- Page 1 KLS24 24 lan ports two-in-one video controller Version: v1.1 release date: November 2021 Manual...
- Page 2 Version record· Version Change details release time V1.0 first release 2021.10.25 V1.1 Correct size data 2021.11.18...
- Page 3 Security Considerations Critical Insurance ● The equipment has high voltage, not professional maintenance personnel should not open the back cover, in order to avoid danger. Notice ● This equipment is not waterproof equipment, in humid environment, please do water treatment; ●...
-
Page 4: Table Of Contents
Catalog PREFACE: EQUIPMENT DEBUGGING PROCESS ................1 ......................1 1、 VIDEO PROCESSOR SETTING ......................3 2、 CONTROL SYSTEM SETTING 1、PRODUCT DISCUSSION ......................6 2、FEATURES ............................7 3、TECHNICAL PARAMETER ......................8 4、WORKING DIAGRAM ........................9 5、PANEL STRUCTURE ........................10 ......................... 11 ABLE CONNECTION DIAGRAM ........................ -
Page 5: Preface: Equipment Debugging Process
1、video processor setting 1、IP address：change PC IP and KSV24 on the same network segment。 KLS24 default IP address：192.168.0.100。 2、 software connect： open PC software to debug （kystar software） ， connect device， select Ethernet to connect. - Page 6 KLS24manual www.kystar.com.cn 3 、 screen configuration setting ： click“setting”“screen configuration ， Change the loading of each output port and the arrangement of the output ports according to the actual output. 4、 open window： Click on the upper left corner to open a new screen or hold down the left mouse button and drag in the operation area.
-
Page 7: 2、Control System Setting
2、control system setting 1、open kystar control system of “kystar”software，click“kystar control system software” enter control card debug interface， first time debug KLS24， click “666888” in keyboard after open software，select network cable direct connection mode，select “directly connected to sending device”. 2 、 On the receiving card interface, add module configuration information through... - Page 8 KLS24manual www.kystar.com.cn "module selection" or "settings", and then fill in the content of the single-card loading area according to the receiving card loading situation. If there is a previously saved configuration file, it can also be loaded on this interface and sent to the receiving card parameters.
- Page 9 KLS24manual www.kystar.com.cn 4、Finally, after confirming that the screen is displayed normally, click "Solid All" to complete all debugging operations of KLS24.
-
Page 10: 1、Product Discussion
KLS24 is a control processor designed for live performance LED large screen. Adopt the industry's top design technology, in line with international and industry standards. Pure hardware FPGA design architecture, all boards of the product adopt modular design, and input boards can be freely selected. -
Page 11: 2、Features
KLS24manual www.kystar.com.cn 2、Features Pure hardware FPGA architecture: no CPU, no core, no poisoning and crash risk, and the system runs stably. Mean time to failure MTBF>30,000 hours, support 365 × 24 hours of continuous operation. A single network port can carry 650,000 pixels, and the whole machine can carry a maximum of 13.8 million ... -
Page 12: 3、Technical Parameter
KLS24manual www.kystar.com.cn 3、Technical parameter The video processor adopts the latest patented video processing technology, and has the video conversion capability of any format input and corresponding format output. Video signals including DVI, HDMI, DP, etc. can be processed and enhanced to meet customer application requirements. -
Page 13: 4、Working Diagram
KLS24manual www.kystar.com.cn 4、Working diagram... -
Page 14: 5、Panel Structure
KLS24manual www.kystar.com.cn 5、panel structure ① ② ③ ④ 1. Input board card：4K@60Hz module，support DP1.2，HDMI2.0 input，max support resolution 4096×2160@60Hz or 7680×1080@60Hz. 2. Output board card ：24 pcs lan cable out. 3. Control board: including power switch, COM port, network port, USB. -
Page 15: Cable Connection Diagram
LAN control port of the device through the network cable, and connect the output network port of the KLS24 controller to the receiving card; 3 、 Make sure that the wiring is correct and then power on and open the gold card debugging software. -
Page 16: 7、Video Processor Software Debugging Instructions
KLS24manual www.kystar.com.cn 7、video processor software debugging instructions 7.1 open software Double-click the software shortcut on the desktop, open the software, and go to the software start-up page. As shown in the following illustration: The first use of no password direct click to determine, if you set the user password requires the correct password to enter the software control / settings. -
Page 17: Software Connection
KLS24manual www.kystar.com.cn 7.2 Software connection ， Click Device Selection, select Video wall , and then click Connecting Devices , Pop-up Communication Settings window, as shown in the following illustration: The software can choose NET or COM two ways to connect, choose a different connection way to prepare for different. -
Page 18: Select Com Connect
KLS24manual www.kystar.com.cn Note: Device IP address defaults to 0 network segment, other device's IP the guarantees that the same field and different numbers are available for normal communication. To change The network segment of IP, you need to change the software settings now. -
Page 19: Out Port Settings
KLS24manual www.kystar.com.cn In General, the software automatically recognizes COM port, users do not need to set, click to confirm. However, in some cases the PC machine may have more than one com port at work, causing software recognition errors, at this point you need to select com Port (Please try it in turn). - Page 20 KLS24manual www.kystar.com.cn Screen Resolution The maximum resolution that the can output for each outlet, typically greater than the resolution of each card or display. Row and Columns set on your own, above the layout diagram 1920 and the on the left 1080 the can be modified according to the actual number of load points, double-click the value to modify.
