Invoke Alarm: Check this option if you wish to send alarm to the GV-System when this
Send to Center:
Invoke Notice: Check this option if you wish to have GV-System notices you by
Output Module:
[Output Configuration]:
The Output area allows you to configure the output parameters from 1 to 16. The PT811
supports 1~8 outputs while the GV-IO supports 1~16 outputs.
PTZ Option
PTZ:
Name:
Force Output: Click on the [Force Output] button and the system will send signal to
Signal Type:
Notes:
The same port cannot connect to both PTZ Dome and I/O device at the same time.
FOR ADDITIONAL QUESTIONS CONTACT TECHNICAL SUPPORT TEAM @ 1 (866) 392-MACE
input device is trigger. You may select the alarm type in the drop down
menu.
Check this option if you wish to send an image to the Center when this
device is trigger. Select the camera in the drop-down menu.
Telephone/Pager or Email when this device is trigger. Click on the
arrow icon to choose between HotLine (Telephone/Pager) or Email
notification.
If the input device is invoked, the system will send a signal
automatically to an output pin.
Output Select Button
Apply All Button
Connect to the panel
You can specify a name for each input device in the Name text column.
the output device.
There are four signal types available: N/O (Normal Open), N/O Pulse,
N/C (Normal Close), and N/C Pulse. Choose the one that suit mostly to
the device that you're using. You may also specify the pulse duration
for pulse type signals.
