- Page 1 KLS12 Twelve ports 2-in-1 video controller version：v1.1 Release Date: October 2021 Manual...
- Page 2 Version record version number Change details release time V1.0 first release 2021.08.02 V1.1 Modify the cover 2021.10.25...
- Page 3 Safety precautions Danger ● There is high voltage in the equipment. Non-professional maintenance personnel should not open the back cover to avoid danger. Warning ● This equipment is not waterproof equipment, please do waterproof treatment in wet environment; ● This device is not allowed to get close to fire or high temperature environment; ●...
-
Page 4: Table Of Contents
Catalog I、 PRODUCT DISCUSSION....................... 1 Ⅱ、PRODUCT CHARACTERISTICS....................2 III、TECHNICAL INDICATORS......................3 V、PANEL STRUCTURE........................5 ............................5 RONT PANEL ............................6 ACK PANEL VI、WIRING AND INSTALLATION....................7 ..........................7 IRING DIAGRAM ..........................7 NSTALLATION STEP VII、EQUIPMENT COMMISSIONING..................... 8 ..........................8 AVIGATION MODE ............................10 XPERT MODE VIII、FUNCTION INTRODUCTION....................14 .............................14... -
Page 5: I、Product Discussion
KLS8Pro manual www.kystar.com.cn I、Product discussion With the rapid development and application demand of LED display industry, various control requirements for large screen control system emerge as the times require. However, due to the limitations of the large screen control system in image processing, picture control and signal format conversion, there are some weak links in the large screen control system of LED, which can not meet the needs of users. -
Page 6: Ⅱ、Product Characteristics
KLS12 manual www.kystar.com.cn Ⅱ、Product characteristics Single machine has 12 network ports, a single network port can load 650,000 pixels, and the whole machine can load a maximum of 7.8 million pixels, the width can reach 12,000 points, and the height can reach 4,000 points. -
Page 7: Technical Indicators
KLS12 manual www.kystar.com.cn III、Technical indicators The video processor adopts the latest patented video processing technology, and has the video conversion capability of any format input and corresponding format output. Video signals including DVI, HDMI, DP, etc. can be processed and enhanced to meet customer application requirements. - Page 8 KLS12 manual www.kystar.com.cn IV、Working sketch LED screen Desktop computer laptop camera...
-
Page 9: Panel Structure
KLS12 manual www.kystar.com.cn V、Panel Structure Front panel ① ② ③ ④⑤ ⑥⑦ ⑧ ⑨⑩ ⑪ ⑫ ⑬ 1、POWER：AC 220V power switch; ON state means the power is on, OFF state means the power is off. 2 、 LCD screen ： Information display; displays information about the device and commissioning. -
Page 10: Back Panel
KLS12 manual www.kystar.com.cn mode button, and the parameter input interface indicates，Numbers 6-0 and clear key. Back panel ⑩ ⑪ ⑫ ⑬ ⑭ ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ 1、 COM -----------------Connect to the host computer software through the COM port 2、... -
Page 11: Wiring And Installation
KLS12 manual www.kystar.com.cn VI、Wiring and installation Wiring diagram Power cable Lan cable Monitor LED screen USB control cable Signal source Installation step 1、Wiring as shown in the picture, connect the DVI port of the graphics card to the DVI-IN input port of the 2-in-1 controller;... -
Page 12: Equipment Commissioning
KLS12 manual www.kystar.com.cn VII、Equipment commissioning Navigation mode This Wizard is suitable for most cases. It is simple to set up. With the prompt, you can gradually debug it to achieve the desired display effect. The processor automatically enters the navigation mode when it is powered up.(or Click Enter Navigation Mode）：... - Page 13 KLS12 manual www.kystar.com.cn Select window layout (Layout1/Layout2/Layout3/Layout4) Select the win signal source, and use the knob to select the signal source input Set window parameters...
