file.
Page 126: Using The Camera With A Macintosh
Using the Camera with a Macintosh Install the required software in accordance with what version of the Macintosh OS you are running and what you want to do. Operating When you want to System do this: Version Save images to your OS 9 Macintosh and view OS X...
Page 127: Your Macintosh
Turn off the camera and then use the USB cable that comes with the camera to connect it to your Macintosh. • The camera does not draw power over the USB cable. Make sure the camera’s battery is sufficiently charged before connecting.
Page 128: To View Copied Images
After the copy operation is complete, drag the drive icon to Trash. On the camera, press [ON/OFF] to turn off the camera. After making sure that the green back lamp is unlit, disconnect the camera from the computer. . To view copied images Double-click the camera’s drive icon.
Page 129: Transferring Images Automatically And Managing Them On Your Macintosh
Transferring Images Automatically and Managing Them on Your Macintosh If you are running Mac OS X, you can manage snapshots using iPhoto, which comes bundled with some Macintosh products. If you are running Mac OS 9, you will need to use commercially available software.
Page 130: Viewing User Documentation
Open the file named “camera_xx.pdf”. • “xx” is the language code (Example: camera_e.pdf is for English.) User Registration Internet registration only is supported. Visit the following CASIO website to register: http://world.casio.com/qv/register/ Using an Eye-Fi Wireless SD Memory Card to Transfer Images...
Page 131 IMPORTANT! • Recorded images are transferred over wireless LAN. Do not use the Eye-Fi card or turn off Eye-Fi card communication (page 135) when on an aircraft or in any other location where use of wireless communication is limited or prohibited. •...
Page 132: Files And Folders
Files and Folders The camera creates a file and saves it each time you shoot a snapshot, record a movie, or perform any other operation that stores data. Files are grouped by storing them in folders. Each file and folder has its own unique name. •...
Page 133: Memory Card Data
Memory Card Data The camera stores images you shoot in accordance with the Design Rule for Camera File System (DCF). . About DCF DCF is a standard that makes it possible to view and print images recorded on one manufacturer’s camera on DCF-compliant devices produced by other manufacturers. You can transfer DCF-compliant images recorded with another camera to this camera and view them on this camera’s monitor screen.
Page 134: Supported Image Files
. Supported Image Files • Image files shot with this camera • DCF-compliant image files This camera may not be able to display an image, even if it is DCF-compliant. When displaying an image recorded on another camera, it may take a long time for the image to appear on this camera’s monitor screen.
Page 135: Other Settings (Set Up)
Other Settings (Set Up) This section explains menu items that you can use to configure settings and perform other operations in both the REC mode and PLAY mode. For information about menu operations, see page 60. Enabling Power Saving (Power Saving) Procedure [MENU] * Set Up Tab * Power Saving Enabling power saving reduces the brightness of the monitor screen and configures...
Page 136: Configuring Camera Sound Settings
Configuring Camera Sound Settings (Sounds) Procedure [MENU] * Set Up Tab * Sounds Startup Specifies the startup sound Half Shutter Sound 1 - 5: Built-in sounds (1 through 5) Shutter Off: Sound off Operation Specifies the sound volume. This setting is also used as the Operation ( audio level during video output (page 87).
Page 137: Specifying The File Name Serial Number Generation Rule
Specifying the File Name Serial Number Generation Rule (File No.) Procedure [MENU] * Set Up Tab * File No. Use the following procedure to specify the rule that governs generation of the serial number used in file names (page 132). Tells the camera to remember the last used file number.
Page 138: Time Stamping Snapshots
Use [8], [2], [4], and [6] to select the geographic area you want and then press [SET]. Use [8] and [2] to select the city you want and then press [SET]. Press [SET]. IMPORTANT! • Before configuring World Time settings, make sure that the Home City setting is the place where you live or normally use the camera.
