Specifications
Monitor
Specifications
Picture Tube
Viewable Image Size:
Input Signal
Sync: Separate sync. TTL Level
Analog input:
Display Colors
Horizontal:
Synchronization
Range
Resolutions Supported
Resolution based on horizontal and
vertical frequencies only
Horizontal:
Active Display Area
(Factory Setting)
Active Display Area
(Full Scan)
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
AccuSync125F
AccuSync
™
125F
Monitor
Diagonal: 22 inch/55 cm
20 inch/51cm
Radius: 50000 mm
Video: ANALOG 0.7 Vp-p/75 Ohms
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Unlimited number of Colors
30 kHz to 96 kHz
Vertical: 50 Hz to 160 Hz
640 x 480 @ 50 to 160 Hz
720 x 400 @ 50 to 160 Hz
800 x 600 @ 50 to 152 Hz
1024 x 768 @ 50 to 120 Hz
1152 x 870 @ 50 to 105 Hz
1280 x 1024 @ 50 to 89 Hz ......................... NEC cites recommended resolution at
1600 x 1200 @ 50 to 76 Hz
396 mm/15.6 inches
Vertical: 297 mm/11.7 inches
406 mm/16.0 inches
305 mm/12.0 inches
AC 100 – 120 V / 220 - 240 V, 50/60 Hz
1.3A @ 100 – 120 V / 0.6A @ 220 - 240 V
495 mm (W) x 493.5 mm (H) x 473 mm (D)
19.5 inches (W) x 19.4 inches (H) x 18.6 inches (D)
29.7 kg
65.5 lbs
+10°C to +35°C/+50°F to +90°F
Humidity: 30% to 80%
Altitude: 3,000 m/10,000 Feet
-20°C to +60°C/-4°F to +140°F
Humidity: 10% to 90%
Altitude: 15,000 m/50,000 Feet
NOTE: Technical specifications are subject to change without notice.
12
12
Notes
90° deflection, 0.24 mm grille pitch,
medium short persistence phosphor,
aperture grille CRT, G-WARAS coating
Depends on display card used.
Automatically
Automatically
Some systems may not support
all modes listed.
85 Hz for optimal display performance.
Dependent upon signal timing used,
and does not include border area.
Dependent upon signal timing used,
and does not include border area.
