- Page 1 KLS8Pro Ten ports 2 in 1 video controller Version: v1.1 Release Date: October 2021 Manual...
- Page 2 Version record version number Change details release time V1.0 First edition released 2021.07.15 V1.1 Modify the cover 2021.10.25...
- Page 3 Safety precautions Danger ● There is high voltage in the equipment. Non-professional maintenance personnel should not open the back cover to avoid danger. Warning ● This equipment is not waterproof equipment, please do waterproof treatment in wet environment; ● This device is not allowed to get close to fire or high temperature environment; ●...
-
Page 4: Table Of Contents
Catalog I、 PRODUCT DISCUSSION ........................1 Ⅱ、PRODUCT CHARACTERISTICS ...................... 2 III、TECHNICAL INDICATORS ......................3 IV、WORKING SKETCH........................4 V、PANEL STRUCTURE........................5 ............................5 RONT PANEL ............................. 6 ACK PANEL VI、WIRING AND INSTALLATION....................7 ............................. 7 IRING DIAGRAM ........................... 7 INSTALLATION STEP VII、EQUIPMENT COMMISSIONING....................8 ............................ -
Page 5: I、Product Discussion
KLS8Pro manual www.kystar.com.cn I、Product discussion With the rapid development and application demand of LED display industry, various control requirements for large screen control system emerge as the times require. However, due to the limitations of the large screen control system in image processing, picture control and signal format conversion, there are some weak links in the large screen control system of LED, which can not meet the needs of users. -
Page 6: Ⅱ、Product Characteristics
KLS8Pro manual www.kystar.com.cn Ⅱ、Product characteristics Whole machine has 10 network ports, and the single network port can load 650,000 pixels. The maximum load of the whole machine is 5 million pixels. The width can reach 8,000 pixels and the height can reach 4,000 pixels. -
Page 7: Technical Indicators
KLS8Pro manual www.kystar.com.cn III、Technical indicators The video processor adopts the latest patented video processing technology, and has the video conversion capability of any format input and corresponding format output. Video signals including DVI, HDMI, DP, etc. can be processed and enhanced to meet customer application requirements. -
Page 8: Working Sketch
KLS8Pro manual www.kystar.com.cn IV、Working sketch LED screen Desktop computer laptop camera... -
Page 9: Panel Structure
KLS8Pro manual www.kystar.com.cn V、Panel Structure Front panel ① ② ③ ④⑤ ⑥⑦ ⑧ ⑨⑩ ⑪ ⑫ ⑬ 1、POWER：AC 220V power switch; ON state means the power is on, OFF state means the power is off. 2 、 LCD screen ： Information display; displays information about the device and commissioning. -
Page 10: Back Panel
KLS8Pro manual www.kystar.com.cn 13、 M1-M6 ： M1-M6: shortcut mode call button; the main menu interface is the shortcut mode button, and the parameter input interface indicates，Numbers 6-0 and clear key. Back panel ○ ○ ○ ○ ○ ○ ○ ○... -
Page 11: Wiring And Installation
KLS8Pro manual www.kystar.com.cn VI、Wiring and installation Wiring diagram Power cable Lan cable LED screen Monitor Signal source USB control cable Installation step 1、Wiring as shown in the picture, connect the DVI port of the graphics card to the DVI-IN input port of the 2-in-1 controller;... -
Page 12: Equipment Commissioning
KLS8Pro manual www.kystar.com.cn VII、Equipment commissioning Navigation mode This Wizard is suitable for most cases. It is simple to set up. With the prompt, you can gradually debug it to achieve the desired display effect. The processor automatically enters the navigation mode when it is powered up.(or Click Enter Navigation Mode）：... - Page 13 KLS8Pro manual www.kystar.com.cn Select window layout (Layout1/Layout2/Layout3/Layout4) Select the win signal source, and use the knob to select the signal source input Set window parameters...
