  • Page 1 G0430A PCIe5 Re-Driver Set Operation Manual First Edition For safety and warning information, please read this manual before attempting to use the equipment. Keep this manual with the equipment. ANRITSU CORPORATION Document No.: M-W4083AE-1.0...
  • Page 2 Ensure that you clearly understand the meanings of the symbols BEFORE using the equipment. Some or all of the following symbols may be used on all Anritsu equipment. In addition, there may be other labels attached to products that are not shown in the diagrams in this manual.

  • Page 3: For Safety

    For Safety CAUTION Static Sensitive Always take the following anti-static measures to prevent the internal circuit from being damaged when using this equipment. Wear a wrist strap connected to the ground terminal of this equipment. Connect the ground wires of this equipment, external measuring instruments and DUT before connecting a coaxial cable.
  • Page 4 In addition, this warranty is valid only for the original equipment purchaser. It is not transferable if the equipment is resold. Anritsu Corporation shall assume no liability for damage or financial loss of the customer due to the use of or a failure to use this equipment, unless the damage or loss is caused due to Anritsu Corporation’s intentional or gross...
  • Page 5 Anritsu Corporation Contact In the event of this equipment malfunctions, please contact an Anritsu Service and Sales office. Contact information can be found on the last page of the printed version of this manual, and is available in a separate file on the PDF...
  • Page 6 Notes On Export Management This product and its manuals may require an Export License/Approval by the Government of the product's country of origin for re-export from your country. Before re-exporting the product or manuals, please contact us to confirm whether they are export-controlled items or not. When you dispose of export-controlled items, the products/manuals need to be broken/shredded so as not to be unlawfully used for military purpose.
  • Page 7 China RoHS 产品中有害物质的名称及含量 部件名称 有害物质 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) [Cr(Ⅵ)] (PBB) (PBDE) 印刷线路板 × × ○ ○ (PCA) 机壳、支架 × ○ × × ○ ○ (Chassis) 电缆、风扇、连接 器等 × ○ × × ○ ○ (Appended goods) 本表格依据...
  • Page 8 viii...

  • Page 9: About This Manual

    About This Manual This operation manual explains the configuration, connection, and operation of the G0430A PCIe5 Re-Driver Set.

  • Page 10: Table Of Contents

    Table of Contents For Safety ............iii About This Manual ..........I Configuration of PCIe5 Re-Driver Set1 Connection Procedure ..... 2 Installation ................ 2 Cables ................2 Software Operation ......4 Preparation ..............4 How to Optimize Return Path .......... 6 Appendix A Recommended Channel Control Values ..........A-1...

  • Page 11: Configuration Of Pcie5 Re-Driver Set1

    Chapter 1 Configuration of PCIe5 Re-Driver Set Configuration of PCIe5 Re-Driver Set The G0430A PCIe5 Re-Driver Set (hereafter G0430A) is an equalizer for 32 Gbaud NRZ signal. With G0430A for channel loss compensation, the MP1900A Signal Quality Analyzer-R can perform tests according to the PCIe 5.0 standard.

  • Page 12: Connection Procedure

    Chapter 2 Connection Procedure Connection Procedure Installation Support MAEQ-39904B EVM board with screws and posts. 3NPS6Ni+SW+WBS ASB-316.5E Figure 2.1-1 Installing Posts Place the MAEQ-39904B EVM board on a horizontal and level surface. Cables Set the DC power supply as below. DC voltage: +3.3 V Current Limit:...
  • Page 13 To MP1900A GND Cable (J1627A) From DUT J1728A (Differential) To ED (Differential) 2.92mm Carlisle cable x2 K220B Figure 2-2 Cable Connection G0430A +3.3V Power USB Control Ch 0 Supply PC or MP1900A From DUT Ch 1 J1728A (Differential) or equivalent...

  • Page 14: Software Operation

    Chapter 3 Software Operation Software Operation Preparation Prepare the G0430A for operation according to the following steps. Install the GUI software on the host PC or MP1900A. Verify jumpers are present in the positions listed on Table 3.1-1. Connect the device under the test (hereafter, DUT) outputs to the MAEQ-39904B Ch1 inputs with the Carlisle connector cables.
  • Page 15 Chapter 3 Software Operation Figure 3.1-1 Channel Control tab...

  • Page 16: How To Optimize Return Path

    When testing the System, connect the G0430A between DUT Tx and ED. Refer to Chapter 2 “Connection Procedure” for how to set up the G0430A. Though the G0430A is not required for AIC Test, it is the same as the method of optimizing Return Path for System / AIC test.
  • Page 17 CTLE Gain to 0.0 dB. Figure 3.2-2 LEQ Test Setting of MX183000A Link Training Turn the G0430A on, set equalization parameters in Figure 3.1-1 to Set No.0 first, as shown in Table A-1, and then click Link Start,.
  • Page 18 Chapter 3 Software Operation 6c. If Loopback cannot be established even with Preset 8, redo step 6b with P7, P6, ... P0. 6d. Check the Preset and EQ settings for which Loopback was established in steps 6a to 6c. 6e. If Loopback cannot be established up to step 6d, remove ISI from the measuring system and retry steps 6a to 6d.
  • Page 19 7f. Click the Auto Search button in step 7c again. 7g. Click CDR Tune. (Optional) ED setting for Return Path optimization In the procedure up to step 7, EQ setting of the G0430A and ED setting parameters for optimizing the Return Path are determined. The parameters are as follows: ●...
  • Page 20 Chapter 3 Software Operation When the settings above are applied to the following parameters for MX183000A, optimization of Return Path is completed. Clock Delay Preset setting Figure 3.2-3 Setting Example of Optimization of Return Path...
  • Page 21 Appendix A Recommended Channel Control Values The following table shows recommened combinations of values for Figure 3-1 Channel Control tab. Table A-1 Recommended Channel Control Values CH1 EQ Bias ch1_eq_lf CH2 EQ Bias ch2_eq_lf Set No. ch1_eq_hf ch2_eq_hf Control (dB) Control (dB)

  • Page 22: Appendix A Recommended Channel Control Values

    Appendix A Recommended Channel Control Values A-2.
