- Page 1 Four lan ports 2 in 1 video controller Version: v2.3 Release Date: November 2021 Manual...
- Page 2 Version record version Change details release time number V1.0 first release 2018.12.12 V2.0 Modify device interface information 2019.11.28 V2.1 Modify the format of the text 2020.12.09 V2.2 change cover 2021.10.25 V2.3 Correct size data, modify function description 2021.11.18...
- Page 3 Safety precautions Danger ● There is high voltage in the equipment. Non-professional maintenance personnel should not open the back cover to avoid danger. Warning ● This equipment is not waterproof equipment, please do waterproof treatment in wet environment; ● This device is not allowed to get close to fire or high temperature environment; ●...
-
Page 4: Table Of Contents
catalog I、 Product discussion..........................1 Ⅱ、 Product characteristics........................2 III 、 Technical indicators......................... 3 IV、Working sketch ..........................4 V、Panel Structure ..........................5 Front panel................................5 Back panel................................6 VI、Wiring and installation ......................7 Wiring diagram..............................7 VII、Equipment commissioning ....................8 Navigation mode..............................8 VIII 、Control menu ........................... -
Page 5: I、Product Discussion
LS4 manual www.kystar.com.cn I、Product discussion With the rapid development and application demand of LED display industry, various control requirements for large screen control system emerge as the times require. However, due to the limitations of the large screen control system in image processing, picture control and signal format conversion, there are some weak links in the large screen control system of LED, which can not meet the needs of users. -
Page 6: Ⅱ、Product Characteristics
LS4 manual www.kystar.com.cn Ⅱ、Product characteristics Professional Video Processor: HD Multi Format Signal input Transient or fading transitions between arbitrary signals Arbitrary free Zoom Display Integrated LED sending card： 4 pcs network port output, the output max width 3840, the max high 1080 Loading 2.36 million pixels... -
Page 7: Technical Indicators
LS4 manual www.kystar.com.cn III、Technical indicators The video processor adopts the latest patented video processing technology, and has the video conversion capability of any format input and corresponding format output. Video signals including CVBS (composite video), HDMI, VGA (RGB) and DVI-D can be processed and enhanced to meet customer application needs. -
Page 8: Working Sketch
LS4 manual www.kystar.com.cn IV、Working sketch LED screen Video processor Desktop computer laptop camera... -
Page 9: Panel Structure
LS4 manual www.kystar.com.cn V、Panel Structure Front panel ⑴ ⑵ ⑶ ⑷ ⑸ ⑹ ⑺ ⑻ ⑼ ⑽ ⑾ ⑿ ⒀ ⒁ ⒂ ⒃ ⒄ ⑴ POWER-----------------------------Device switch, OFF - power off, ON - power on ⑵ LCD----------------------------------Text display, displaying menus, parameters, etc. -
Page 10: Back Panel
LS4 manual www.kystar.com.cn Back panel ⑴ ⑵ ⑶ ⑷ ⑸ ⑹⑺ ⑻ ⑼⑽ ⑾ ⑿ ⑴ UART -------------------------------------Connect the host computer software through the 9-pin serial port to the RJ45 network port ⑵ USB-CFG ---------------Connect the host computer software through the USB port ⑶... -
Page 11: Wiring And Installation
LS4 manual www.kystar.com.cn VI、Wiring and installation Wiring diagram 电源线 Lan cable Signal source Output port USB control cable LED 屏 installation steps 1 、 Connect the DVI interface of the graphics card to the DVI-IN input port of the video processor as shown in the figure. -
Page 12: Equipment Commissioning
LS4 manual www.kystar.com.cn VII、Equipment commissioning Navigation mode This Wizard is suitable for most cases. It is simple to set up. With the prompt, you can gradually debug it to achieve the desired display effect. The processor automatically enters the navigation mode when it is powered up.(or Click Enter Navigation Mode）：... - Page 13 LS4 manual www.kystar.com.cn Select whether to import the box file: Note: The box files need to be imported into the equipment through the upper computer software. The box files here refer to the parameters of the receiving card. Set the number of cabinet rows/columns: Note: Number of rows/columns in the box refers to the number of horizontal/vertical receiving cards used in the large screen.
