3. Installation

3.1. General Overview

The SeaKing heads are supplied with a waterblock fitted to the device and
as standard a proprietary connector usually referred to as the "Tritech 6-
Way Connector". Other connectors are available and various lengths of test
cable can be supplied with the connector. For more details contact Tritech
International Ltd.
The waterblock is fastened to the body tube of the head, and provides
a 4000m rated pressure bulkhead. This will protect the electronics from
water ingress in case the connector is damaged or not fitted correctly. The
connector may be disconnected from the heads by unscrewing the four
securing screws.

3.2. Seanet Pro Software

The Seanet Pro Windows software will be provided either on an Installation
CD-ROM (for SeaHub interface to user computer) or pre-installed on the
Seanet SCU.
For the CD Installation, if Setup does not auto-run on disc insertion, run the
SETUP.EXE file from the disc to start the installation.

3.3. Installing the Profiler Head

!
The heads should be secured by clamping on the cylindrical body section
such that the transducer is unimpeded and not shielded. A guard can be fitted
0374-SOM-00002, Issue: 04
Note
It is not necessary to remove the waterblock when removing the
connector. While the connector is removed from the head, the
blanking plugs supplied should be fitted to prevent the ingress of
dirt or moisture.
Caution
Although the profiler heads are rugged, they should be handled
with care, particularly the connector and transducer.
