- Page 1 Promask Promask Instructions for Use ENGLISH 009751-J 01/2010...
- Page 2 Promask (thread connection EN 148-1) Promask (bayonet connection) ◄ aligning mark...
- Page 3 Spare parts 013355 Inner mask TPE with fastening ring 012691 Inner mask SIL with fastening ring 013391 Inner mask SIL black with fastening ring 012692 Head harness PM 013312 Head harness SIL yellow PM 013354 Head harness PM Polynet 012694 Buckle set for harness PM (5 pcs) 012693 Visor frame set PM...
- Page 4 Promask Promask Fig A Fig B...
- Page 5 Fig C Fig D Fig E Fig F Fig G Inner mask disc...
- Page 6 Fig K Fig L Fig M Fig N Fig O Fig P Fig Q Fig R Fig S Fig T Speech channel cover Fig U Fig V...
- Page 7 These products are warranted to be free from defects in materials and workmanship at the time of delivery. Scott will be under no liability for any defect arising from wilful damage, negligence, abnormal working conditions, failure to follow the original manufacturers instructions, misuse or unauthorised alteration or repair.
- Page 8 (rubber) year quarter-of-year 2001, January-March +50 ºC -10 ºC < 75 % Symbolit See Instructions for Use! Recommended storage conditions (temperature and humidity). Promask Twin-filter-use (2 filters / same type + class). BGIA, DE-53754 Sankt Augustin, Australia Russia Germany...
- Page 9 Recommended to use in dirty circumstances and in welding. Spark guard replaces exhalation valve cover. Spark guard covers speech channel.
-
Page 10: Full Face Mask
Particle filters must be replaced at the latest when breathing resistance becomes too high. 2.10 The weight of filter used with a full face mask shall not exceed 500 g. The Promask is used with one filter only (the other opening on the mask is blocked by the manufacturer). - Page 11 Full face mask with gas filter *) Filter types A, B, E, K, AX, SX, Hg-P3 and NO-P3 have different applications. For more information, see Instructions for Use of Scott Health & Safety filters. Device with combined filter The specified multiples of threshold value for the gas or particle filters are given separately, but in all cases the lowest value applies *) Provided that the maximum permissible detrimental gas concentration for the gas filter is not exceeded.
- Page 12 Promask + Pro2000: Remove eventual safety plugs from the filter. Screw the filter tightly in the connector of the mask (=inh. valve body). Promask + Pro2000 + blower device: Screw the filters to the blower device and fix the breathing hose to the connector of the mask.
- Page 13 Unscrew the screws (Torx 20), loosen the visor frames, and remove the visor (Fig. A) Place a new visor in the faceblank (with the marking ”UP” on the visor showing upwards). Align the check marks of the visor and faceblank with each other (Fig. B). Position the visor frames and tighten both screws (Fig.
- Page 14 Do not use solvents (e.g. alcohol, acetone, turpentine), hot water or bleaching agents (perborate, percarbonate). 5.9 Disinfection After cleaning, disinfect the inside/faceseal with a disinfection solution (e.g. Scott Trigene), rinse and allow to dry. Finally, reassemble the mask. 5.10 Storage Storage protected from direct sunlight, at -10...+50 °C and relative humidity (RH) under 75...
