- Page 1 ASSEMBLY INSTRUCTIONS SKU : DEH-20-Q 175 Southbelt Industrial Dr, Houston, TX 77047 Email : info@eastwestfurniture.net Description : Denali Queen Bed Dimension : 86.10" x 63.07" x 78.54" H Denali Queen Bed - page 1 -...
- Page 2 BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. Please take the time to read and follow the assembly instructions carefully. Be sure to check all packing material carefully for small parts which may have come loose inside the carton during shipment.
- Page 3 HARDWARE LIST Q'Ty Description Q'Ty Sketch Description Sketch Allen Head bolts Allen Head bolts 1/4" x 45mm 1/4" x 35mm Flat Washer Lock Washer Ø1/4" Ø1/4" Flat Washer Allen Head bolts Ø5/16" 5/16" x 20mm Wood Dowels Lock Washer Ø8 x 30mm Ø5/16"...
- Page 4 STEP 2 : Assemble Footboard Assemble footboard panel (B) with footboard post (E) by Bolt (1) , Lock washer (4) , flat washer (3) 10 1 STEP 3 : Assemble side rails Assemble side rails (F) with headboard & footboard by Bolt (5) , Lock washer (7) , flat washer (6) Assemble Short (I) and long canopy (K) by Bolt (1).
- Page 5 STEP 4 : Assemble support legs Assemble the support legs (H) with Slats (G) STEP 5 : Attach slats Attach the slats (G) to side rails with the screws (9) and a screw driver Denali Queen Bed - page 5 -...
