C
M
HLOR
AKER
TM
O
PERATING
I
NSTRUCTIONS
ControlOMatic, Inc. 13433 Lime Kiln Road, Grass Valley, CA 95949
www.ControlOMatic.com Support@ControlOMatic.com 530-205-4520
Manual Version: 9/1/11 Made in the USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHLOR MAKER 10 and is the answer not in the manual?

Questions and answers

Related Manuals for ControlOMatic CHLOR MAKER 10

Summary of Contents for ControlOMatic CHLOR MAKER 10

  • Page 1 HLOR AKER PERATING NSTRUCTIONS ControlOMatic, Inc. 13433 Lime Kiln Road, Grass Valley, CA 95949 www.ControlOMatic.com Support@ControlOMatic.com 530-205-4520 Manual Version: 9/1/11 Made in the USA...

  • Page 2: Important Safety Instruction

    INTRODUCTION ChlorMaker is a semi-automated, salt water chlorine generation system specifically designed for portable spas up to 1,250 Gallons. ChlorMaker generates chlorine from a small amount of ordinary salt (Sodium Chloride, NaCl) dissolved in the spa water. The amount of salt added is very small in relation to the volume of the water in the spa. It’s about 90% less concentration than ocean water and below the typical taste level of most humans.
  • Page 3 WATER PREPARATION & MAINTENANCE To ensure proper operation, the spa must be drained, rinsed, refilled with fresh water, and balanced to the recom- mended levels indicated in this section before installing the product. Use the test strips to measure water chem- istry and verify that the water has been balanced properly.

  • Page 4: Salt Requirement

    SALT REQUIREMENT ChlorMaker can generate both Chlorine or Bromine. It all depends on which sanitizer the user prefers. Use So- dium Chloride Salt if you prefer Chlorine Generation and Sodium Bromide Salt if you prefer Bromine. Please Note: Each salt requires a different level of salinity for ChlorMaker to operate effectively. CHLORINE SALT - SODIUM CHLORIDE (NaCl): Raise Salt Level to 2,000 PPM (Parts Per Million).

  • Page 5: Product Installation

    PRODUCT INSTALLATION ChlorMaker is equipped with a 110/220 VAC Auto-Sensing Power Supply allowing ChlorMaker to be installed on almost any spa with a 24 Hour Circulation Pump. Spa Dealers or Licensed Electricians are required to install this product as they are familiar with the electrical codes in your area. ChlorMaker needs to be wired to a power source that turns on &...
  • Page 6 Find 24 Circulation Plumbing: Locate the continuous (24 Hour) circulating pump and the 3/4 inch tub- bing connected to the pump. The ChlorMaker cell should be installed on the OUTPUT side of the pump. The tube will need to be cut and reconnected to the ChlorMaker cell. Refer to DIAGRAM 2 Item (B). Additional tubing may be needed if the existing tube is not long enough or is hard to access.
  • Page 7 Mounting The Control Panel: Find a location in the spa skirting that will give easy access to the spa cabinet & spa pack. Drill a 3/4” Hole to allow the Control Panel cables to run through. Use silicone caulking to seal the hole once the cables are run through. Use the provided mounting screws to securely fasten the control panel to the spa skirting making sure the control panel completely covers the 3/4 inch hole.

  • Page 8: Selecting The Right Power Level

    SELECTING THE RIGHT POWER LEVEL Selecting the right power level requires some testing and adjustment. There are many factors that affect the sanitizing needs of a spa such as: Frequency of spa use, number of people, if there is an Ozone Generator, spa temperature, last drain and refill, etc.

  • Page 9: Troubleshooting

    CLEANING & REVERSE POLARITY ChlorMaker is uniquely designed with reverse polarity which is a self cleaning feature built in to every unit. How- ever, there may be water conditions (very hard water) where the self cleaning design may not be able to keep up. If this water condition exists in your area, a white buildup will be visible on the titanium plates.

  • Page 10: Limited Warranty

    Models: This warranty applies to ChlorMaker models referenced as “System”. ControlOMatic, Inc. Warrants the system to be free of all defects in material and workmanship for one (1) year from the original purchase date. The system includes the power supply unit, cable, electronics, and electrolytic genera- tor for residential use only.
  • Page 11 HLOR AKER Go To www.ControlOMatic.com For More Product Information...

  • Page 12: Product Registration

    PRODUCT REGISTRATION Please fill out the information below and send to ControlOMatic to properly register your prod- uct. Or register your product on line at www.ControlOMatic.com. First Name: Last Name: Address: City: State / Province: Postal Code: Phone: E-Mail: Please copy this section and forward a copy to ControlOMatic, Inc.
