- Page 1 AUTOPULSE IQ-318/E/C ANALOG ® ADDRESSABLE CONTROL SYSTEM Fire Alarm Control Panel Installation Manual (Meets the Requirements of UL 864 9th Edition) Document 52864 9/29/15 Rev: P/N 52864:J3 ECN 15-230...
- Page 2 Fire Alarm & Emergency Communication System Limitations While a life safety system may lower insurance rates, it is not a substitute for life and property insurance! An automatic fire alarm system—typically made up of of detector is necessarily best and a given type of detector smoke detectors, heat detectors, manual pull stations, audible may not provide adequate warning of a fire.
- Page 3 HARSH™ and NIS™ are trademarks; and Acclimate®, FAAST®, FlashScan®, NION®, NOTIFIER®, ONYX®, ONYXWorks®, UniNet®, VeriFire®, and VIEW® are all registered trademarks of Honeywell International Inc. AUTOPULSE™ is a trademark of Tyco Fire Products LP. Echelon® is a registered trademark and LonWorks™...
- Page 4 Software Downloads In order to supply the latest features and functionality in fire alarm and life safety technology to our customers, we make frequent upgrades to the embedded software in our products. To ensure that you are installing and programming the latest features, we strongly recommend that you download the most current version of software for each product prior to commissioning any system.
-
Page 5: Table Of Contents
Table of Contents Section 1: About This Manual....................6 1.1: Standards and Other Documents........................6 1.2: UL 864 Compliance............................7 1.3: Related Documents ............................7 1.4: Cautions and Warnings ..........................8 Section 2: System Overview ....................9 2.1: System Description ............................9 2.2: System Components ............................10 2.3: Compatible Equipment ..........................15 Section 3: Installation...................... -
Page 6: Section 1: About This Manual
Section 1: About This Manual 1.1 Standards and Other Documents This Fire Alarm Control Panel complies with the following NFPA standards: • NFPA 12 CO Extinguishing Systems • NFPA 12A Halon 1301 Extinguishing Systems • NFPA 13 Sprinkler Systems •... -
Page 7: Ul 864 Compliance
UL 864 Compliance About This Manual • C22.1-98 The Canadian Electrical Code, Part 1 1.2 UL 864 Compliance 1.2.1 Products Subject to AHJ Approval This product has been certified to comply with the requirements in the Standard for Control Units and Accessories for Fire Alarm Systems, UL 864 9th Edition. -
Page 8: Cautions And Warnings
About This Manual Cautions and Warnings Document Number System Components (Part no. if applicable) Annunciator Control System Manual 15842 ACM-8R Annunciator Control Module Manual 15342 FDU-80G Remote Annunciator Manual 52707 LCD-80 Liquid Crystal Display Annunciator 15037 LCD2-80 Liquid Crystal Display Annunciator 53242 LDM Series Lamp Driver Annunciator Manual 15885... -
Page 9: Section 2: System Overview
Section 2: System Overview 2.1 System Description The IQ-318/E control panel is a modular, intelligent fire alarm control panel (FACP) with an extensive list of powerful features. The control panel uses the CPS-24/E integral power supply with battery charger. This is mounted in its cabinet to create a complete fire alarm control system. The panel supports FlashScan®... -
Page 10: System Components
System Overview System Components 2.1.2 Options Refer to Section 2.2 “System Components” for descriptions of the various optional modules. • Optional devices include: • Optional annunciators connected through UDACT/UDACT-2 Universal Digital the EIA-485 interface allow remote Alarm Communicator/Transmitter, and system monitoring. ACM-8R remote relay module to increase point capacity. - Page 11 System Components System Overview Figure 2.1 IQ-318/E System, Shown with Door Open 2.2.3 Main Power Supply CPS-24/E The main power supply is an integral part of the IQ-318/E and mounts directly over the control panel’s circuit board. It provides a total of 3.9 A (7.4 A in alarm) and contains an integral battery charger.
- Page 12 System Overview System Components 2.2.4 Circuit Board Components The following three figures illustrate the location of the various connections, switches, jumpers and LEDs on the IQ318 and its power supply. Figure 2.2 shows wiring connections; Figure 2.3 shows jumpers, LEDs and switches. See Section 3 “Installation” for larger images and more details. (Larger images are referenced on these drawings.) Figure 2.2 IQ318 and Power-Supply: Wiring Connections IQ-318/E/C Installation Manual —...
- Page 13 System Components System Overview Figure 2.3 IQ318 and Power-Supply: Jumpers, LEDs and Switches IQ-318/E/C Installation Manual — P/N 52864:J3 9/29/15...