Page 139: Setting The Camera's Clock
Setting the Camera’s Clock (Adjust) Procedure [MENU] * Set Up Tab * Adjust [8] [2] Change the setting at the cursor location [4] [6] Move the cursor between settings [BS] Toggles between 12-hour and 24-hour format When the date and time settings are what you want, press [SET] to apply them. •...
Page 140: Specifying The Display Language
Specifying the Display Language (Language) Procedure [MENU] * Set Up Tab * Language . Specify the display language you want. Select the tab on the right. Select “Language”. Select the language you want. Configuring Sleep State Settings (Sleep) Procedure [MENU] * Set Up Tab * Sleep This feature turns off the monitor screen whenever no camera operation is performed for a preset amount of time.
Page 141: Configuring Auto Power Settings
Configuring Auto Power Settings (Auto Power Off) Procedure [MENU] * Set Up Tab * Auto Power Off Auto Power Off turns off the camera whenever no camera operation is performed for a preset amount of time. Trigger Time Settings: 1 min, 2 min, 5 min (The trigger time is always 5 minutes in the PLAY mode.) •...
Page 142: Configuring Usb Protocol Settings
Configuring USB Protocol Settings (USB) Procedure [MENU] * Set Up Tab * USB You can use the procedure below to select the USB communication protocol, which is used when exchanging data with a computer, printer, or other external device. Select this setting when connecting to a computer (pages 117, Mass 126).
Page 143: Formatting Built-In Memory Or A Memory Card
Formatting Built-in Memory or a Memory Card (Format) Procedure [MENU] * Set Up Tab * Format If a memory card is loaded in the camera, this operation will format the memory card. It will format built-in memory if no memory card is loaded. •...
Page 144: Configuring Monitor Screen Settings
Configuring Monitor Screen Settings You can turn display information on and off by pressing [8] (DISP). You can configure separate settings for the REC mode and PLAY mode. Information display on Information display + Histogram on Information display off Using the On-screen Histogram to Check Exposure Displays a histogram on the monitor screen which you can use to check the exposure of an image before you shoot it.
Page 145: How To Use The Histogram
How to Use the Histogram A histogram is a graph that represents the lightness of an image in terms of the number of pixels. The vertical axis indicates the number of pixels, while the horizontal axis indicates lightness. If the histogram appears too lopsided for some reason, you can use EV shift to move it left or right in order to achieve better balance.
Page 146: Appendix
Appendix Precautions during Use . Avoid Use While In Motion • Never use the camera to record or play back images while operating an automobile or other vehicle, or while walking. Looking at the monitor while in motion creates the risk of serious accident. .
Page 147 • Never try to take the camera apart or modify it in any way. Doing so creates the risk of electric shock, burn injury, and other personal injury. Be sure to leave all internal inspection, maintenance, and repair up to your dealer or nearest CASIO authorized service center.
Page 148: Memory Protection
• The battery is intended for use with a CASIO Digital Camera only. Use with any other device creates the risk of the battery damage, or deterioration of battery performance and service life.
Page 149: Battery Life
• If battery charging does not end normally within the specified charging time, stop charging anyway and contact your local CASIO authorized service center. Continued charging creates the risk of battery overheating, fire, and explosion.
Page 150: Data Error Precautions
. Data Error Precautions Your digital camera is manufactured using precision digital components. Any of the following creates the risk of corruption of data in camera memory. – Removing the battery or memory card while the camera is performing some operation –...
Page 151: Caring For Your Camera
0 Should the power cord ever become damaged (to the point that internal wires are exposed or cut), immediately contact your original retailer or authorized CASIO authorized service center to request repair. Continued use of a damaged power cord creates the risk of fire, malfunction, and electric shock.