-
Page 14: Expert Mode
KLS12 manual www.kystar.com.cn Save mode, mode 1 - mode 32 Expert mode Step 1: Click "MENU" to enter the main menu interface, no need to set in "Device Mode", the default horizontal splicing Step 2: Set the screen parameters, the horizontal size and vertical size in the screen parameters are... - Page 15 KLS12 manual www.kystar.com.cn Note: There are two ways to enter numbers: （1）Adjust by rotating the knob, and adjust the step size by "×1", "×10" and "×100", for example, "×100" means that the number increases by 100 each time the knob is rotated.
- Page 16 KLS12 manual www.kystar.com.cn Step 5: Click "MENU" to return to the main menu interface, enter Menu - More - Common Functions - Partial Display, enter the part display setting interface, and set the size and position of the partial interception of each signal source.
- Page 17 KLS12 manual www.kystar.com.cn Note: Mode 1 is the data that is started by default when the device is powered on. It is recommended that the most commonly used or the mode that needs to be displayed when booting is saved to Mode 1.
-
Page 18: Function Introduction
KLS12 manual www.kystar.com.cn VIII、function introduction Key Function INFO: Information query button, click this button to enter the input information query interface, showing whether the input of each signal source is normal, the interface is as follows, red means the signal is lost, green means the signal is normal. -
Page 19: Common Functions
KLS12 manual www.kystar.com.cn OUT: Output status button, click this button to enter the output status interface, there are three output options: black screen, blue screen, normal. Selecting black screen means that all output ports will output black image, and the large screen will turn black; if selecting blue screen, all output ports will output blue image, and the large screen will turn blue;... - Page 20 KLS12 manual www.kystar.com.cn and set the four parameters of the horizontal position, vertical position, horizontal size, and vertical size of the local interception for the specified position interception. The default data is 0, which means no local interception is performed.
-
Page 21: Advanced Menu
KLS12 manual www.kystar.com.cn 13、K-HDR The K-HDR function is Kstar's SDR to HDR image optimization technology, which can improve the contrast of ordinary SDR videos, enhance the performance of image details, and make ordinary videos have HDR effects. Set the K-HDR function parameters of DP or HDMI, including function switch, function level, effective area switch, effective area parameters, presentation mode. -
Page 22: Software Debug
KLS12 manual www.kystar.com.cn IX、software debug Open the software to enter the expert debugging interface, set the parameters of the sending card, the receiving card parameters, and the screen connection. 1、software connect Use USB serial cable to connect, after opening the software, the software interface recognizes that the model of the sending card is KLS8Pro, and the number of receiving cards detected is the actual number of on-site loads 2、expert debug... -
Page 23: 3、Receiving Card Parameter Settings
KLS12 manual www.kystar.com.cn 3、Receiving card parameter settings Module select： select the module manufacturer: select the corresponding module manufacturer; the specifications of the main modules, the driver chip and the decoding method should be consistent Intelligent setting: According to the width and height of the module, the driver chip and the... -
Page 24: 4、Screen Connection
KLS12 manual www.kystar.com.cn 4、Screen connection Single card setting: set the receiving card load size Network port selection: select the paired network port settings Connection method (horizontal/vertical): the connection between the receiving cards Setting ： According to the flickering of the large screen, click the corresponding area to intelligently identify the serial connection method of the network port and network cable. -
Page 25: Faq
KLS12 manual www.kystar.com.cn X、FAQ Q1：DVI, HDMI port definition. A： DVI： Digital (HD) video signal is an interface standard introduced by DDWG (Digital Display Working Group) in 1999 by Silicon Image, Intel and other companies. It has been well optimized in speed, clarity and HDCP protocol. Signal sources are typically desktop computers, notebooks, etc. - Page 26 KLS12 manual www.kystar.com.cn ③ The serial port cable is not well connected or the cable is damaged; Q5：The large screen of the video card directly connected with the sending card is displayed normally, and the screen will appear black screen when it is connected to the video processor.
