Summary of Contents for TBB power BS1225
- Page 2 BS Smart battery charger...
- Page 3 BS Smart battery charger WARNING: HIGH VOLTAGE INSIDE CAUTION: THE DC FUSE MUST HAVE BEENTURNED OFF BEFORE SERVICING MADE IN CHINA...
- Page 4 BS Smart battery charger Disclaimer Unless specially agreed in writing, TBB Power Co., Ltd. ▪Take no warranty as to the accuracy, sufficiency of suitability of any technical or other information provided in this manual or other documentation. ▪Assumes no responsibility or liability for loss or damage, whether direct, indirect, consequential or incidental, which might arise out of the use of such information.
-
Page 5: Table Of Contents
2.1 Features ........................2 2.1 Principle Diagram ...................... 4 2.2 Naming Rules ....................... 4 2.3 Product size ....................... 5 2.3.1 BS1225-3/BS1240-3/BS2412-3/BS2420-3 ............5 2.3.2 BS1210 ......................5 2.3.3 Optional remote control RBS................6 3. Installation ........................7 3.1 BS installation ......................7 3.2 Optional remote control RBS installation .............. -
Page 6: General Safety Information
BS Smart battery charger 1. General Safety information Before using the charger, read all instructions and cautionary markings on the charger, the batteries, and all appropriate sections of this manual. Use BS battery charger only for its use as intended purpose. ... -
Page 7: Introduction
BS Smart battery charger 2. Introduction Batteries will be permanently damaged if they are overcharged or left discharged for a period of time.The BS range of smart battery chargers will continuously monitor and deliver the correct charging profile for all battery types and conditions.The built in battery management software ensur es the batteries life expectancy is maximized. - Page 8 BS Smart battery charger Battery temperature compensation Battery temperature is a key factor in correct charging, the charging formula must be adjusted (automatically and in real time) according to the actual battery temperature to ensure that battery is fully charged but not overcharged or undercharged. All charging voltages recommended by battery manufacture are in fact only applied at 20℃...
-
Page 9: Principle Diagram
BS Smart battery charger 2.1 Principle Diagram Figure 2-1 schematic diagram 2.2 Naming Rules figure explanation Series name BS battery charger Rated DC voltage Rated DC current 220/230V Rated AC input 110V 1+1 outputs (1 for starter battery) Outputs 2+1 outputs (1 for starter battery) -
Page 10: Product Size
BS Smart battery charger 2.3 Product size 2.3.1 BS1225-3/BS1240-3/BS2412-3/BS2420-3 2.3.2 BS1210... -
Page 11: Optional Remote Control Rbs
BS Smart battery charger 2.3.3 Optional remote control RBS... -
Page 12: Installation
BS Smart battery charger 3. Installation 3.1 BS installation BS can be installed on a horizontal surface or vertically on a wall. Please see following instructions: Hole size BS1225-3/BS1240-3/BS2412-3/BS2420-3... - Page 13 BS Smart battery charger M5*20mm 20mm M5*20mm M5*20mm Vertical Installation Horizontal Installation Hole size Hole size BS1210 Ensure clearance on both sides of BS unit upon installation. A recommended clearance of 5cm on each side. ntal Installation...
-
Page 14: Optional Remote Control Rbs Installation
BS Smart battery charger 3.2 Optional remote control RBS installation RBS can be installed by surface mounting or wall mounting. Please see following instructions: Surface Mounting Installation Wall Mounting Installation... -
Page 15: Operation
BS Smart battery charger 4. Operation 4.1 Front Panel Figure 4-1 BS1225/BS1225-3/BS1240/BS1240-3 BS2412/BS2412-3/BS2420/BS2420-3 Figure 4-2 BS1210 LED2 ~ 5 represents different status of the units combined with the LED 1. When LED1 is slow flashing, the BS charger is in the setting status. - Page 16 BS Smart battery charger Color Status LED1 status Description ON, Green Bulk charging ON, Blue Battery type is AGM Charging current is 10A (12V40A) Charging current is 10A (12V25A) ON, Red Charging current is 5A (24V20A) Charging current is 3A (24V12A) (In addition to 12V10A model) LED2 Green...
- Page 17 BS Smart battery charger Charging current is set to 30A (12V40A) Charging current is set to 20A (12V25A) Charging current is set to 15A (24V20A) Slow flashing, Red Charging current is set to 9A (24V12A) （In addition to 12V10A model） ON, Green Power supply mode ON, Blue...
-
Page 18: Side Panel
BS Smart battery charger 4.2 Side panel Figure 4-3 BS1225/BS1225-3/BS1240/BS1240-3/ BS2412/BS2412-3/BS2420/BS2420-3 Label Description Input AC input socket Starter Battery Starter battery connector Output Service battery connector Sensor Battery temperature and voltage sensor connector Monitor Remote panel connector Setting/Select Setting button... -
Page 19: Configuration
As a reminder, different colors of LED are designed for various setting. BLUE = battery type setting (AGM, GEL, LFP, WET) = charging current setting （In addition to 12V10A model） GREEN = working mode setting, battery charger or power supply Examples Figure 5-1 BS1225/BS1225-3/BS1240/BS1240-3 BS2412/BS2412-3/BS2420/BS2420-3... - Page 20 BS Smart battery charger Figure 5-2 BS1210 When the LED1 is green, it is in the indication of charging status. You can also set this battery charger into a power supply by pressing this button for 3secs entering into setting mode. LED 1 LED2 LED3...
- Page 21 BS Smart battery charger If the LED1 is blue, it is in the indication of battery type. You can also set the battery type after long press the button for 3secs. LED1 LED2 LED3 LED4 LED5 Battery type BLUE Green If the LED1 is red, it is in the indication of battery charger power.
-
Page 22: Faq
BS Smart battery charger 6. FAQ 6.1 Fault indicator When the LED1 is red and flashing, it is fault indication. Please refer the below table for details. If the user switch on the AC grid before the connection of battery, there will be “Battery not connected” indication. -
Page 23: 7．Optional Remote Control Rbs Introduction
BS Smart battery charger 7．Optional remote control RBS introduction An optional remote control RBS can be connected to BS via a communication line, （In addition to 12V10A model ） and there are 3 LEDs and 2 buttons to check and set the status of BS synchronously. - Page 24 BS Smart battery charger LED1 indicates the working mode of BS： LED1：Green Mode of BS Always on Battery charge mode Flash once every other second Power supply mode Flash once every other three seconds Silent mode LED2 indicates the charging status of BS： LED2 ：Green Charging status of BS No charging...
-
Page 25: Specification
BS Smart battery charger 8. Specification Model BS1225 BS1225-3 BS1240 BS1240-3 Electrical 13.5V±0.27 Output voltage (PS mode) (VDC) Max Output current (A) Nominal input voltage (VAC) 165-265VAC,50/60Hz Charge algorithms 5 steps. soft start, bulk, absorption, float, recycle Temperature compensation Automatically Absorption voltage (VDC) AGM:14.4V, GEL:14.1V, LFP:14.4V, WET:14.7V... - Page 26 BS Smart battery charger Model BS2412 BS2412-3 BS2420 BS2420-3 Electrical 27.0V±0.5 Output voltage (PS mode) (VDC) Max Output current (A) Nominal input voltage (VAC) 165-265VAC,50/60Hz Charge algorithms 5 steps. soft start, bulk, absorption, float, recycle Temperature compensation Automatically Absorption voltage (VDC) AGM:28.8V, GEL:28.2V, LFP:28.8V, WET:29.4V Floating voltage (VDC) AGM:27.0V, GEL:27.0V, LFP:27.0V, WET:27.4V...
- Page 27 BS Smart battery charger Model BS1210 Electrical Output voltage (PS mode) (VDC) 13.5V±0.27 Max Output current (A) Nominal input voltage (VAC) 85-265VAC,50/60Hz Charge algorithms 5 steps. soft start, bulk, absorption, float, recycle Temperature compensation Automatically Absorption voltage (VDC) AGM:14.4V, GEL:14.1V, LFP:14.4V, WET:14.7V Floating voltage (VDC) AGM:13.5V, GEL:13.5V, LFP:13.5V, WET:13.7V Charging current (A)
- Page 28 BS Smart battery charger...
