- Page 1 Instruction Manual No. 7435-50 Multiple Measuring System Model SK-5RAD-MR 3-4, Kanda-kajicho, Chiyoda-ku, Tokyo 101-0045 Japan URL: http://www.sksato.co.jp/english/ P.12...
- Page 2 - Read this manual thoroughly before using. Keep the manual in a safe place for future references whenever necessary. Warning The SK-5RAD-MR is not explosion-proof. Never use it in an atmosphere containing flammable gases Beware of explosion! There is a risk of explosion. Take extreme care Should you have any questions, please consult with the local store where the device is purchased or with our service network.
- Page 3 select a brushless motor when placing your order. The test results under the normal temperature and humidity conditions demonstrate that the service life of brushless motors is at least 10,000 hours of continuous operation. ・ Do not operate the touch panel with a pointed object such as a pen. Doing so may scratch the screen.
- Page 4 ■ Notes on product warranty ・ If this equipment is used for the purposes other than hygrometer, the measurement accuracy cannot be guaranteed. Be sure to use this equipment only as a hygrometer. ・ If the "Offset" or "Gain" settings are changed, the equipment will no longer be covered by the warranty including measurement accuracy.
- Page 5 Features ● This equipment can be easily operated using the touch panel. ● Measurement data can be stored on an SD memory card and then data can be managed and analyzed on a PC. ● A platinum resistance temperature sensor (PRT) is adopted. This PRT is highly reliable and ensures stable accuracy for a long period of time.
- Page 6 ● Paperless recorder ① ② ④ ⑩ ③ MENU FUNC PUCH TO E JE CT ⑤ ⑥ ⑦ ⑧ ⑨ ① Handle : Used to carry the recorder by hand * Be careful not to drop the equipment when carrying or installing it.
- Page 7 Wiring 1. Connecting the sensor and the paperless recorder Remove the two hooks on the right and left sides of the protective cover, and then remove the cover from the main unit. Connect the sensor cable to the terminal block as shown in the figure and table below. Remove the screws from the terminal block first, insert the cable terminals and then remount and retighten the screws on the terminal block.
-
Page 8: Installing The Equipment
Installing the equipment ① Installing the sensor Depending on the location where measurements will be made, install and firmly secure the sensor section. For example, the sensor can be installed with the stand provided, or it can be installed on the wall by using the wall-mounting hook and wall-mounting bracket on the back of the sensor. - Page 9 ② Installing the paperless recorder Install the paperless recorder in the places as following. ・ Places free from mechanical vibrations or impact (Vibration: 10 to 60 Hz, 0.2 m/s , impact: not allowed) ・ At dust-free atmosphere ・ Places free from flammable gas, explosive gas and corrosive gas (such as SO or H ・...
-
Page 10: Starting Measurement
Starting measurement Caution ・ Before turning on the power, make sure that the AC power cord and the sensor cable have been connected correctly, the sensor section has been set up, and an SD memory card has been mounted. ・ When mounting an SD memory card, make sure that it has been inserted all the way in the correct direction. -
Page 11: Starting Recording
④ Start measurement when the readings of the dry-bulb temperature and wet-bulb temperature have become stable. Note: Once this equipment has become stable, it can detect subsequent changes of the temperature and humidity environment almost in real time. However, the equipment may be unable to respond to sudden environmental changes. - Page 12 After the recording has stopped, the SD memory card communicates with this equipment to store the data. Do not remove the SD memory card until the data has been completely saved. The memory status indicators will remain red while data is being saved, and will turn light blue when data has been completely saved.
- Page 13 ● Parameter Loader This software enables various settings for the paperless recorder to be performed on the PC. The Parameter Loader can be used to read the settings data stored on the SD memory card, or create or change settings data. ①...
- Page 14 Caution SD Memory Card ・ Normally, commercially available SD memory cards can be used without being formatted. If SD memory cards are to be formatted again, format them using this equipment. If formatted using the PC standard function, the SD memory card may not operate correctly. ・...
- Page 15 ④ FUNC button - "Change display" function is set by default- By pressing this FUNC button," Change display", "Capture", "Message", " Addition reset", and "OFF" are selectable. Note: The function assigned to the FUNC button can be changed by selecting [Device/Other] and then [FUNC key] from the System screen.
