Halle Queen Assembly Instructions
Hardware included in headboard carton to attach bed feet and center support system.
A
C
Φ6*20 MM
Φ8*50 MM
Φ6 MM
8PCS
12PCS
12PCS
1

Step#1

Retrieve bed feet from carton fastened behind the headboard.
Attach bed feet (F) to the headboard using Wrench (I), Bolt (C) and Washer (E).

Step#2

Attach bed feet (F1) to the footboard using Wrench (I), Bolt (C) and Washer (E).

Step#3

Attach steel center support legs (J) to the Metal slat (G) using Wrench (I), Bolt (T) and
Washer (D).
CONGRATULATIONS ON YOUR NEW BED PURCHASE
~Warning:do not move bed after final assembly as it may result in damages to floor and/or bed.~
D
E
F
Φ8 MM
H=5 CM
14PCS
2PCS
2
F
G
H=5 CM
Metal Slats
2PCS
4PCS
I
J
Φ8 MM
Center support legs
H=11CM
1PC
4PCS
3
K
T
Φ8*80MM
Φ6*25MM
2PCS
4PCS
