en
4

Application/use

4.1

Intended use

4.2

Improper use

5

Product description

5.1

Description

7
6
5
4
Fig. 2: Overview
12
• Storage conditions:
–
Maximum: -15 to +60 °C (5 to 140 °F), max. humidity: 90 %, non-condensing.
–
Recommended: 5 to 25 °C (41 to 77 °F), relative humidity: 40 to 50 %.
–
Protect the pump from direct exposure to sunlight. Extreme heat can cause damage!
• Do not store the pump in rooms where welding work is carried out. The resulting gases
or radiation can corrode the elastomer parts and coatings.
• Seal the suction and discharge connection tightly.
• Protect the connection cable against kinking and damage. Maintain a constant bend ra-
dius!
For pumping in commercial areas of:
• Sewage containing faeces
• Wastewater (with small amounts of sand)
Sewage pumping according to (DIN) EN 12050
The pumps meet the requirements of EN 12050-2.
DANGER
Explosion due to pumping of explosive fluids!
Pumping of highly flammable and explosive fluids (gasoline, kerosene,
etc.) in pure form is strictly prohibited. There is a risk of fatal injury due to
explosion! The pumps are not designed for these fluids.
The submersible pumps must not be used for pumping:
• Untreated sewage
• Drinking water
• Fluids containing hard components (such as stones, wood, metal, etc.)
• Fluids containing high quantities of abrasive contents (e.g. sand, gravel).
Intended use also includes compliance with this manual. Any other use is regarded as non-
compliant with intended use.
Fully submersible grinder pump for stationary and portable wet well installation in continu-
ous operation.
1 Handle/attachment point
1
2 Connection cable
3 Discharge connection
4 Macerator
2
5 Hydraulics housing
6 Seal housing
7 Motor housing
Rexa PRO-S .../M .../O
3
Sewage pump with radial macerator with double shear effect. Horizontal discharge port with
flange and oval connection. Hydraulics housing and impeller made of grey cast iron; macer-
ator made of hardened cutting steel. Surface-cooled 1~ motor with thermal motor monitor-
ing and moisture probe. Oil-filled sealing chamber with two mechanical seals. Motor housing
made of grey cast iron. Detachable connection cable with capacitor box and bare cable ends.
Unit with Ex-rating as standard.
Rexa PRO-S .../T .../O
Sewage pump with radial macerator with double shear effect. Horizontal discharge port with
flange and oval connection. Hydraulics housing and impeller made of grey cast iron; macer-
ator made of hardened cutting steel. Surface-cooled 3~ motor with thermal motor monitor-
ing and moisture probe. Oil-filled sealing chamber with two mechanical seals. Motor housing
Installation and operating instructions • Wilo-Rexa PRO-S • Ed.01/2022-03
