HANGOUT HIDEAWAY
CLUBHOUSE
Easy step-by-step 3D interactive
instructions for this product can be
found in BILT
INSTALLATION AND OPERATING INSTRUCTIONS
FOR 24/7 ONLINE PARTS REPLACEMENT
parts.kidkraft.com
KidKraft, Inc.
4630 Olin Road
Dallas, Texas 75244
USA
customerservice@kidkraft.com
1.800.933.0771
972.385.0100
®
. Download today.
parts.kidkraft.eu
KidKraft Netherlands BV
Olympisch Stadion 8
1076 DE Amsterdam
The Netherlands
europecustomerservice@kidkraft.com
+31 20 305 8620
M-F from 09:00 to 17:30 (GMT+1)
OBSTACLE FREE SAFETY ZONE - 26'-7.92" x 24'-10.44" x 16'-2.88 (7.82 m x 7.58 m x 4.95 m)
area requires Protective Surfacing. See page 4.
MAXIMUM VERTICAL FALL HEIGHT - 9 ft 9.8 in (2. 99m).
CAPACITY - 9 Users Maximum, Ages 3 to 10; Weight Limit 110 lbs. (50 kg) per child.
RESIDENTAL HOME USE ONLY. Not intended for public areas such as multi-unit
residences, schools, churches, nurseries, day cares or parks.
11'-8.93"
24'-10.44"
357.95 cm
7.58 m
P280135
TWO-PERSON
ASSEMBLY TIME
ASSEMBLY
10 - 14 HOURS
WARNING
To reduce the risk of serious injury or death, please read and follow
these instructions. Keep and refer to instructions as needed and
pass along to any future owners of this item.
26'-7.92"
7.82 m
12'-6.54"
382.38 cm
9'-8.07"
294.81 cm
Rev 12/01/2021
WARNING. ONLY
FOR OUTDOOR
DOMESTIC USE