Page 152: Other Precautions
Note that CASIO COMPUTER CO., LTD. shall not be held liable for use of this product in any way that infringes on the copyrights of others or that violates copyright laws.
Page 153 Any and all unauthorized commercial copying, distribution, and copying of the bundled software over a network are prohibited. This product contains PrKERNELv4 Real-time OS of eSOL Co., Ltd. Copyright 2007 eSOL Co., Ltd. © PrKERNELv4 is a registered trademark of eSOL Co., Ltd. in Japan.
Page 154: Power Supply
If problems continue to occur after you perform the above steps, it could mean that the battery is faulty. Contact your nearest CASIO authorized service center. To replace the battery Open the battery cover and remove the current battery.
Page 155: Battery Precautions
Battery Precautions . Precautions during Use • Operation provided by a battery under cold conditions is always less than operation under normal temperatures. This is due to the characteristics of the battery, not the camera. • Charge the battery in an area where the temperature is within the range of 5°C to 35°C (41°F to 95°F).
Page 156: Using A Memory Card
Using a Memory Card See page 18 for information about supported memory cards and how to load a memory card. To replace the memory card Press the memory card and then release it. This will cause it to pop out of the memory card slot slightly. Pull the card out the rest of the way and then insert another one.
Page 157 . Memory Card Handling Precautions Certain types of cards can slow down processing speeds. In particular, you may experience problems saving high-quality (HD and STD) movies. Use of certain types of memory cards increase the time it takes to record movies, which can cause movie frames to be lost.
Page 158: Computer System Requirements For Bundled Software (Bundled Cd-Rom)
Hard Disk Drive Space : At least 180MB Other : Internet Explorer 6.0 or higher installed For details about the minimum system requirements for each software application, see the “Read me” files on the CASIO Digital Camera Software CD-ROM that comes bundled with the camera. Appendix...
Page 159: Reset Initial Default Settings
Reset Initial Default Settings The tables in this section show the initial default settings that are configured for menu items (displayed when you press [MENU]) after you reset the camera (page 143). Menu items depend on whether the camera is in the REC mode or PLAY mode. •...
Page 160 “Quality” Tab Size 12M (4000 Quality Normal (Snapshots) Quality » (Movies) EV Shift White Balance Auto Auto “Set Up” Tab Power Saving Screen Auto 2 Eye-Fi Startup: Sound 1 / Half Shutter: Sound 1 / Shutter: Sound 1 / Sounds Operation: Sound 1 / = Operation: ...//// /...
Page 161: Play Mode
. PLAY Mode “PLAY” Tab Images: All images / Time: 30 min / Slideshow Interval: 3 sec / Effect: Pattern 1 Dynamic Photo – Movie – Converter Layout Print – MOTION PRINT 9 frames Movie Editing – Lighting – Red Eye –...
Page 162: When Things Don't Go Right
2)The battery may be dead. Charge the battery (page 14). If the battery goes dead soon after being charged, it means the battery has reached the end of its life and needs to be replaced. Purchase a separately available CASIO NP-90 rechargeable lithium ion battery. The camera 1)Auto Power Off may have activated (page 141).
Page 163 (page 32) or select a different BEST SHOT scene (page 51). The ? (Flash Off) The flash unit may be malfunctioning. Contact a CASIO service icon flashes red on center or your original retailer. Note that though the flash will not the monitor screen fire, you still can use the camera for non-flash shots.
Page 164 Problem Possible Cause and Recommended Action A recorded image 1)Camera power may have been turned off before the save was not saved. 2)You may have removed the memory card from the camera Though available Not enough light is reaching the subjects. Change the flash lighting is bright, mode setting to <...
Page 165 Images are not This camera cannot display non-DCF images recorded onto a displayed. memory card using another digital camera. Images cannot be 1)Note that you cannot edit the following types of snapshots. edited (with Layout • Snapshots created using MOTION PRINT Print, resizing, •...
