Wiring Diagram - Zephyr ACT Siena Pro ZSP-E36CS Use, Care And Installation Manual

ZEPHYRONLINE.COM
ZSP-E36CS, ZSP-E42CS,
ZSP-E48CS Wiring Diagram
Body
REMARKS: CONDENSER 11+11uF 250VAC *2 FIT AC120V 60Hz
Power consumption shown for default 1200 CFM blower configuration
ACT 590 CFM - Fan Max. 556W @ 4.6A
ACT 390 CFM - Fan Max. 381W @ 3.4A
Siena Pro Use, Care, and Installation Guide
White
Brown
Yellow
Green
Body
Motor
AC N AC L
HI
MID LO
Transformer
Volts
120
Grey
Grey
Brown
Blue
Yellow
Red

Wiring Diagram

Hz
Max Amps
60
White
Blue
Red
Green
Body
Motor
LED
LED
7
23