- Page 14 System Overview System Components 2.2.5 System Cabinet The control panel is factory installed in its backbox. The lockable door is hinged on the left and opens a full 180 degrees. Mounting methods include surface-mounting or semi-flush mounting on a wall between 16 inch (40.64 cm) on-center studs. A trim ring option is available for semi-flush mounting.
-
Page 15: Compatible Equipment
Peripheral devices in the second list were listed under UL 8th Edition and may only be used in retrofit applications (see Section 1.2, “UL 864 Compliance”, on page 7). AutoPulse and Notifier Compatible Equipment NOTE: Products marked with a checkmark “” have not received UL 864 9th Edition certification and may only be used in retrofit applications (see Section 1.2, “UL 864 Compliance”,... - Page 16 A2143-00 End of Line Resistor Assembly FSB-200, FSB-200S Beam Detectors EOLR-1 End-of-Line Resistor Assembly Retrofit Equipment: Compatible Notifier Equipment Listed Under Previous Editions of UL 864 NOTE: The products in this list have not received UL 864 9th P-40 Keltron Printer P40-KITB Dress plate for Keltron Printer...
-
Page 17: Section 3: Installation
Section 3: Installation 3.1 Preparing for Installation Choose a location for the fire alarm system that is clean, dry, and vibration-free with moderate temperature. The area should be readily accessible with sufficient room to easily install and maintain it. There should be sufficient space for cabinet door(s) to open completely. Carefully unpack the system and inspect for shipping damage. -
Page 18: Installation Checklist
Installation Installation Checklist 3.2 Installation Checklist Table 3.1 provides an installation checklist for installing, wiring, and testing the IQ-318/E system. It has references to installation information included in manuals listed in Section 1.3 “Related Documents”. Task Refer to Mount the cabinet backbox to the wall. Section 3.3 “Mounting a Cabinet”... -
Page 19: Mounting A Cabinet
Mounting a Cabinet Installation 3.3 Mounting a Cabinet This section provides instructions for mounting the IQ-318/E backbox to a wall. The IQ-318/E is assembled with a removable chassis that can be removed to provide easier access to the backbox’s mounting holes, or to allow the electronics to be worked on outside the cabinet. Follow these guidelines when mounting the backbox: •... - Page 20 Installation Installing Option Boards Remove and re-install KDM-R2 as shown in Figure 3.2. It may be convenient to do some basic field-wiring before reinstalling KDM-R2. Lay the first option board over the four stand-offs already installed on the CPU, so that the holes and stand-offs align.
-
Page 21: Connecting The Power Cables
Connecting the Power Cables Installation 3.5 Connecting the Power Cables WARNING: Remove all power sources to equipment while connecting electrical components. Leave the external, main power breaker OFF until installation of the entire system is complete. WARNING: Several sources of power can be connected to the control panel. Before servicing the control panel, disconnect all sources of input power including the battery. - Page 22 Installation Connecting the Power Cables Component Status Control panel The green AC Power indicator on; the system Trouble indicator on because batteries are not connected. circuit board Each option board In an unconfigured system, the yellow Trouble indicator may come on for approximately 10 seconds after applying AC power.
- Page 23 Connecting the Power Cables Installation 24 VDC Resettable Power Circuit (Four-Wire Smoke Detectors). The power supply provides a single 24 VDC filtered, power-limited, resettable power circuit for devices that require resettable power (such as four-wire smoke detectors). This circuit is power-limited, but must be supervised.
