- Page 1 LS4Pro Four lan ports 2 in 1 video controller Version: v2.3 Release Date: November 2021 Manual...
- Page 2 Version record version Change details release time number V1.0 first release 2018.12.12 V2.0 Modify device interface information 2019.11.28 V2.1 Modify loading information 2020.12.09 V2.2 change cover 2021.10.25 V2.3 Correct size data, 2021.11.18...
- Page 3 Safety precautions Danger ● There is high voltage in the equipment. Non-professional maintenance personnel should not open the back cover to avoid danger. Warning ● This equipment is not waterproof equipment, please do waterproof treatment in wet environment; ● This device is not allowed to get close to fire or high temperature environment; ●...
-
Page 4: Table Of Contents
catalog I、 PRODUCT DISCUSSION....................... 1 Ⅱ、PRODUCT CHARACTERISTICS....................2 III、TECHNICAL INDICATORS......................3 V、PANEL STRUCTURE........................5 ............................5 RONT PANEL ............................6 BACK PANEL VI、WIRING AND INSTALLATION....................7 ..........................7 IRING DIAGRAM ..........................7 NSTALLATION STEPS VII、EQUIPMENT COMMISSIONING..................... 8 ..........................8 AVIGATION MODE VIII、CONTROL MENU........................15 IX、FREQUENTLY ASKED QUESTIONS..................18 X、METHOD OF IMPORTING BOX FILES .................. -
Page 5: I、Product Discussion
LSPro manual www.kystar.com.cn I、Product discussion With the rapid development and application demand of LED display industry, various control requirements for large screen control system emerge as the times require. However, due to the limitations of the large screen control system in image processing, picture control and signal format conversion, there are some weak links in the large screen control system of LED, which can not meet the needs of users. -
Page 6: Ⅱ、Product Characteristics
LS4Pro manual www.kystar.com.cn Ⅱ、Product characteristics 1.The maximum load of the whole machine is 2.42 million pixels, the widest is 3840 pixels, and the highest is 1920 pixels. 2.Support PC software control to achieve visual and fast operation; 3.Support dual-screen display, can draw Chinese painting, painting outside, the screen position is arbitrary;... -
Page 7: Technical Indicators
LS4Pro manual www.kystar.com.cn III、Technical indicators Video processor adopts the latest patented video processing technology and has the ability of video conversion with arbitrary format input and corresponding format output. Video signals including CVBS (composite video), HDMI, VGA (RGB) and DVI-D can be processed and enhanced to meet customer application needs. - Page 8 LS4Pro manual www.kystar.com.cn IV、Working sketch LED screen Video processor Desktop computer laptop camera...
-
Page 9: Panel Structure
LS4Pro manual www.kystar.com.cn V、Panel Structure Front panel ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ 1、 POWER-------------------------Equipment switch, OFF - power off, ON - power on 2、 LCD--------Text display screen, display menus, parameters and other information 3、... -
Page 10: Back Panel
LS4Pro manual www.kystar.com.cn 20、Navigation keys-----------------User navigation mode, used as step size switch key when adjusting data size 21、arrowhead tag----------------------------------------------------------------back key back panel ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ 1、 UART-------------------------------------Connecting PC Software through 9-pin Serial Port to RJ45 Network Port 2、... -
Page 11: Wiring And Installation
LS4Pro manual www.kystar.com.cn VI、Wiring and installation Wiring diagram Power cable Lan cable LED screen Signal source USBcontrol cable Installation steps 1 、 Connect the DVI interface of the graphics card to the DVI-IN input port of the video processor as shown in the figure. -
Page 12: Equipment Commissioning
LS4Pro manual www.kystar.com.cn VII、Equipment commissioning Navigation mode This Wizard is suitable for most cases. It is simple to set up. With the prompt, you can gradually debug it to achieve the desired display effect. The processor automatically enters the navigation mode when it is powered up.(or Click Enter Navigation Mode）：... - Page 13 LS4Pro manual www.kystar.com.cn Select whether to import the box file: Note: The box files need to be imported into the equipment through the upper computer software. The box files here refer to the parameters of the receiving card. Set the number of cabinet rows/columns: Note: Number of rows/columns in the box refers to the number of horizontal/vertical receiving cards used in the large screen.