-
Page 14: Expert Mode
KLS8Pro manual www.kystar.com.cn Save mode, mode 1 - mode 32 Expert mode Step 1: Click "MENU" to enter the main menu interface, select "Device Mode", there are two modes: 4*DVI+DP(2K)+HDMI(2K) and 2*DVI+DP(4K)+HDMI(4K) Note; only DVI1 and DVI2 are available in 4K mode... - Page 15 KLS8Pro manual www.kystar.com.cn Note: There are two ways to enter numbers: （1）Adjust by rotating the knob, and adjust the step size by "×1", "×10" and "×100", for example, "×100" means that the number increases by 100 each time the knob is rotated.
- Page 16 KLS8Pro manual www.kystar.com.cn Step 5: Click "MENU" to return to the main menu interface, enter Menu - More - Common Functions - Partial Display, enter the part display setting interface, and set the size and position of the partial interception of each signal source.
- Page 17 KLS8Pro manual www.kystar.com.cn Note: Mode 1 is the data that is started by default when the device is powered on. It is recommended that the most commonly used or the mode that needs to be displayed when booting is saved to Mode 1.
-
Page 18: Function Introduction
KLS8Pro manual www.kystar.com.cn VIII、function introduction Key Function INFO: Information query button, click this button to enter the input information query interface, showing whether the input of each signal source is normal, the interface is as follows, red means the signal is lost, green means the signal is normal. -
Page 19: Common Functions
KLS8Pro manual www.kystar.com.cn image will be output normally. Output status Black Blue Display black screen Norma FUNC: function button, click this button to enter the common function interface. Common functions include: screen brightness, processor brightness, local global, local settings, switching effects, switching time, cutout settings, transparency settings, intelligent hot backup, OSD settings, EDID, multi-level cascade, still picture, preview settings , K-HDR. - Page 20 KLS8Pro manual www.kystar.com.cn 6、effect time Set the screen switching time or the switching time between modes, adjustable from 0.2s to 3s. 7、Cutout Settings The cutout setting is to cut out some text or pictures and remove the rest, which is often used for subtitle production.
-
Page 21: Advanced Menu
KLS8Pro manual www.kystar.com.cn The K-HDR function is Kstar's SDR to HDR image optimization technology, which can improve the contrast of ordinary SDR videos, enhance the performance of image details, and make ordinary videos have HDR effects. Set the K-HDR function parameters of DP or HDMI, including function switch, function level, effective area switch, effective area parameters, presentation mode. -
Page 22: Software Debug
1、software connect Use USB serial cable to connect, after opening the software, the software interface recognizes that the model of the sending card is KLS8Pro, and the number of receiving cards detected is the actual number of on-site loads 、expert debug... -
Page 23: 3、Receiving Card Parameter Settings
KLS8Pro manual www.kystar.com.cn 3、Receiving card parameter settings First select the module manufacturer: select the corresponding module manufacturer; the specifications of the main modules, the driver chip and the decoding method should be consistent Set Single Card Load: the width and height of the receiving card load... -
Page 24: 5、Save Parameter
KLS8Pro manual www.kystar.com.cn 5、save parameter After the parameter setting is completed, the large screen display is normal, click all to cure, For detailed software parameter settings, please refer to "Kstar Control System Instruction Manual V2.1"... -
Page 25: Faq
KLS8Pro manual www.kystar.com.cn X、FAQ Q1：DVI, HDMI port definition. A： DVI： Digital (HD) video signal is an interface standard introduced by DDWG (Digital Display Working Group) in 1999 by Silicon Image, Intel and other companies. It has been well optimized in speed, clarity and HDCP protocol. Signal sources are typically desktop computers, notebooks, etc. - Page 26 KLS8Pro manual www.kystar.com.cn ③ The serial port cable is not well connected or the cable is damaged; Q5：The large screen of the video card directly connected with the sending card is displayed normally, and the screen will appear black screen when it is connected to the video processor.