-
Page 24: Nac Connections And Releasing Circuits
Installation NAC Connections and Releasing Circuits 3.6 NAC Connections and Releasing Circuits The control panel provides four NAC terminals as shown in Figure 3.9. Each can be configured as Style Y (Class B) or Style Z (Class A) as shown in Figure 3.8. Each circuit can provide 1.5 A of current, but the total current drawn from the main power supply cannot exceed 7.4 A in alarm condition (refer to Table 6.2). -
Page 25: Output Relay Connections
Output Relay Connections Installation 3.6.1 Stat-X Devices Figure 3.10 shows typical wiring for STAT-X devices using the Ematch Protection Device (P/N 3005014). Note the following: • Each Stat-X device requires an Ematch Protection Device to Releasing Circuit protect against high-voltage transient signals, such as lightning, that may cause the device to Green... -
Page 26: Backup-Alarm Switches
Installation Backup-Alarm Switches 3.8 Backup-Alarm Switches WARNING: Do not enable the BACKUP option switch for any of the four Notification Appliance Circuits (NACs) if they are used for releasing functions! Backup alarm switches are provided that enable NACs and the alarm relay to activate during a backup alarm condition. -
Page 27: Ul Power-Limited Wiring Requirements
UL Power-limited Wiring Requirements Installation 3.9 UL Power-limited Wiring Requirements Power-limited and nonpower-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25 inches (6.35 mm) from any nonpower- limited circuit wiring. All power-limited and nonpower-limited circuit wiring must enter and exit the cabinet through different knockout and or conduits. -
Page 28: Installing Eia-485 Devices
Installation Installing EIA-485 Devices NOTE: In order to meet UL wiring requirements, please install grounding straps as shown below. 3.9.1 Labeling Modules and Circuits At the time of installation, each nonpower-limited circuit connected to ACM-8R, and LDM-R32 modules must be identified in the space provided on the cabinet door label when connected to a non-power-limited source of power. - Page 29 Installing Remote Printers and/or CRT Installation Tighten clamp on connector to secure cable. DB-9 Connector DB-25 Connector TB12 on Control Panel Pin 2 Pin 3 Pin 3 Pin 2 Pin 5 Pin 7 3.11.2 Installing and Configuring the PRN Series Printer When connected to the Control Panel via an EIA-232 interface, the PRN prints a copy of all status changes within the control panel and time-stamps the printout with the time of day and date the event occurred.
- Page 30 Installation Installing Remote Printers and/or CRT DB-9 Connector on PRN series Printer DB-25 connector on PRN series printer (female socket shown) Terminate one end of shield at backbox Control Panel NOTE: Outputs are power-limited but are not supervised Figure 3.15 Remote Printer Connections Setting Printer Options Refer to the documentation supplied with the PRN series printer for instructions on using the printer menu controls.
- Page 31 Installing Remote Printers and/or CRT Installation DB-25 connector on CRT-2 (female socket shown) Terminate one end of shield at backbox Control Panel Figure 3.16 Connecting a CRT-2 Setting CRT-2 Parameters The CRT-2 communicates with the control panel through a protocol defined by thirteen groups of parameters.
- Page 32 Installation Installing Remote Printers and/or CRT Function Key CRT-2 Parameters F1: Quick Emulation=CRT-2 EIA Baud Rate=9600 EIA Data Format=8/1/N (“Read Status” key) Comm Mode=Full Duplex Aux Baud Rate=9600 Aux Data Format=8/1/N Enhanced=On Language=U.S. Host/Printer=EIA/Aux F2:Genrl Emulation=CRT-2 Enhanced=On Auto Wrap=Off (“Alter Status” key) Auto Font Load=On Auto Page=Off Auto Scroll=On...
-
Page 33: Wiring A Signaling Line Circuit (Slc)
Wiring a Signaling Line Circuit (SLC) Installation Connect multiple devices as shown in Figure 3.17. To Control Panel TB12-PC/CRT REF TB12-PC/CRT TX TB12- PC/CRT RX To AUX Port of CRT-2 To EIA-232 port of CRT-2 (female socket shown) (female socket shown) To EIA-232 port of next CRT-2 or PRN (female socket shown) Note: For wire requirements, see Table 7.1 in Appendix 7 “Electrical Specifications”. -
Page 34: Connecting A Pc For Off-Line Programming
Installation Connecting a PC for Off-Line Programming SLC B SLC A SLC B (output loop) SLC A (loop return) SLC Loop Connections on FACP’s main circuit board TB13 on IQ-318/E Style 4 SLC Loops Style 6 SLC Loops Note: T-Tapping is not allowed on a four-wire SLC. Figure 3.18 SLC Loop Connections and Wiring 3.13 Connecting a PC for Off-Line Programming A PC can be hooked up to the control panel to allow the VeriFire Tools programming utility to... -
Page 35: Section 4: Applications
Section 4: Applications 4.1 Overview Chapter Covers the following topics Section 4.3 “NFPA 72 Central or How to install UDACT/UDACT-2 with the control panel for use as a Remote Station Fire Alarm System NFPA Central or Remote Station Fire Alarm System (Protected (Protected Premises Unit)”... -
Page 36: Nfpa 72 Central Or Remote Station Fire Alarm System (Protected Premises Unit)
Applications NFPA 72 Central or Remote Station Fire Alarm System (Protected Premises Unit) Power Supervision Relay (EOLR-1) (Not required for FlashScan type codes SLC from FACP that provide built-in power supervision.) – Non-resettable 24 – VDC Power from a listed source Device to be Supervised *If the SLC device does... - Page 37 NFPA 72 Central or Remote Station Fire Alarm System (Protected Premises Unit) Applications Ferrite cores P/N 29090 FACP Cabinet Solid earth To supervised ground phone lines EIA-485 24 VDC (ACS Mode) Nonresettable power Supervised and power-limited EIA-485 and power wiring UDACT in ABS-8RB (shown with cover removed) Figure 4.2 Typical Wiring Diagram for a Central Station Fire Alarm System...
