PROPER USAGE AND ASSEMBLY INSTRUCTIONS
The following instructions will provide you with a guide for installation and usage
for the Workbench Series. If at any time you need guidance or help, please do not
hesitate to call us. Thanks again for choosing Champion Tool Storage.
Read all instructions before proceeding with installation or drawer loading. Vital
product information pertaining to proper set-up and cautions are included.
Failure to follow these instructions may cause failure which may result in
personal injury or property damage.
QUESTIONS
Champion Tool Storage
3070 Lower Mill Dr.
Hood River Oregon 97031
W: www.championbuilt.com
E-mail: info@championbuilt.com
Phone: 866-391-4200
8 AM - 5PM, PST, Monday-Friday
THIS DOCUMENT IS CONFIDENTIAL AND PROPRIETARY
WORKBENCH SERIES
PART NO. 1000590

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Workbench Series and is the answer not in the manual?

Questions and answers

Related Manuals for Champion Workbench Series

Summary of Contents for Champion Workbench Series

  • Page 1 The following instructions will provide you with a guide for installation and usage for the Workbench Series. If at any time you need guidance or help, please do not hesitate to call us. Thanks again for choosing Champion Tool Storage.

  • Page 2: Table Of Contents

    Table Of Contants Before You Begin Basic Workbench Bottom Shelf Retainer Lip Riser Shelf Bench Uprights Bin Rails Light Frame / Light Fixture Monitor Holder, With Keyboard, Dual Tilt, Vertical Mount Warranty THIS DOCUMENT IS CONFIDENTIAL AND PROPRIETARY PART NO. 1000590...

  • Page 3: Before You Begin

    Check your inventory to be sure you received your entire order; refer to the Parts List on the following pages. If there are any missing or damaged parts, contact Champion Customer Service at 541-386-7700 Only use the provided hardware during assembly.

  • Page 4: Basic Workbench

    Basic Workbench Parts List THIS DOCUMENT IS CONFIDENTIAL AND PROPRIETARY PART NO. 1000590...
  • Page 5 Assembly of Basic Worbench Attach Legs to Wood Top Place the wood top on the ground upside down. Use the packing foam to protect the surface when on the ground. Place the legs on the wood top as shown and align the edge of the leg flush to the wood top.
  • Page 6 Assembly of Basic Worbench Final Assembly Ensure all fasteners are properly tightened. Rotate the Workbench to upright position. Requires (2) people. Do not attempt to tip bench on its side with a single person, as it is unstable in this position and may cause harm to you or damage to workbench integrity. Move Workbench to final location.

  • Page 7: Bottom Shelf

    Bottom Shelf Parts List Assembly of Bottom Shelf Position Bottom Shelf over left and right Leg Assemblies. Note, Large single return is placed at the rear of the unit. Align holes in Bottom Shelf to holes in Leg Assemblies. Install the following and tighten. This completes the assembly of the Bottom Shelf.

  • Page 8: Retainer Lip

    Retainer Lip Parts List Assembly of Retainer Lip Position ITEM 2 flush to bottom edge of the top and flush to each end. Mark the holes on the wood top and drill 3/4" deep with 5/32" drill bit. Install Item 2 using the supplied screws(ITEM3). Do not overtighten. Position Item 1 flush to bottom edge of the top and with the return lip sitting inside of ITEM 2.

  • Page 9: Riser Shelf

    Riser Shelf Parts List Assembly of Riser Shelf Position ITEM 2 flush to back edge of the top and flush to the edge of the end. Mark the holes on the wood top and drill 3/4" deep with 5/32" drill bit. Install Item 2 using the supplied screws(ITEM6). Do not overtighten. Set ITEM 1 on top of ITEM 2, align holes.

  • Page 10: Bench Uprights

    Bench Uprights Parts List BP-UPB48 - Uprights, 48", power plug, for 1.75" butcher block top. Fig. 1 Fig. 2 Assembly of Uprights Set Upright on bench top with the bracket tight up against the wood top and flush to the end. See Fig. 1 Using the 1/4"...

  • Page 11: Bin Rails

    Bin Rail Parts List BP-B48 - Bin Rail, 48" BP-UPB48 - Upright Post Fig. 1 Assembly of Bin Rails Install the Bin Rail into the Upright post by choosing the inner most slots on the Upright Post. See Fig. 1 Push the Bin Rail into the slot, then gently tap the Bin Rail in a downward position until it stops.

  • Page 12: Light Frame / Light Fixture

    Light Frame / Light Parts List BP-LF48 - Light Frame, 90°, 48" 1/4" x 2" Mounting Screw Fig. 4 Fig. 1 Fig. 2 Fig. 3 Assembly of the Light Frame and Light Fixture Unfold the Light Frame Assembly until it is a U-Shape. Slide over the uprights until the frame is flush with the Upright Post, See Fig.

  • Page 13: Monitor Holder, With Keyboard, Dual Tilt, Vertical Mount

    Monitor Holder With Keyboard Tray Parts List BP-MHLK - Monitor Holder, With Keyboard, Dual Tilt, Vertical Mount Knob BP-UPB48 - Upright Post Fig. 1 Assembly of the Monitor Holder With Keyboard Tray Slide over the uprights until the unit is in the desired position, See Fig. 1. Tighten the knob on the back of the unit, See Fig.

  • Page 14: Warranty

    Doing so may cause personal injury.. Champion at buyer’s expense or provide transportation charges prepaid. Champion’s sole obligation under its warranty shall be, at its option, to repair, replace or refund the price of any product thereof which is proved to violate such warranty.In no event shall Champion be liable to the buyer for special,...
