ControlOMatic MegaChlor Operating Instructions Manual

Pool & spa saltwater chlorine generator
Hide thumbs Also See for MegaChlor:
Table of Contents

Advertisement

Quick Links

Download this manual
MegaChlor
Pool & Spa saltwater chlorine generator
O
PERATING
I
NSTRUCTIONS
ControlOMatic, Inc. 12659 Arbor Lane Grass Valley, CA 95949
www.controlomatic.com support@controlomatic.com
530-205-4520
Manual Version: 12/09/15
Made in the USA - Please like us at www.facebook.com/controlomatic

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MegaChlor and is the answer not in the manual?

Questions and answers

Related Manuals for ControlOMatic MegaChlor

Summary of Contents for ControlOMatic MegaChlor

  • Page 1 MegaChlor Pool & Spa saltwater chlorine generator PERATING NSTRUCTIONS ControlOMatic, Inc. 12659 Arbor Lane Grass Valley, CA 95949 www.controlomatic.com support@controlomatic.com 530-205-4520 Manual Version: 12/09/15 Made in the USA - Please like us at www.facebook.com/controlomatic...
  • Page 2 Slight discomfort may be felt in cuts, sores, or sensitive skin areas due to chlorine concentration and the electrolysis process. WARNING: DO NOT insert objects into, or tamper with the MegaChlor cell in any way. Inserting metal objects into the cell body may cause damage and void the warranty.
  • Page 3 A minimum of only 2.5 cups of salt per 100 gallons of water is all it takes for MegaChlor to produce fresh, pure chlorine leaving your water clean and clear day after day! WATER PREPARATION &...

  • Page 4: Adding Salt

    The MegaChlor can handle any salt level and a good target is 3000 PPM. If the salt is lower that will reduce the efficiency of the chlorine generation and may lead to low chlorine levels. You may be able to taste the salt above 3500 PPM.
  • Page 5 MegaChlor Installation MegaChlor is equipped with a 110/220 VAC Auto-Sensing Power Supply allowing MegaChlor to be installed on almost any pool or spa. Please follow the installation instructions below. The power supply is not an outdoor supply and needs to have protection from the environment.
  • Page 6 MegaChlor Cell Installation The MegaChlor cell will hang over the edge of the pool or spa and hang down into the water. Find a location where the cell will be at least 1” from the side of the pool or spa and for best results as deep as possible. The deeper the cell is the more time the chlorine has to dissolve into the water before reaching the surface.
  • Page 7 MegaChlor Inline Installation The MegaChlor electrode can be removed from the cell and installed into an inline cell that is with the main plumbing of the pool or spa. Use the following guidelines when installing: 1. Do not install into the main circulation flow, that will damage the electrode. Only install into a bypass.
  • Page 8 Making Chlorine (Salt Level Indication) MegaChlor will indicate if the salt level is low or normal. If it is low that is OK, you could add more salt if you want but not required. The MegaChlor has constant current mode of operation meaning that if the salt is high the output will adjust to protect the cell and the power supply.
  • Page 9 MegaChlor includes 10 power level settings that need to be set based on water volume, usage and testing. MegaChlor is set to power level 3 straight from the factory. The output power to the cell is always the same, the power levels change the amount of time the cell is energized every three hours. At the start of the three hour period the cell will be energized and then after the time indicated by the power level the cell will be put into standby mode and stop producing chlorine and at the start of the next 3 hour period will repeat.

  • Page 10: Trouble Shooting

    00:45:00 04:30:00 production of chlorine according to the following table. To 01:00:00 06:00:00 activate Boost Mode simply press the Boost Mode Button. The Salt Light will begin flashing indicating that MegaChlor is in 01:30:00 09:00:00 Boost Mode. 02:00:00 12:00:00 The titanium plates will last around 7000 hours of chlorine...

  • Page 11: Replacement Parts

    MegaChlor In-line conversion cell NOTE: Installing the MegaChlor inline may void the spas warranty and UL safety certification as you will be adding to the existing equipment of the spa. We can provide the conversion kit MCIL-KIT or you can find the required parts at your local hardware store.

  • Page 12: Limited Warranty

    Models: This warranty applies to MegaChlor model referenced as “System”. ControlOMatic, Inc. Warrants the system to be free of all defects in material and workmanship for one (1) year from the owners original purchase date. The system includes the power supply unit, cable, electronics, and electrolytic generator for residential use only.
