The CR805 Printer with Optional Multi-Hopper

The CR805 Printer with Optional Multi-Hopper
C
B
A
A = Output Hopper
B = Hopper Lock Bars
C = Input Hoppers 1–6
D = Multi-Hopper Lock
E = Lock Bar Release Button (B1)
4 CR805 Retransfer Card Printer User Reference Guide
All manuals and user guides at all-guides.com
H
I
J
D
E
G
F
F = Cartridge Release Buttons
G = Exception Slide
H = Card Weight
I = Cartridge Door
J = Cartridge Door Release Button
527693-001EN_C

Load Cards in a Single-Hopper Printer

Load Cards in a Single-Hopper Printer
527693-001EN_C CR805 Retransfer Card Printer User Reference Guide 5
