- Page 1 ChlorMaker MegaChlor MegaChlor-CD Installation & Operation Manual ControlOMatic, Inc. 12659 Arbor Lane, Grass Valley, CA 95949 (530) 205-4520 • www.controlomatic.com Manuals also available at: https://www.controlomatic.com/documents Support and Service: support@controlomatic.com...
-
Page 2: Important Warning And Safety Instructions
WARNING – Cutting the cord from the power supply to the MegaChlor cell voids the warranty. Damage will occur if the connection is reversed. WARNING – DO NOT use with extension cord. Injury may result. - Page 3 WARNING – DO NOT insert objects into, or tamper with the MegaChlor cell in any way. Inserting metal objects into the cell may cause damage and void the warranty. WARNING – DO NOT plug MegaChlor control box directly into the VAC supply, this will damage the MegaChlor .
- Page 4 A minimum of only 2.5 cups of salt per 100 gallons of water is all it takes for MegaChlor to produce fresh, pure chlorine leaving your water clean and clear day after day! MegaChlor produces chlorine in its pure form using electrolysis in order to sanitize the pool/spa water.
-
Page 5: Adding Salt
The salt range for the MegaChlor is 3000 to 4000 PPM. The salt is constantly recycled, salt is lost only when pool water is removed from splashing or people getting out of the water. -
Page 6: Megachlor Installation
6. The power supply must be located near the MegaChlor control box or an extension cable will need to be added. If located behind the spa’s skirt a hole will be needed below the control box to route the cable to the box. - Page 7 ● The power supply will need to be controlled with the same voltage that turns on the circulation pump. You do not want the MegaChlor making chlorine when there is no water flow because gasses will accumulate in the plumbing.
-
Page 8: Making Chlorine (Salt Level Indication)
If it is low that is OK, you could add more salt if you want, but not required. If the lights are on solid or blinking (at a one second rate) the MegaChlor is producing chlorine: �... -
Page 9: View The Current Power Level Setting
MegaChlor includes 10 power level settings that are set based on water volume, usage and testing. The MegaChlor factory setting is 3 (2 hours). The output power to the cell is always the same, the power level changes the amount of time the cell is energized when it turns on. Power level 1 is 30 minutes on, 2 is 1 hour on, 3 is 2 hours on and so on. - Page 10 If currently in a production cycle pressing the Boost button will terminate the production cycle and place the MegaChlor in standby mode for 3 hours. The boost button is an easy way to start or stop a chlorine production cycle. When Boost Mode is active, the salt level light will flash.
- Page 11 MegaChlor measures for the absence of sanitizer as a voltage with a built in sensor. When the sensor value drops below the Zero Point and it has been off at least 3 hours, MegaChlor will start a chlorine production cycle. The Zero Point should be set to a value that represents no chlorine when measured with a test kit.
-
Page 12: Troubleshooting Guide
It is always a good idea to start off low and add more salt after a couple days. If you contact ControlOMatic with this problem you will be asked for the results of the following tests. -
Page 13: Consistently Low Chlorine
CD Version - Chlorine is Always Low The MegaChlor-CD starts a chlorine chlorine production cycle when the chlorine reaches 0 and it may be 0 for a couple hours. -
Page 14: Replacement Parts And Accessories
The titanium plates of any saltwater chlorine generator will eventually wear out and need replacing. Visit www.controlomatic.com and select Shop which will take you to our store. NOTE: Installing the MegaChlor inline may void the spas warranty and UL safety certification as you will be adding to the existing equipment of the pool/spa. -
Page 15: Limited Warranty
Models: This warranty applies to MegaChlor model referenced as “System”. ControlOMatic, Inc. Warrants the system to be free of all defects in material and workmanship for one (1) year from the owners original purchase date. The system includes the power supply unit, cable, electronics, and electrolytic generator for residential use only.
