- Page 1 CR Oven Models: CR4, CR8, CR16 Operating & Service Manual Manual 014 / Issue 001 / may 2020...
- Page 2 To ensure the best results from this unit please take the time to read and follow all safety, installation and maintenance guidelines carefully before proceeding to install. Keep this manual in a safe place for future consultation. These appliances are marked in compliance with the relevant Low Voltage &...
-
Page 3: Table Of Contents
Contents page Electrical Specification General Installation Operation Setting Time setting Temperature Application 9 / 10 Cleaning... -
Page 4: Electrical Specification
1: Electrical Specification This appliance must be earthed and damaged cables must be replaced by a suitably qualified person! 1 Phase Cable 3 Phase Cable Live (L1) Brown Brown Black Grey Neutral Blue Blue Earth Yellow & Green (Striped) Yellow & Green (Striped) A mains cable, type H07RN-F, conforming to code designation 60245 IEC 57, is supplied. -
Page 5: General Installation
Move into position and adjust feet setting the oven level. • The oven can be place either on a table top or on Moffat's support stands • Table tops must be strog enought to hold the weight of the oven •... -
Page 6: Operation
3: Operation The oven must be connected to the correct power supply, with the correct rating for the appliance. This information should be found on the data badge on the oven. If in doubt, speak to a qualified electrician. Do not attempt connection to any other power supply which differs from the data badge. -
Page 7: Setting Time
3: Operation Setting Timer for Regeneration Cycle The Timer is adjustable to a max of 9 hours and 99 minutes. Change the cook time as below before starting the countdown. The adjustment is made by pressing either [<<] for reducing time and [>>] for increasing. Exit from the program by pressing the [hand] button or do not use the keypad for 5 seconds. -
Page 8: Setting Temperature
3: Operation Changing The Temperature Setting The oven is set between 100’C & 200’C in the factory. The set point is normally factory set to 190°C and can be viewed and changed even during the ovens cycle. To access the temperature set-point in the controller, press the L1 key. -
Page 9: Application
4: Application Cook Frozen Oven is normally pre-heated for approximately 20 minutes. This is achieved by pressing the switch to the pre-heat position. At the end of this time, the ready light will illuminate and the internal buzzer will sound. Load the food, evenly spaced through the oven to give a good airflow throughout the oven. - Page 10 4: Application Bake Off Application Oven is normally pre-heated for approximately 20 minutes. This is achieved by pressing the switch to the pre-heat position. At the end of this time, the ready light will illuminate and the internal buzzer will sound. Load oven with pies, sausage rolls etc.
-
Page 11: Cleaning
5: Cleaning Before attempting to clean the unit, please ensure that the Unit is isolated from the electric supply and allowed to cool down, with all food plates and other Dishes removed from the unit. Do not use a water jet or pressure spray to clean this appliance. Disconnect trolley from mains and wait until appliance has cooled. - Page 12 Thank you for choosing E&R Moffat! E&R Moffat Ltd. www.ermoffat.co.uk Bonnybridge +44 (0) 1324 812272 FK4 2BS sales@ermoffat.co.uk Scotland...