-
Page 38: Central Station Fire Alarm System Canadian Requirements
Applications Central Station Fire Alarm System Canadian Requirements 4.4 Central Station Fire Alarm System Canadian Requirements For Canadian applications requiring a second dial-out option, refer to the following illustration for UDACT/UDACT-2 and TM-4 setup: NOTES: • Drawing is not to scale. EIA-485 •... -
Page 39: Fire/Security Applications
Fire/Security Applications Applications Telephone line and backup UDACT or UDACT-2 Compatible Receiving Unit IQ-318/E (see UDACT Manual or UDACT-2 Manual) IQ-318/E Protected Premises Unit Figure 4.4 Typical Proprietary Fire Alarm Systems Wiring Connections 4.6 Fire/Security Applications 4.6.1 General Operation The control panel can be used as a combination Fire/Security system when installed and operated according to the instructions in this section. - Page 40 Applications Fire/Security Applications STS-200 mounting location Connect to J5 “Security Tamper” Figure 4.5 Installing the STS-200 Security Tamper Switch 4.6.3 Receiving Unit For applications requiring transmission of security alarm information to a central receiving unit, the control panel may be connected via the UDACT or UDACT-2 to a compatible receiving unit (see the UDACT Manual or UDACT-2 Manual).
-
Page 41: Releasing Applications
Releasing Applications Applications IQ-318/E Protected Premises Unit Channel UL-listed, UL-listed 47K A or B normally-open End-of-Line Resistor security switch (provided with module) *If the SLC device does not match the one in this figure, refer to the SLC manual appendix, which UL-listed, normally-closed contains wiring conversion security switch... - Page 42 Applications Releasing Applications 4.7.2 Programming The control panel supports up to ten releasing software zones. You can map these zones to activate Control Panel releasing outputs and FCM-1 modules. Program the FCM-1 module for the appropriate type code according to the chart below: Type Code: RELEASE CKT Type Code: REL CKT ULC •...
- Page 43 Releasing Applications Applications Circuit Requirements. When connecting a releasing device, note the following: The control panel provides four NAC/Releasing Circuits (Style Y or Z). Each circuit can provide 1.5 A. Total current drawn from the power supply cannot exceed 7.4 A in an alarm condition (refer to Table 6.2, “System Draw Current Calculations,”...
- Page 44 Applications Releasing Applications Figure 4.10 Releasing Circuits (Option 3) Figure 4.11 Release Circuits (Mechanical Disconnect Switch) 4.7.5 Connecting a Releasing Device to the FCM-1 Module The module can control 1 A of current. Make sure to keep total system current within the limits of the power supply.
- Page 45 Releasing Applications Applications For applications using power-limited circuits: a) Use an in-line supervisory device (P/N REL-47K) with the FCM-1 module. Connect the in- line supervisory device as shown in Figure 4.12. b) Program the releasing circuit for Type Code REL CKT ULC. c) Circuits are supervised against opens and shorts.
- Page 46 Applications Releasing Applications 4.7.6 Connecting a Releasing Device to the FCM-1-REL Typical Connections Figure 4.13 shows typical connections for wiring a releasing device to the FCM-1-REL. Refer to the Device Compatibility Document for compatible releasing devices. Non-resettable 24 VDC power SLC (-) Module polarities are shown in alarm condition.
- Page 47 Releasing Applications Applications Do not loop wiring under the screw terminals. Break the wire run to provide supervision of connections. All applications using the FCM-1-REL are power-limited: Program the releasing circuit for Type Code REL CKT ULC or RELEASE CKT. Circuits are supervised against opens and shorts.
-
Page 48: Section 5: Testing The System
Section 5: Testing the System 5.1 Acceptance Test When finished with the original installation and all modifications, conduct a complete operational test on the entire installation to verify compliance with applicable NFPA standards. Testing should be conducted by a factory-trained fire alarm technician in the presence of a representative of the Authority Having Jurisdiction and the owner’s representative. -
Page 49: Battery Checks And Maintenance
Battery Checks and Maintenance Testing the System NOTE: The battery test requires fully charged batteries. If batteries are new or discharged due to a recent power outage, allow the batteries to charge for 48 hours before testing. • Return all circuits to their pretest condition. •... -
Page 50: Calculating Ac Branch Circuit Current
Appendix 6: Power Supply Calculations Calculations must be done to determine standby and alarm DC current loads. Ampere-hour requirements must be calculated as well to determine battery size. The CPS-24/E power supply provides filtered 24VDC power that may be used for operating external devices. - Page 51 Calculating the System Current Draws Power Supply Calculations How to Use the Calculating Tables As used in this section, “Primary” refers to the control panel’s on-board power supply, its primary source of AC power. “Secondary” refers to the control panel’s backup batteries (or any other 24 VDC power supply listed for Fire Protective Signaling and connected in place of the batteries).
