Quickplay BALLER MINI HOOP SYSTEM Quick Start Manual page 2

PARTS:
1
15
1. Base
2. Axel
3. Wheel (2)
4. Lower Post
5. Left Support Strut
HARDWARE
SETS:
2
2
3
5
6
13
14
6. Right Support Strut
7. Upper Post
8. Height Adjust Collar
9. Height Adjust Pole
10. Lower Backboard Support Pole (2)
- M8X20 Bolt (2)
x2
- Nylon Washers (2)
A
- M8 Locking Nut
- M8X55 Bolt
x1
B - Nylon Washers (2)
- M8 Locking Nut
x1
C - Height Adjustment Pin
- M8X40 Bolt
x1
- Nylon Washers (2)
D
- M8 Locking Nut
- M8X90 Bolt
x2
E - Nylon Washers (4)
- M8 Locking Nut
- M8X90 Bolt
x1
F - Nylon Washers (2) & Short Spacers (2)
- M8 Locking Nut
- M8X90 Bolt
x2
G - Nylon Washers (2) & Long Spacer
- M8 Locking Nut
- M6X100 Bolt
x1
- Washers (2)
H
- M6 Locking Nut
- M8X65 Bolt
x1
- Spring & Washer
I
- M8 Locking Nut
- M6X16 Pan Head Bolt
x3
J
- Washer & M6 Locking Nut
4
7
8
9
10
11. Upper Backboard Support Pole (2)
12. Backboard
13. Rim
14. Rim Plate
15. Middle Post
A
11
12
G
E
G
H I
J
F
E
C D
YOU WILL NEED
FOR ASSEMBLY:
X2 ADJUSTABLE
WRENCHES
AND/OR
SOCKET WRENCHES
B
A
SAND AND/OR WATER