Page 166 If the same message appears after you turn power back on, contact your retailer or a CASIO authorized service center. The time and date Load the camera’s battery and reconfigure the time and date settings configured settings (page 17).
Page 167: Display Messages
Display Messages The camera’s protection function may have activated because camera temperature is too high. Turn off the ALERT camera and wait until it cools down before trying to use it again. Battery is low. Battery power is low. Keystone correction of the image cannot be performed for Cannot correct some reason.
Page 168 If the same LENS ERROR message appears after you turn power back on, contact a CASIO authorized service center or your original retailer. The Camera Shake unit may be malfunctioning. If the same LENS ERROR 2 message appears after you turn power back on, contact your retailer or a CASIO service center.
Page 169 There is no image The setup you are trying to save is for an image that cannot to register. be saved as a user BEST SHOT scene. This card is not The memory card loaded in the camera is not formatted. formatted.
Page 170: Number Of Snapshots/Movie Recording Time/Voice Recording Time
Number of Snapshots/Movie Recording Time/ Voice Recording Time Snapshot Image Size Image (Pixels) Quality Fine (4000 3000) Normal Economy Fine (4000 2656) Normal Economy 16:9 Fine (4000 2240) Normal Economy Fine (3264 2448) Normal Economy Fine (2560 1920) Normal Economy Fine (2048 1536)
Page 171: Voice Recording
Movies Image Maximum Quality File Size (Pixels) 1280 Maximum Movie Size: 4 GB 2.7 Megabits/second Maximum YouTube Movie Length: 10 minutes Voice Recording Maximum File File Format Size 4 GB IMA-ADPCM Built-in memory capacity after formatting The above values are based on use of a PRO HIGH SPEED SD memory card (Panasonic Corporation).
Page 172: Specifications
Specifications File Format Recording Media Recorded Image Sizes Delete Effective Pixels Imaging Element Lens/Focal Distance Zoom Focusing Approximate Focus (Snapshot) (From Lens Surface) Metering Exposure Control Exposure Compensation Shutter Snapshots: JPEG (Exif Version 2.2); DCF 1.0 standard; DPOF compliant Movies: Motion JPEG AVI, IMA-ADPCM audio (monaural) Audio (Voice Recording): WAV (monaural) Built-in Memory (Image Storage Area: 35.7MB*)
Page 173 Shutter Speed Snapshot (Auto): 1/2 to 1/2000 second Snapshot (Night Scene): 4 to 1/2000 second * May differ due to the camera setup. Aperture Value F3.2 (W) to F7.5 (W) (When used with ND filter) * Using optical zoom changes the aperture value. White Balance Auto, Daylight, Overcast, Shade, Day White Fluorescent, Daylight Fluorescent, Tungsten, Manual WB...
Page 174 Approximate Battery Life All of the values provided below represent the approximate amount of time under normal temperature (23°C (73°F)) before the camera turns off. These values are not guaranteed. Low temperatures shorten battery life. Number of Shots (CIPA) (Operating Time)* Continuous Playback (Snapshots)* Approximate continuous movie recording time Continuous Voice Recording*...
Page 175 . Rechargeable lithium ion battery (NP-90) Rated Voltage Rated Capacitance Operating Temperature Dimensions Weight . Charger unit (BC-90L) Input Power Output Power Operating Temperature Supported Battery Type Charging Time Dimensions Weight • Power cord precautions for use in Singapore The power cord set is not supplied. The power cord used must comply with relevant national and/or international standards.
Page 176 CASIO COMPUTER CO.,LTD. 6-2, Hon-machi 1-chome Shibuya-ku, Tokyo 151-8543, Japan MA0910-D...
Page 177 Dynamic Getting the Most Out of Dynamic Photo For a wealth of information about Dynamic Photo including explanations about how to use Dynamic Photo images, the Dynamic Studio image conversion service, sample images, and more, visit the special Dynamic Photo website at: This manual provides an introduction to Dynamic Photo, which creates a whole new way to enjoy digital imaging.
Page 178: Dynamic Photo! A Totally New Way To Enjoy Digital Photography
Dynamic Photo! A totally new way to enjoy digital Dynamic Photo makes it easy to crop a moving subject out of a series of images and insert it into other images! A simple operation on the camera extracts a moving subject automatically by cropping up to 20 Continuous Shutter images.
