Physical; Electrical And Communication - Tritec SeaKing Profiling Sonar Product Manual

Specification

2.3. Physical

Physical
Weight in air
Weight in water
Materials
Depth rating
Temperatures

2.4. Electrical and Communication

Electrical and Communications
Power requirement
Communication protocols
Communication rate
ARCNET line driver
ARCNET isolation
Connector options
0374-SOM-00002, Issue: 04
3.5kg (aluminium)
1.7kg (aluminium)
Boot: Acetal copolymer
Body tube: Anodised aluminium alloy
(6Al4V Titanium optional)
4000m
Operating: -10 to 35°C
Storage: -20 to 50°C
20 to 72V DC at 8W
AUX port voltage equal to Main port supply
ARCNET, RS485, RS232 (single head only)
ARCNET: 156kbit·s
RS232 & RS485 : 115.2kBd
1500m at 156kbit·s
2500m at 78kbit·s
-1
Transformer Isolated 1500V
Tritech 6-pin (standard)
Others available on request
9
SeaKing Profiling Sonar
, 78kbit·s
-1 -1
-1