- Page 52 Power Supply Calculations Calculating the System Current Draws Calculation Column 1 Calculation Column 2 Calculation Column 3 Category Primary, Non-Fire Alarm Primary, Fire Alarm Secondary, Non-Fire Alarm Current (amps) Current (amps) Current (amps) X [current draw]= Total X [current draw]= Total X [current draw]= Total...
- Page 53 Calculating the System Current Draws Power Supply Calculations 6.2.1 Calculating the Maximum Secondary Power Fire Alarm Current Draw Use Table 6.3 below to determine the maximum current requirements of secondary power source during fire alarm conditions. The result obtained is the amount of current that the batteries must be able to supply to the fire alarm system.
-
Page 54: Calculating The Battery Requirements
Power Supply Calculations Calculating the Battery Requirements 6.3 Calculating the Battery Requirements 6.3.1 Calculating the Battery Capacity Use this table to determine the battery capacity needed for the system: Current (amps) Time (hours) Secondary Non-Fire Alarm Current Required Secondary Non-Fire Alarm (from column 3 in Table 6.2) Standby Time (24 or 60 hours) (see Note 8) - Page 55 Calculating the Battery Requirements Power Supply Calculations 6.3.2 Calculating the Battery Size Use this table to choose the battery size, in amp-hours, needed to support the fire alarm system. The CPS-24/E can charge batteries from 18 to 200 AH. Select batteries that meet or exceed the Total Amp-Hours calculated in Table 6.4 and that are within the acceptable battery charger range.
-
Page 56: Electrical Specifications
Appendix 7: Electrical Specifications 7.1 Electrical Specifications AC Power Component Values Main Power Supply 120 VAC, 50/60 Hz, 5.0 A; or 220-240 VAC, 50/60 Hz, 2.5 A Wire size Maximum 12 AWG (3.31 mm ) with 600 VAC insulation NOTE: If using an auxiliary power supply such as FCPS-24S6/S8 or APS-6R, refer to the documentation for that equipment. - Page 57 Electrical Specifications Electrical Specifications Notification Appliance Circuits and Releasing Circuits Item Value Max. wiring voltage drop 2 VDC (Retrofit note: SLCs with old CMX modules are restricted to 1.2 VDC.) NAC Nominal operating 24 VDC regulated; 1.5 A max. voltage Special Applications for 20.16 - 26.42 VDC Releasing Circuits...
-
Page 58: Wire Requirements
Electrical Specifications Wire Requirements Operating Power: AC Branch Circuit The control panel requires connection to a separate dedicated AC branch circuit. Follow these guidelines when connecting the AC branch circuit: • Label the branch circuit “Fire Alarm”. This must be a separate dedicated AC fire alarm circuit. •... - Page 59 Wire Requirements Electrical Specifications Circuit Distance Circuit Type Wire Requirements Typical Wire Type Function (feet/meters) Connects to Twisted-unshielded pair, 12 to 18 AWG 12,500 ft. (3,810 m) 12 AWG (3.31 mm (power limited) intelligent and (3.31 to 0.82 mm ). 50 ohms maximum per 9,500 ft.
-
Page 60: Index
Index Numerics 24 VDC, see Power (DC) FCM-1, also see Releasing Applications Circuit Requirements 44 FCM-1-REL, also see Releasing Applications 46 Connections 46 A77-716B, see Power Supervision Relay – Fire/Security Applications 39 (Replaced by EOLR-1) Form-C relays 25 AC, see Power 21 Four-wire Smoke Detector Acceptance Test 48 Specifications 57... - Page 61 Index O–W UL wiring requirements 27 Security Tamper Switch 39 Notification Appliance Circuits, see NACs Service 48 Device Capacity 33 Installation 33 Operating Power 58 Maximum Wiring Distance 33 Operational Checks 48 specifications 56 Option boards SLC See also SLC Wiring Manual 33 Installation steps 19 Specifications 56 Output relays...
- Page 62 TYCO SAFETY PRODUCTS ONE STANTON STREET MARINETTE, WI 54143-2542 715-735-7411 TYCO SAFETY PRODUCTS ONE STANTON STREET MARINETTE, WI 54143-2542 715-735-7411...
