Each MIB has two communication ports. The MIB-W has two twisted pair wire ports, the MIB-F
has two fiber optic cable ports and the MIB-WF has one twisted pair wire and one fiber optic cable
port.
The NAM-232 provides a physical communication interface from the AFP-200, AFP-300/AFP-
400, AM2020/AFP1010 Analog Fire Panel to the following communication media which connect
nodes together forming a network:
•
Twisted Pair Wire NAM-232W
•
Fiber Optic Cable NAM-232F
The Serial Interface Board for NOTI•FIRE•NET™ (SIB-NET) connects an AM2020/AFP1010
to the network through a MIB and permits communication between the AM2020/AFP1010 and
other nodes on the network. The SIB-NET supports all of the same functions as the SIB-2048A;
i.e. Annunciator Control System (ACS), printers, and CRTs.
Each AM2020/AFP1010 requires a network node address.
The NRT-NET interface card and the MIB allow the NRT and NCS to communicate with the
network. The NRT-NET interface card plugs directly into a computer expansion slot located on the
NRT and NCS. The MIB, which supports the physical connection to the network, plugs onto the
NRT-NET card to complete the network interface. Each NRT or NCS requires a network node
address.
The Repeaters (RPT) boost data signals between network nodes extending communication
distances. The RPT-W supports twisted pair wire, the RPT-F supports fiber optic cable, and the
RPT-WF supports twisted pair wire and fiber optic cable.
NOTI•FIRE•NET™, when properly configured, is suitable for use as a Protected Premises Fire
Alarm System as defined in the National Fire Protection Association (NFPA) 72 documentation.
To obtain a complete understanding of specific features within the network, or to become familiar
with the network functions in general, make use of the documentation listed in Table 1.
For information on...
Noti•Fire•Net Nodes
Off-line programming utility
Networking
Table 1 Network Related Documentation
firealarmresources.com
Refer to...
AM2020/AFP1010 Manual
AFP-300/400 Fire Panel Installation Manual
AFP-300/400 Fire Panel Programming Manual
AFP-300/400 Fire Panel Operations Manual
AFP-200 Analog Fire Panel Manual
Veri•Fire Tools Help File
Noti•Fire•Net 3.0 Manual Manual
NCS Network Control Station
INA Intelligent Network Annunciator Manual
NAM-232 Manual
MIB Media Interface Board Manual
RPT Repeater Manual
Service Provided
Part No.
15088
50253
50259
50260
15511
Verifire-CD
50257
51095
15092
50038
50255
50256
NOTI•FIRE•NET™ PN 50257:E 7/5/01