Page 179: Using The Dynamic Photo Extracted Sample Subjects
Using the Dynamic Photo Extracted Sample Subjects Your digital camera comes with a number of extracted sample subjects in its built-in memory. You can use these sample subjects to practice creating Dynamic Photo images by inserting them into your original snapshots.
Page 180 After creation of the Dynamic Photo image is complete, the finished image with the inserted moving subject will appear on the monitor screen. After you master the above procedure using extracted sample subjects, you will be ready to create your own extracted subjects and insert them into snapshots for totally original Dynamic Photo images.
Page 181: Creating A Dynamic Photo Image
Creating a Dynamic Photo Image Step 1: Shoot the subject. Dynamic Photo images are created by extracting the subject out of one image, and inserting it into another image. The term “subject” as used here refers to what you extract or crop out of the first image. Perform the following steps to shoot and extract the subject.
Page 182 First, shoot the subject. Best results can be obtained with the camera secured on a tripod. With the camera pointed at the moving subject, press the shutter button to record. If you selected “Moving Subject”, the camera will record a series of Continuous Shutter (CS) images over a few seconds.
Page 183: Step 2: Create The Dynamic Photo Image
Complete! The camera compares the images you shot in steps 3 and 4 and extracts the subject. The extracted subject image will appear on the monitor screen. If you selected “Moving Subject”, the 20 subject images that were recorded will scroll on the screen, creating the illusion of movement.
Page 184 Use [4] and [6] to select the subject you want to insert and then press [SET]. * Only subjects that can be inserted into other images will appear at this time. Use the zoom controller to adjust the size of the subject and use [8], [2], [4], and [6] to adjust its position.
Page 185: Four Tips For Good Subject Cropping
Four Tips for Good Subject Cropping • When shooting the subject image, shoot against a white wall or some other surface whose color is different from that of the subject. The camera will not be able to crop the subject image properly if its color is the same as or similar to the background color.
Page 186 Move the subject away from the wall to avoid shadows! The camera may mistake shadows on the wall or floor caused by strong sunlight, illumination, or other light sources as part of the subject. Shadows tend to form when the subject is too close to a wall.
Page 187: Specifying The Subject Type And Cs Speed
Specifying the Subject Type and CS Speed Pressing [SET] during step 1 of “3. First, shoot the subject.” will display a screen for specifying the subject type and CS speed. You can select from among the four subject types listed below.
Page 188: On The Camera
Step 3: Have fun with Dynamic Photo. You can use the Dynamic Photo image you created in Step 2 in a variety of fun ways. Step 4: Convert a Dynamic Photo to a Movie A Dynamic Photo is stored as a series of 20 still images. You can use the following procedure to convert the 20 images that make up a Dynamic Photo to a movie.
Page 189: Step 5: Use Dynamic Studio To Expand Use Of Dynamic Photo Images To Other Applications
This makes it possible to view Dynamic Photo images you created with a CASIO EXILIM digital camera to a format that can be played back as a movie on a PC, digital photo frame, cell phone or other device.

Casio Exilim EX-H10 User Manual

Table of Contents

Quick Start Basics

Snapshot Tutorial

Recording Movie Images and Audio

Using BEST SHOT

Advanced Settings

Viewing Snapshots and Movies

Other Playback Functions (PLAY)

Dynamic Photo

Printing

Using the Camera with a Computer

Other Settings (Set Up)

Configuring Monitor Screen Settings

Appendix

Dynamic Photo

Dynamic Photo! a Totally New Way to Enjoy Digital Photography

Using the Dynamic Photo Extracted Sample Subjects

Creating a Dynamic Photo Image

Quick Links

Digital Camera

Chapters

Need help?

Questions and answers

Related Manuals for Casio Exilim EX-H10

Summary of Contents for Casio Exilim EX-H10
