- Page 1 Smart Sensor 2-D Profile Measuring Sensor Short Manual Setting tutorial V1.0...
- Page 2 Max. total length: 27m Data Storage Unit: Sensor Controller: Parallel Output Unit: ZG2-DSU41 ZG2-WDC41A ZG-RPD41 ZG2-DSU11 ZG2-WDC11A ZG-RPD11 Controller Link: ZS-XCN RS232 RS232 RS232 cable: ZS-XPT2 for PLC ZS-XRS2 for PC PC Setup Software „SmartMonitor ZG2“ and USB cable included with the ZG-WDCxxA...
- Page 3 ZG2 Short Manual Overview (11) (12) (13) (10) (14) (1) Judgement Indicator (turns on if judgement result is O.K.) (2) Laser Indicator (turns on while the LASER is powered on) (3) Zero Reset Indicator (turns on while Zero Reset function is active)
- Page 4 ZG2 Short Manual Overview...
- Page 5 If 2 ZG2-WDCxx are used, connect the USB cable only to CH2 Channel assigment is always as shown above (regardless of the presence of a ZG2-DSUxx). The Data Storage Unit ZG2-DSUxx can be used for logging measurement results, logging profiles or storing bank data.
- Page 6 ZG2 Short Manual Tutorial This chapter shows step by step how to set up the ZG2 profile sensor to perform a measurement. Below you can find the 7 steps to follow. More detailed description of each step is given then on the following pages.
- Page 7 ZG2 Short Manual Setting Tutorial 1) Initialization: To operate the menu you can either use the cursor keys and the set key or the number keys. LD ON ZERO TRIG HEIGHT1 B1T1 3.000mm 1-320 Number keys Corsor keys 1 - 4...
- Page 8 2) Mount the sensor head: The ZG2 can measure up to 8 tasks at the same time. The settings for these 8 tasks is stored in 1 bank. Up to 32 banks can be stored in the ZG2-WDC. The bank can be changed in run mode via digital input terminal, RS232 or USB.
- Page 9 ZG2 Short Manual 3) Teach: Store a profile in the internal memory Move the mode switch to the „FUN“ position, push key „1“ for „Meas“, and again key „1“ for „TEACH“. Confirm the teach process with the key „1“ for „YES“.
- Page 10 ZG2 Short Manual 4) Select a measurement item: In order to choose the measurement item for task 1 for the measurement of the width of the bar you have to select the menu „3 SENS“: LD ON ZERO TRIG MEAS „3 SENS“...
- Page 11 ZG2 Short Manual Please select task 1 by pressing the key 1. Now the menu screen for the measurement item apears. In the top line the current item is displayed. The menu allows to 1) select a new item, 2) to set scaling for the output value, 3) to set the measurement region...
- Page 12 ZG2 Short Manual 5) Set the measurement region: The sensor uses up to 4 characteristic points of the profile to calculate the measurement result . For each point you have to define a horizontal region where the sensor finds this characteristic point in RUN mode. This setting is done with the profile which is stored with the teach process.
- Page 13 ZG2 Short Manual LD ON ZERO TRIG MEAS/WIDTH1 1 ITEM 2 CUSTOM 3 SCALE 4 AUTO Now all important settings are made und you can check the result in the RUN mode: Move the mode switch to the „RUN“ position and confirm the settings with key 1 for „YES“.