- Page 14 LS4Pro manual www.kystar.com.cn Set the cabinet splicing method: Note: The cabinet splicing method refers to the splicing method between the two network cables of the device. Set the cabinet connection method: Note: Cabinet routing mode: Series mode between receiving cards should ensure that the direction of the two cable is the same.
- Page 15 LS4Pro manual www.kystar.com.cn Set screen pixels. Note: Set screen pixels, the screen pixels is the resolution of the whole screen. Save settings: Note: Some parameters of the control system are saved here. Image navigation...
- Page 16 LS4Pro manual www.kystar.com.cn Set the number of windows Select the input source: Note: Select the input signal source Whether local display is needed: Note: This interface is to select whether it is necessary to intercept part of the image of the input signal source and display it on the LED screen.
- Page 17 LS4Pro manual www.kystar.com.cn window and switch to the panoramic display of the computer desktop at any time. Part mode full mode Among them, "location" - where to start intercepting; "size" - how big to intercept. The interface is as follows:...
- Page 18 LS4Pro manual www.kystar.com.cn The last step is to save the settings, in which mode one is automatically invoked after booting. At this point, the setup of the processor is completed. In the process of using it, the signal can be switched directly with the front panel.
-
Page 19: Control Menu
LS4Pro manual www.kystar.com.cn VIII、Control menu Main menu Option Defaults （1）screen Navigation mode Horizontal position Vertical position （2）scaler parameters Horizontal size 1920 Vertical size 1080 Horizontal position Vertical position （3）part Horizontal size Vertical size Mode 1 Mode 2 （4）Save mode Mode 3... - Page 20 LS4Pro manual www.kystar.com.cn English （1）Language Settings English Chinese confirm （2）factory cancel Please contact the sales staff. （3）support 400-159-0808 Enable （4）Scheduled Tasks Disable （6）more （5）effect Effect Time Horizontal position default Vertical position default （6）VGA adjust Horizontal size default Vertical size default...
- Page 21 LS4Pro manual www.kystar.com.cn Freeze （8）Freeze Active Mute （9）Voice Volume Select source Enable （1）Load hotkey Disable Enable （2）Key locked Disable （3）Resend config （4）Read config 60Hz （10）master （5）Frame Frequency 50Hz Settings 30Hz （6） Color temperature correction （7）多 Multi-machine synchronization （8）upgrade online （9）HDCP delayed （10）ADC Correcting...
-
Page 22: Frequently Asked Questions
LS4Pro manual www.kystar.com.cn IX、frequently asked questions Q1：DVI、HDMI、VGA、CV、USB port definition。 A： DVI： Digital (HD) video signal is an interface standard introduced by DDWG (Digital Display Working Group) in 1999 by Silicon Image, Intel and other companies. It has been well optimized in speed, clarity and HDCP protocol. Signal sources are typically desktop computers, notebooks, etc. - Page 23 LS4Pro manual www.kystar.com.cn A:Menu - Advanced Menu - Expert Settings - Keyboard Lock. Keyboard can be locked after opening. Keyboard can be unlocked even by pressing MENU key 10 times. Q4：What is the password to enter the screen navigation? “168”“666”“888”“999”Any one is OK.
-
Page 24: Method Of Importing Box Files
LS4Pro manual www.kystar.com.cn X、Method of Importing Box Files 1. Save cabinet files Expert screen adjustment interface has the option of saving box files: 2、new cabinet file Select the video processing option of the main menu of the software, and select the list of new... - Page 25 LS4Pro manual www.kystar.com.cn Select Add in the pop-up window, add the required box file to the list, and then save it as a blst file:...
- Page 26 LS4Pro manual www.kystar.com.cn 3、import cabinet file list Select Add in the pop-up window, add the required box file to the list, and then save it as a blst file: Select the saved blst file to import to the device...
- Page 27 LS4Pro manual www.kystar.com.cn After the software prompts that the data is successfully written, it can be debugged by the video processor. When the processor selects the box file, the imported file file will be displayed on the LCD screen.
