Specifications

Specifications
Display
Input Signal
Display Colours
Synchronisation
Range
Resolutions
Supported
Active Display
Area**
LCD1525E.PM5
38 cm (15.1 inch) viewable image size; 1024 x 768
native resolution (Pixel Count); active matrix;
thin film transistor (TFT); liquid crystal display (LCD);
0.30 mm dot pitch; 200 cd/m
200:1 contrast ratio, typical
Video Analog 0.7 Vp-p 75
Sync Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Analog Input: 16,194,277 colours with dithering
(Depends on the graphics board)
Horizontal 24.8 kHz to 48.4 kHz (Automatically)
Vertical 56.2 Hz to 75.0 Hz (Automatically)
720 x 400*: VGA text
640 x 480* at 60 Hz to 75 Hz
800 x 600* at 56 Hz to 75 Hz
1024 x 768 at 60 Hz
Horizontal
Vertical
Page 27
2
white luminance, typical;
307.2 mm
230.4 mm