- Page 16 ⑤ Display switchover : This area is used to switch the screen display method. If this area is touched when the menu screen is displayed, the display will return to the screen displayed before the menu screen. Note: This area is displayed in gray if the settings prevent the screen display method from being selected by touching the screen.
- Page 17 Item Settings Input channels CH1 : Dry-bulb temperature (ºC) Pt100-2 CH2 : Wet-bulb temperature (ºC) Pt100-2 CH13 : Relative humidity (%RH) CH14 : Dew point temperature (ºC) Note: CH13 and CH14 are calculation channels. Group Group 1: HYGRO-STATION-MR Alarm Recording Recording interval : 1 minute (File recording: 1 day) Memory overwriting : OFF...
- Page 18 The following table shows the default settings. SD Remove Touch this button to remove the SD memory card. This button will terminate communications with the SD memory card. Language Touch this button to change the language displayed on the screen. Select either English or Japanese.
- Page 19 ③ Touch [SD/Param] in the main menu and then [Param save] in the submenu. The settings will be saved to the SD memory card. * Settings are saved in the [Prm] subfolder of the [Recorder] folder on the SD memory card. These folders are automatically created when an SD memory card is mounted on this equipment.
- Page 20 ③ Set up recording. [Record Cycle]: Set the recording interval for main recording. * "100 ms" can only be selected for sub-recording. For sub-recording, refer to the instruction manual stored on the CD-ROM. [File rec cycle]: Set the interval for recording measurements to a file. * The selectable range varies according to the specified value in [Record Cycle].
- Page 21 ⑤ Touch [Record type] and specify the type of data to be recorded. For [Channel], dry-bulb temperature is set CH01 and wet-bulb temperature is set CH02. ・Instant value : Records data at recording intervals. ・Average : Records the average value of all values measured during each recording interval. ・Max/Min : Records the maximum and minimum values of all values measured during each recording interval.
- Page 22 ⑦ Touch File format on the menu screen. ⑧ Select the desired storage format in the File format section. After the setting has been made, touch OK to save the setting. ・ Binary : This format enables recorded data to be read using the data analysis software provided.
-
Page 23: Maintenance
* The types (extensions) of files stored are as follows: ・ Main recording management file (dm) This file contains the main recording start and end times, and link information. A single file manages 50 dmt files. ・Main recording trend file (dmt) This file contains measurement data where the main recording has been split according to the recording interval. - Page 24 . Remove the water reservoir by pulling horizontally the air intake clamp, and pull down the air intake tube (lower part). Air intake tube (upper part) Old wick Air intake clamp Air intake tube (lower part) 2. Clean the dust on the sensing part (at 30 mm from the top of PT sensor) with alcohol or like. If the old wick is on, remove it.
- Page 25 3. Cut a piece of gauze large enough to fit around the bulb (100 x 25 mm), and dampen it with distilled water. Extend the gauze about 10mm from the end of the bulb, and wind the gauze around the sensing part without making wrinkles. 4.
- Page 26 ● On measuring range for continuous measurement (within 24 hours) and measuring area Part is an area where continuous measurement is possible. Part is an area where a short time measurement is possible. 50℃ ● Storage When you do not use this equipment for a long period of time, please all throw away the remaining water in a water reservoir, and keep it in the place where there is little humidity and sunlight does not hit directly.
-
Page 27: Specifications
Specifications Product name Multiple Measuring System for Temperature and Humidity with Paperless Recorder Model SK-5RAD-MR Cat. No. 7435-50 Elements Dry Bulb Wet Bulb Relative Humidity Dew Point Temperature Temperature Temperature Range Measurement 5.0 to 50.0ºC 5.0 to 50.0ºC Operation 0.0 to 99.9%rh -40 to 50.0ºC... - Page 28 WARRANTY POLICY Warranty Our products are warranted to be free from defects in materials and workmanship for a period of one year from date of delivery. If repair or adjustment is necessary and has not been the result of abuse or misuse within the one-year-period, please return the units on - Freight Prepaid –...