- Page 14 LS4 manual www.kystar.com.cn Set the cabinet splicing method: Note: The cabinet splicing method refers to the splicing method between the two network cables of the device. Set the cabinet connection method: Note: Cabinet routing mode: Series mode between receiving cards should ensure that the direction of the two cable is the same.
- Page 15 LS4 manual www.kystar.com.cn Set screen pixels. Note: Set screen pixels, the screen pixels is the resolution of the whole screen. Save settings: Note: Some parameters of the control system are saved here. Select the input source: Note: Select the input signal source...
- Page 16 LS4 manual www.kystar.com.cn Note: This interface is to select whether it is necessary to intercept part of the image of the input signal source and display it on the LED screen. Ps-The most common way to do "partial display" is to display the full screen of the playback window and switch to the panoramic display of the computer desktop at any time.
- Page 17 LS4 manual www.kystar.com.cn Save mode settings: End of navigation: The last step is to save the settings, in which mode one is automatically invoked after booting. At this point, the setup of the processor is completed. In the process of using it, the signal can be switched directly with the front panel.
-
Page 18: Control Menu
LS4 manual www.kystar.com.cn VIII、Control menu Main menu Option Defaults （1）screen Navigation mode Horizontal position Vertical position （2）scaler parameters Horizontal size 1920 Vertical size 1080 Horizontal position Vertical position （3）part Horizontal size Vertical size Mode 1 Mode 2 （4）Save mode Mode 3... - Page 19 LS4 manual www.kystar.com.cn English （1）Language Settings English Chinese confirm （2）factory cancel Please contact the sales staff. （3）support 400-159-0808 Enable （4）Scheduled Tasks Disable Enable （6）MORE （5）effect Disable Horizontal position default Vertical position default （6）VGA adjust Horizontal size default Vertical size default Contrast （7）contrast...
- Page 20 LS4 manual www.kystar.com.cn Freeze （8）Freeze Active Brightness （9）Brightness Green Blue Enable （1）Load hotkey Disable Enable （2）Key locked Disable Video （3）Play Type Picture （10）Master Enable （4）Resume Disable （5）Online load （6）Information （7）Sharpness Mute （8）Voice Volume Select source （9）resend config （10）read config （11）EDID Among them, the functions of the first four options have been introduced before, and I will not repeat them here.
-
Page 21: 1）、Language
LS4 manual www.kystar.com.cn Advance ★ （１）Language ★ （２）Factory （３）Support （４）Schedule （５）Effect （1）、Language The language mode of the video processor is Chinese by default, and users can switch between Chinese and English through the language setting menu in the advanced menu. -
Page 22: 8）、Freeze
LS4 manual www.kystar.com.cn The video processor is equipped with a contrast setting function, which can directly control the contrast of the LED large screen, see the control menu table for details. （8）、Freeze This function is divided into two types: image activity and image still, which is equivalent to the start and pause functions of the player. - Page 23 LS4 manual www.kystar.com.cn IX、frequently asked questions Q1：DVI、HDMI、VGA、CV、USB port definition。 A： DVI： Digital (HD) video signal is an interface standard introduced by DDWG (Digital Display Working Group) in 1999 by Silicon Image, Intel and other companies. It has been well optimized in speed, clarity and HDCP protocol. Signal sources are typically desktop computers, notebooks, etc.
- Page 24 LS4 manual www.kystar.com.cn A:Menu - Advanced Menu - Expert Settings - Keyboard Lock. Keyboard can be locked after opening. Keyboard can be unlocked even by pressing MENU key 10 times. Q4：What is the password to enter the screen navigation? “168”“666”“888”“999”Any one is OK.
-
Page 25: Method Of Importing Box Files
LS4 manual www.kystar.com.cn X、Method of Importing Box Files 1. Save cabinet files Expert screen adjustment interface has the option of saving box files: 2、new cabinet file Select the video processing option of the main menu of the software, and select the list of new... - Page 26 LS4 manual www.kystar.com.cn Select Add in the pop-up window, add the required box file to the list, and then save it as a blst file:...
- Page 27 LS4 manual www.kystar.com.cn 3、import cabinet file list Select Add in the pop-up window, add the required box file to the list, and then save it as a blst file:...
- Page 28 LS4 manual www.kystar.com.cn Select the saved blst file to import to the device After the software prompts that the data is successfully written, it can be debugged by the video processor. When the processor selects the box file, the imported file file will be displayed on the LCD screen.