-
Page 21: Open Window
KLS24manual www.kystar.com.cn P： Sync all screen brightness The check mark indicates that the color value of the modified rear is for all outlets, and removing the checkmark can be used to adjust the color for a single outlet. Set up a good outlet layout and load points after the click to determine, return to the operating area. - Page 22 KLS24manual www.kystar.com.cn The top bar of the window has both gray and blue display, when the window is blue to indicate that the window is selected, you can do a direct operation, when the window is gray to indicate that the window is unchecked, if you want to operate the window, you need to left-click the top bar of the window, the top bar becomes blue to set the window.
- Page 23 KLS24manual www.kystar.com.cn Click Properties Visible: Property settings mainly include the following three items: Signal source Selection, screen parameters, local display. Signal source selection is for the current window to select the desired signal source, you can also directly click on the left of the signal source bar signal Source to switch.
-
Page 24: Mode Save And Call
KLS24manual www.kystar.com.cn 7.mode save and call 7.5.1 Mode save Click Save Mode in the main ribbon to eject the Save Mode Settings window, as shown in the following image: You can change the pattern as needed ID , that is, to save to the first few modes, you can also change the schema name as needed. -
Page 25: 8、Control Card Software Debugging Instructions
1、software connection Use the network cable to connect, when debugging KLS24 for the first time, after opening the software, type "666888" on the keyboard, select the network cable direct connection mode, check the "direct connection sending device", and detect that... -
Page 26: 2、Receiving Card Parameter Settings
KLS24manual www.kystar.com.cn 2、Receiving card parameter settings The common IC and dual-latch IC mainly adjusts the test data clock frequency and multiplier to refresh and debug to 1920, and the PWM chip mainly adjusts the gray-scale clock frequency and refreshes and debugs to 3840. -
Page 27: 3、Screen Connection
KLS24manual www.kystar.com.cn when the receiving card has no signal. effect debugging ： Debug data clock frequency and multiplier, and refresh to 1920 (PWM chip debug gray clock frequency, refresh to 3840). Effective means to improve the display effect: 1 、 Raise the data clock ： The frequency is not affected by other parameters, which is the first condition;... -
Page 28: 4、Save Parameter
KLS24manual www.kystar.com.cn Single card setup：Set the receiving card load size. Network port selection：Select the peer network port settings. Connection method (horizontal/vertical)： The serial connection method between the receiving card and the receiving card. Setting：According to the flickering of the large screen, click the corresponding area to intelligently identify the serial connection method of the network port and network cable. -
Page 29: 9、Faq
KLS24manual www.kystar.com.cn 9、FAQ Q1：DVI, HDMI port definition. A： DVI： Digital (HD) video signal is an interface standard introduced by DDWG (Digital Display Working Group) in 1999 by Silicon Image, Intel and other companies. It has been well optimized in speed, clarity and HDCP protocol. Signal sources are typically desktop computers, notebooks, etc. - Page 30 KLS24manual www.kystar.com.cn ②The USB cable driver is not installed on the computer or the USB driver is damaged; ③ The serial port cable is not well connected or the cable is damaged; Q5：The large screen of the video card directly connected with the sending card is displayed normally, and the screen will appear black screen when it is connected to the video processor.
