Quick Start

To attach the AccuSync
instructions:
1. Turn off the power to your computer.
2. If necessary, install the display card into your system. For more information,
refer to the display card manual.
3. For the PC: Connect the 15-pin mini D-SUB of the signal cable to the
connector of the display card in your system (Figure A.1). Tighten all screws.
For the Mac: Connect the AccuSync125
included) to the monitor connector on the Macintosh (Figure B.1). Attach the
15-pin mini D-SUB end of the signal cable to the AccuSync125
cable adapter on the computer (Figure B.1). Tighten all screws.
NOTE: To obtain the AccuSync125
NEC-Mitsubishi Electronics Display of America, Inc. at (800) 632-4662.
4. For download information on the Windows
your AccuSync monitor, refer to the References section of this User's Manual.
5. Connect one end of the power cord to the AccuSync125
other end to the power outlet (Figure C.1).
6. Turn on the monitor (Figure D.1) and the computer.
NOTE: If you have any problems, please refer to the Troubleshooting section of
this User's Manual.
AccuSync125F
monitor to your system, follow these
™
125F
Macintosh cable adapter (not
F
Macintosh cable adapter, call
F
98/Me/2000/XP INF file for
®
Detachable Signal Cable
15-pin mini D-DUB
Figure A.1
3
3
Macintosh
F
monitor and the
F
