KA-C76 DOME COVER

Thank you for purchasing this product.

Please read this instruction manual carefully before use.

Retain this manual so that you may refer to it when necessary.

For inquiries related to installation, etc., please consult your dealer.

Supplied Accessories

INSTRUCTIONS

(This Document)

● Remove the dome type camera (TK-C676 or TK-C655) from the ceiling before attach-

ing the dome cover (KA-C76). Otherwise, the dome type camera may drop from the

ceiling and cause an accident.

● When using a (KA-C76) dome cover in a dark place, remember that the amount of

light transmission is reduced when a (KA-C76) dome cover is attached.

● Due to the dome cover's semispherical shape, near its edge there will be distortion in

the image. The dome camera masks the edge of the semisphere, so when the cam-

era is tilted to the horizontal position the edge of the semisphere enters the picture,

causing the upper edge of the image to appear blacked out or the focus to become

fuzzy.

● When replacing a part, take care not to scratch or stain the lens surfaces or the dome

cover.

CAUTION

INSTRUCTIONS

Blind Mask (

Page 1 (KA-C76). Otherwise, the dome type camera may drop from the ceiling and cause an accident. ● When using a (KA-C76) dome cover in a dark place, remember that the amount of light transmission is reduced when a (KA-C76) dome cover is attached.
Page 2 Attaching the Dome Cover (KA-C76) ● Make sure before attaching the dome cover (KA-C76) After making sure that the blind masks (2 places) and rubber packing are in place as shown in the illustration below, attach the dome cover.
Page 3 ● Attach the cover after confirming the blind masks and rubber packing parts Dome Cover (KA-C76) Main body cover Groove Clearance Pipe Align the tab on the dome cover (KA- Attach the main In order to secure the main body C76) with the groove on the pipe and body cover.
Page 4 Cover rubber packing before attaching the main unit cover. In this case, attach by Rubber following the procedure described Packing below. Dome Cover (KA-C76) Rubber Packing Rubber Packing Cross-section Dome Cover Groove Rubber Pipe...
