5.2 Functions and Features of RPB Application
This section will describe the RPB application's major function and features. To start RPB
application, click RemotePlayBack.exe in your workstation and the following screen will appear.
Camera Layout Panel

5.2.1 Main Screen Functions

This section will explain the major functions and tools of the RPB main screen. The RPB
Function Panel and RPB Playback Control Panel will be explained in 5.2.2 and 5.2.3.
Camera Layout Panel
The camera layout panel allows you to choose from 8 different display layout options.
Page Select
You may choose to go to previous page or next page.
RPB View Window
Displays your selected video event.
Exit Minimize Button
Allow you to close the RPB application or minimize it in the Window's task bar.
FOR ADDITIONAL QUESTIONS CONTACT TECHNICAL SUPPORT TEAM @ 1 (866) 392-MACE
RPB View Window
Chapter 5 Remote PlayBack System
RPB Playback Control Panel
Page Select
Mace Security Products
Exit/Minimize
Button
Page 63
RPB Function
Panel
