Assemble the Left Side Drive
You now build the left side of the drive train.
1.
To complete the first step:
Locate one Chassis Rail [R15].
Fasten two Bearing Flats [BF] to the Chassis Rail using two Bearing Rivets [BR] for each
Bearing Flat.
Fasten two 1" Beams [B1] to the Chassis Rail using using #8-32 x 1/4" screws [S2].
The completed model is as shown:
