DVR-9404~9408~9416
Remote PTZ and I/O Function
If you have installed PTZ or I/O devices on the connected GV-System, then you will be able to
control these devices over TCP/IP or dial-up network.
Remote PTZ control
Select [View] > [PTZ Device] from the menu bar and the PTZ control panel will appear. Use
the [PTZ select] buttons to choose the type of camera you wish to control. The control
panel's user interface may vary from models to models.
PTZ select button
Remote I/O control
Select [View] > [I/O Module] from the menu bar and the I/O control panel will appear. The
Remote view application allows you to control the output devices only. Click on the [Output
signal] buttons to send signal to the output device.
FOR ADDITIONAL QUESTIONS CONTACT TECHNICAL SUPPORT TEAM @ 1 (866) 392-MACE
Direction control button
Zoom
Focus
Auto Focus
Auto Pan
PTZ speed select
ID address select
Output signal buttons
