Triton LocBoard LBS31T-SLV Installation & Assembly Instructions

LBS31T-SLV, -WHT - (1) 31.5" x 9" x 9/16" LocBoard® Pegboard Strip, 8 Hooks
Read all instructions completely before installing. Should you have any questions about your installation, please call

Review Carton Contents:

1 Pcs. LocBoard Pegboard 31.5" x 9" x 9/16" (SLV= Silver, WHT=White)
8 Pcs. Assortment of LocHook® Pegboard Hooks
1 Pk. Wall Mounting Hardware Packet
•
Pegboard Strips fasten directly to concrete, solid wood and hollow wall structures without the use of furring strips.
•
Pegboard Strips are designed with internal mounting flanges that keep mounting hardware hidden from sight and add
to the board's structural integrity and holding power.
•
If installing to bare studs you will need to install wood headers before completing installation.
Tools needed for Installation (not supplied with kit):
Level, marker, 7/32" standard or masonry drill bit, 7/64" drill bit for wood studs, #2 Phillips head screwdriver, power
drill.
For drywall, hollow concrete wall installation: Use (12 each) plastic drywall anchors and #8 Phillips head wood screws
(SUPPLIED WITH THIS SYSTEM). If installing to bare studs you will need to install wood headers before completing
installation using wood screws only. NOTE: Always install one board at a time.
1. (IMPORTANT!) Select wall location for your LocBoard Strips. When selecting a location for mounting always make sure
that mounting locations do not fall in line with, are adjacent to or interfere with any internal or external electrical
wiring, wall mounted or built-in electrical appliances, heaters, gas lines, ductwork or plumbing inside of wall, or are
located on the opposite side of any wall surface from where you are mounting. If you are unsure, please consult a
professional before proceeding with installation.
2. There are three screw holes in on the top and bottom row of back of your LocBoard Strips that are accessible through
the square holes on the front (see images on back).
3. Place one LocBoard Strips with against wall surface, while using a level to make sure your board is straight and
squared. Mark the centers of all 6 screw holes onto your wall surface.
4. Pre-drill holes for #8 wall anchors marked in Step 3 using 7/32" standard or masonry drill bit depending on wall
surface. If you hit a wood stud stop drilling and using a 7/64" drill bit create a pilot hole for the wood screw, Note:
avoid over-drilling holes. (Plastic wall anchors should fit snug.)
5. Insert plastic wall anchors in each hole drilled in Step 4 except where you drilled 7/64" pilot hole for wood stud.
6. Align mounting holes in wall surface with screw holes in back flanges. Insert wood screws through the front square
opening and into pre-installed plastic wall anchors. Tighten all screws. The head of each screw should not be visible
and will be tight against inside surface of each mounting flange.
30700 D Carter Street ∙ Solon, OH 44139 ∙ (P) 440.248.5480 ∙
For a full line of products visit
Installation & Assembly Instructions
Customer Service at 440-248-5480.
LocBoard Strip™ Installation:
