D1.8 Seismic Supplement Welding Manual
A General Overview of AWS D1.8 Structural Welding Code - Seismic Supplement
www.lincolnelectric.com
Structural Welding Code
Seismic Supplement

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D1.8 and is the answer not in the manual?

Questions and answers

Related Manuals for Lincoln Electric D1.8

Summary of Contents for Lincoln Electric D1.8

  • Page 1 D1.8 Seismic Supplement Welding Manual A General Overview of AWS D1.8 Structural Welding Code - Seismic Supplement www.lincolnelectric.com Structural Welding Code Seismic Supplement...

  • Page 2: Table Of Contents

    The leader in seismic welding solutions is Lincoln Electric. Our leadership comes from our history; for over 100 years Lincoln Electric has been at the forefront of welding technology. It comes from our people; Duane Miller, Lincoln’s Manager of Engineering Services, chaired the D1.8 committee.
  • Page 3 Examples of such modifications include, but are not limited to, the incorporation of additional product data and alterations due to AWS D1.8 updates. The reader is encouraged to check the Lincoln Electric website for updates (www.lincolnelectric.com). This manual references other documents not published by Lincoln Electric.

  • Page 4: Background

    D1.8 Seismic Supplement Welding Manual Background In January 1994, the Northridge, California earthquake caused unexpected damage to a number of welded steel-framed buildings in the greater Los Angeles area. The Federal Emergency Management Agency (FEMA) funded a variety of investigations that sought to address both the immediate and long-term needs related to solving the performance problems associated with welded steel moment-frame connections.
  • Page 5 FEMA 353 provisions directly into AISC or AWS specifications. AWS D1.8 was approved in 2005 and first printed and distributed in 2006. In 2009 the AWS published the second edition of the AWS D1.8/D1.8M, Structural Welding Code - Seismic Supplement. Subsequent revisions have also been made to this document.

  • Page 6: Purpose.and.use

    AISC website (www.AISC.org) for free, or can be purchased in printed form. This manual does not in any respect act as a substitute for or in compliance with AWS D1.8 or AISC specifications. Should any conflict exist between the content of this manual and these referenced specifications, the documents as published by AISC or AWS should be taken as the authoritative reference.
  • Page 7 However, qualifications and various tests done to meet the criteria of FEMA 353 may be used to meet similar or identical requirements in D1.8. Accordingly, such transfer of results is encouraged in D1.8, subject to the Engineer’s approval. For example, the welder qualification test as prescribed in FEMA 353, Appendix B is similar to that specified in D1.8 Annex...

  • Page 8: Overview

    Structural Welding Committee’s intent behind many of the provisions, as well as an index. New.Terminology. In a manner that has been coordinated with the applicable AISC committees, D1.8 utilizes some new terminology. An understanding of these terms, officially defined in Clause 3: Terms and Definitions of D1.8, is necessary to properly apply the code.
  • Page 9 The SFRS does not typically include all the various structural elements in a building. See D1.8, clause 3.1. Demand Critical welds are defined as “welds designated by the Engineer in Contract Documents, and required to meet specific requirements of this code.”...

  • Page 10: Differences.from.fema.353

    RT). Additionally, the typographical error as contained in FEMA 353 that called for 3/4 in. bend tests has been corrected in D1.8 to call for the intended 3/8 in. thick bend specimens. See D1.8, Annex D.

  • Page 11: A.user's.guide.to.aws.d1.8

    A User’s Guide to AWS D1.8 Certain portions of D1.8 are more important to some parties than others, depending on their specific role in the construction process. The following is a general summary of sections of particular interest to the various participants in a construction project.

  • Page 12: Structural.detailers

    Techniques Welder Qualification Clause 5 and Annex D of D1.8 are devoted to welder qualification. In addition to meeting the welder qualification requirements of D1.1, welders performing work under D1.8 are required to take the Supplemental Welder Qualification for Restricted Access Welding Test, as prescribed in Annex D, when the production weld involves all of the following: www.lincolnelectric.com...
  • Page 13 The type of test to be taken is dependent on the type of backing (if any) that will be used in production, and as shown on the WPS. See D1.8, clause 5.1.3 and Annex D clause D3.2, D3.3.
  • Page 14 D1.8 as well. In addition to meeting the requirements of D1.1, D1.8 mandates additional WPS requirements. Under D1.8, WPSs must list the filler metal manufacturer as well as the filler metal trade name (such as Lincoln Electric’s Innershield -233) as opposed to showing only the AWS classification (in this case, E71T-8). D1.8 ®...
  • Page 15 D1.8 Seismic Supplement Welding Manual From a practical perspective, it is expected that most contractors doing D1.8 work will use the same filler metals for both Demand Critical welds and other welds that are part of the seismic force resisting system.
  • Page 16 D1.8 requires that the filler metals to be used in production first be evaluated in tests run at high and low levels of heat input, that is, under slow and fast cooling rates. Production welding WPSs are then permitted to use a wide range of variables, providing the calculated heat input levels are within the range of tested values.
  • Page 17 Lincoln Electric products is shown on the documents contained in Appendix A of this manual. Techniques All tack welds made under D1.8 are required to be made with the preheat as listed in the WPS. Tack welding on members in the protected zone is restricted, generally being prohibited except when made in certain locations, such as within the joint.

  • Page 18: Inspectors

    D1.8 Seismic Supplement Welding Manual Inspectors. The Inspector’s role with respect to D1.8 is no different than the role as defined by AWS D1.1, namely to ensure that materials and workmanship meet the requirements of the code and contract documents. This is done by performing inspection as necessary prior to assembly, during assembly, during welding, and after welding.

  • Page 19: References

    Regarding Structural Details Ensure that weld access holes are properly prepared. See D1.8, clause 6.9. Ensure that weld tabs and backing have been removed, when required. See D1.8, clause 6.7, 6.10. Regarding the Protected Zone Ensure that no unauthorized welds or attachments have been added. See D1.8, clause 6.15.

  • Page 20: Lincoln.electric.products

    D1.8 Seismic Supplement Welding Manual Lincoln Electric Products The Lincoln Electric Company offers a broad range of filler metals capable of meeting the requirements of AWS D1.8 Seismic Welding Supplement. Whether your choice of welding process is SMAW, FCAW-S, FCAW-G, GMAW, GMAW-C or SAW, Lincoln manufactures and offers consumables that will satisfy D1.8 requirements for nearly every application.
  • Page 21 The requirements for Demand Critical welds are the most rigorous. Filler metals that meet D1.8 requirements for Demand Critical welds will automatically meet all the requirements for welds that are on the SFRS but not Demand Critical. For consistency and simplicity, Lincoln Electric suggests that filler metals that meet the requirements for Demand Critical be used on all welds made on the SFRS.

  • Page 22: Exposure.testing

    D1.8 Seismic Supplement Welding Manual Exposure Testing: Lincoln Electric Approved Filler Metal per AWS D1.8/D1.8M:2009, Subclause 6.1.3 TABLE 3: HEAT INPUT LIMITS FOR DEMAND CRITICAL WELDS Product.Name Filler.Metal.with.70.ksi.Minimum.Tensile.Strength.Requirement.per.AWS Excalibur 7018 MR ® AWS E7018 H4R Excalibur 7018-1 MR ® AWS E7018-1 H4R...
  • Page 23 No heat input testing required 3/16 7/32 0.045 0.052 1/16 0.045 0.052 1/16 0.035 0.045 0.035 0.045 0.052 1/16 No heat input testing required 0.045 0.045 0.040 0.047 www.lincolnelectric.com D1.8 Seismic Supplement Welding Manual Exposure.Time.@. 80°F./.80%.Relative.Humidity — 16 Weeks 16 Weeks —...

  • Page 24: Appendices

    Appendices The following appendices reference the required documentation required to support the use of suggested Lincoln Electric products for D1.8 Demand Critical applications. Check with your Lincoln Electric sales representative, authorized distributor or the Lincoln Electric website at www.lincolnelectric.com for more information.

  • Page 25: A:.d1.8.Certifications

    Appendix A: D1.8 Certifications Additional.Certificates.Available.Online. AWS D1.8 mandates a series of tests that must be performed before various filler metals can be used to make Demand Critical welds. While AWS D1.8 permits these tests to be performed by fabricators and erectors, it also allows for manufacturers like Lincoln Electric to conduct such tests.
  • Page 26 960/Lincolnweld ® Lincolnweld 960/Lincolnweld ® Lincolnweld 960/Lincolnweld ® NOTE: Lincoln Electric is continuously adding D1.8 approved products. Please check our website for the most up-to-date information, www.lincolnelectric.com. www.lincolnelectric.com AWS.Classification AWS E71T-8-H16 AWS E71T-8-H16 AWS E70T-6-H16 AWS E70T7-K2-H16 AWS E71T-1M-H8, E71T-9M-H8...
  • Page 27 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 28 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 29 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 30 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 31 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 32 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 33 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 34 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 35 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 36 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 37 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 38 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 39 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...

  • Page 40: B:.intermix.testing

    FCAW-S, the intermixed zone must be tested in accordance with Annex B of AWS D1.8. This testing can be performed by the filler metal manufacturer, the customer, or by a third party. The results for intermixed weld metal tested by Lincoln Electric are listed as follows: www.lincolnelectric.com...
  • Page 41 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...

  • Page 42: C:.lot.control.alternative.documentation

    Alternative To Production Lot Testing As an alternative to certification by test of every production lot made, D1.8 allows an alternative means for a manufacturer to demonstrate that products are manufactured consistently and capable of achieving the required weld metal mechanical properties.
  • Page 43 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 44 D1.8 Seismic Supplement Welding Manual www.lincolnelectric.com...
  • Page 45 D1.8 Seismic Supplement Welding Manual NOTES www.lincolnelectric.com...
  • Page 46 D1.8 Seismic Supplement Welding Manual District Sales Offices U.S.A. ALABAMA. BIRMINGHAM 35124-1133 (205) 988-8232 DOTHAN 36303-5533 (334) 782-1074 JACKSON 39212-9635 (601) 506-4598 MOBILE 36527-5323 (251) 377-8574 ALASKA. Contact VANCOUVER, WA (360) 693-4712 ARIZONA. PHOENIX 85260-1745 (480) 348-2004 ARKANSAS. LITTLE ROCK 72032-4371 (501) 764-0480 CALIFORNIA.
  • Page 47 Phone: (216) 481-8100 The Harris Products Group 4501 Quality Place, Mason, Ohio 45040 U.S.A. • Web Site: www.harrisproductsgroup.com Consumables: ph: 1-800-733-8912, fax: (513) 754-8778 • Equipment: ph: 1-800-241-0804, fax: (770) 535-0544 D1.8 Seismic Supplement Welding Manual CANADA WASHINGTON.DC. ALBERTA. Contact PHILADELPHIA...
  • Page 48 THE.LINCOLN.ELECTRIC.COMPANY 22801 St. Clair Avenue • Cleveland, OH • 44117-1199 • U.S.A. Phone: +1.216.481.8100 • www.lincolnelectric.com C1.65 10/2010 © Lincoln Global, Inc. All Rights Reserved. Printed in the U.S.A.
