Remote Keypad Unit; Operating Instructions; Service Parts List - York YK Service Instructions Manual

OPERATING INSTRUCTIONS

The Remote Keypad Unit (RKU) is a portable, hand-
held accessory for use with the YORK International
Variable Speed Oil Pump Drive (VSOP). When con-
nected to a VSOP drive, the Remote Keypad Unit pro-
vides the ability to view the different controls within the
VSOP drive. Typically, the RKU will be used to deter-
VSOP DRIVE 230 VAC UNIT
VSOP DRIVE 460 VAC UNIT
INPUT FUSES with a Liquid Cooled Solid State Starter
200, 208, 220, 230, 240 Volts
380, 400, 415, 440, 460, 480 Volts
550, 575, 600 Volts
INPUT FUSES with a VSD Compressor Drive
HEATSINK GREASE
RELAY 3R
SUPPRESSOR FOR RELAY 3R
OUTPUT FILTER BOARD
STEP DOWN TRANSFORMER
FOR 575 VAC INSTALLATIONS
YORK INTERNATIONAL

REMOTE KEYPAD UNIT

mine what condition is causing the VSOP drive to fault.
The RKU is available from the Baltimore Part Center
with the following part number WAEXRK01. (Yes this
is a real YORK part number and the last two digits are
zero, one.) Operation of the RKU is covered in Form
160.00-NO7.

SERVICE PARTS LIST

024-30468-001
024-30468-002
025-25584-000 (FNQ-15)
025-25515-000 (FNQ-7)
025-27971-000 (KTK-10)
025-25515-000 (FNQ-7)
013-02997-000
024-27806-000
024-26598-000
031-01739-000
025-33233-000
FORM 160.52-M2
17
