Weight
14.9 kg (33.0 lb)
Display
64 × 128 graphical
Operating Temperature
Minimum
Typical
Maximum
Operating Environment
0%–90% RH noncondensing
Data Communications
USB
Power
110–220 VAC 50/60 Hz
COMPLIANCE
Manufactured under ISO 9001:2015
EM ISO/IEC 17050:2010 (CE Mark)

2.4 USER INTERFACE AND MENUS

The AQUALAB VSA is a standalone instrument with arrows and three buttons useful for
navigating menus and beginning tests. There are four tabs at the top of the display screen,
the Isotherm, Measurement, Configuration, and Data tabs. These tabs indicate the four
menus. The button icons on the display change to show the available actions for the screen
(Table 1).
AQUALAB VSA
4 °C
23 °C
50 °C
