7706LR Series
7706LR L-Band Fiber Receiver
User Manual
Fax: 905-335-3573
Fax: 905-335-7571

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7706LR Series and is the answer not in the manual?

Questions and answers

Summary of Contents for evertz 7706LR Series

  • Page 1 Version 1.1, November 2016 The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of purchasers of the 7706LR series product. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation of the 7706LR series product.
  • Page 2 This page left intentionally blank...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (Servicing) instructions in the literature accompanying the product.
  • Page 4 WARNING Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s authority to operate the equipment. Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables...
  • Page 5: Table Of Contents

    7700 MultiFrame Manual 7706LR Series TABLE OF CONTENTS OVERVIEW ........................... 1 INSTALLATION ..........................3 2.1. 7706LR CONNECTIONS ...................... 4 2.2. CARE AND HANDLING OF OPTICAL FIBER ..............4 2.2.1. Handling and Connecting Fibers ................4 7706LR SPECIFICATIONS ......................5 3.1. RF OUTPUTS ........................5 3.2.
  • Page 6 7700 MultiFrame Manual 7706LR Series Figures Figure 1-1: 7706LR Block Diagram ........................1 Figure 2-1: 7706LR Rear Panel ........................3 Figure 5-1: Location of 7706LR Jumpers and LEDs ..................9 Tables Table 4-1: LED Status Indicators ........................8 Table 5-1: Dip Switches..........................11 Page-ii Revision 1.1...
  • Page 7 Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
  • Page 8 7700 MultiFrame Manual 7706LR Series WARNING Do not connect the 7706LR without optical attenuation to a transmitter producing in excess of +3dBm optical power. Maximum optical input to the 7706LR is +3dBm – more power than this may damage the receiver.
  • Page 9: Overview

    7700 MultiFrame Manual 7706LR Series OVERVIEW The 7706LR is a fiber optic receiver for receiving extended L-Band and other signals. It accepts a fiber optic input from a companion transmitter and provides an electrical output signal. Control of the card is provided locally at the card edge via DIP Switches.
  • Page 10 7700 MultiFrame Manual 7706LR Series This page left intentionally blank Page-2 Revision 1.1...
  • Page 11: Installation

    7700 MultiFrame Manual 7706LR Series INSTALLATION The 7706LR comes with a companion rear plate appropriate for a 1RU, 3RU or standalone enclosure as specified at the time of order. SC/UPC, SC/APC, ST/UPC, FC/UPC or FC/APC optical connectors are available and the type specified at the time of order will be installed. For information on mounting the rear plate and inserting the module into the frame, see the 7700FR manual for detailed instructions.
  • Page 12: 7706Lr Connections

    Evertz recommends that you maintain a minimum bending radius of 5 cm to avoid fiber-bending loss that will decrease the maximum attainable distance of the fiber cable. Evertz fiber optic modules come with cable lockout devices to prevent the user from damaging the fiber by installing a module into a slot in the frame that does not have a suitable rear plate installed.
  • Page 13: 7706Lr Specifications

    7700 MultiFrame Manual 7706LR Series 7706LR SPECIFICATIONS 3.1. RF OUTPUTS Number of Outputs: Connector: BNC per IEC 61169-8 Annex A, F type and SMA optional 75 Ω (50 Ω optional) I/O Impedance: Return Loss: >15dB Frequency Range: 120MHz-2250MHz Output IP3:...
  • Page 14 7700 MultiFrame Manual 7706LR Series This page left intentionally blank Page-6 Revision 1.1...
  • Page 15: Status Indicators And Displays

    7700 MultiFrame Manual 7706LR Series STATUS INDICATORS AND DISPLAYS 4.1. 7706LR STATUS INDICATORS The 7706LR has nine LED status indicators on the front card edge to show operational status of the card at a glance. See Figure 5-1 for LED locations.
  • Page 16: Table 4-1: Led Status Indicators

    7700 MultiFrame Manual 7706LR Series LED # Colour Function Local/ Fault GREEN RF Output Power HIGH: > -5dBm RF Output Power not HIGH: <=-5dBm GREEN RF Output Power OK: -5 dBm >= RF Output Power >= -50 dBm RF Output Power not OK: -5dBm < RF Output Power < -50dBm YELLOW RF Output Power LOW: <-50 dBm...
  • Page 17: Jumper Positions

    7700 MultiFrame Manual 7706LR Series JUMPER POSITIONS 5.1. 7706LR JUMPERS LOCAL FAULT / MODULE OK Optical High RF Low Optical OK RF OK Optical Low RF High Gain Mode Squelch Status Dip Switches FACTORY FRAME STATUS Serial Upgrade Port Figure 5-1: Location of 7706LR Jumpers and LEDs 5.2.
  • Page 18: Configuring The Module For Firmware Upgrades

    The module is now ready for normal operation. 5.4. FACTORY AND BDM JUMPERS When shipped from the Evertz facility, the FACTORY and BDM jumpers will not be installed. These jumpers should not be installed for any reason. If jumpers are on these positions they should be removed.
  • Page 19: Table 5-1: Dip Switches

    7700 MultiFrame Manual 7706LR Series Switch Function Notes open = off, closed = on Squelch open = off, closed = on not used open = off, closed = on manual gain / AGC target bit 1 open = off, closed = on...
  • Page 20: 7706Lr Parameters

    7700 MultiFrame Manual 7706LR Series 5.5. 7706LR PARAMETERS 5.5.1. Selecting the Output Gain Mode The 7706LR has two gain modes available: Manual gain mode allows the user to select a fixed gain level for the RF signal. AGC (automatic gain control) will maintain a constant output level even if the input RF level changes, as long as this input level does not go outside of the AGC hold range.
  • Page 21: Adjusting The Agc Target Level

    7700 MultiFrame Manual 7706LR Series 5.5.4. Adjusting the AGC Target Level The target output level to be maintained by the 7706LR when AGC mode is user adjustable. To set the AGC target level, use the Dip Switches 4,5,6,7,8 according to the table (see Table 5-1).
  • Page 22 7700 MultiFrame Manual 7706LR Series End of document Page-14 Revision 1.1...
