- Page 1 ® ® Bose FreeSpace System Controller Installer’s Guide Installationsvejledning Installateur-Anleitung Guía de Instalación Notice d’installation Guida all’installazione Handleiding voor de installateur Monteringsanvisninga May 7, 2002 AM177675-2_04_V.pdf Bose Corporation...
-
Page 2: Safety Information
As with all electrical appliances, dangerous electrical shock may result if repair is attempted by unqualified personnel. Service and the installation of any optional electronics should always be performed by Bose-authorized personnel. CAUTION RISK OF ELECTRICAL SHOCK—DO NOT OPEN TO PREVENT ELECTRICAL SHOCK, DO NOT REMOVE COVER. - Page 3 1.0 Safety Information ® Please read this safety information before installing, connecting, or operating the Bose ® FreeSpace system controller (Model 8/32). 1.1 Read the instructions – Read and keep all safety and operating instructions. 1.2 Follow cautions – For safety, follow all cautions and warnings in this guide and on the system controller.
-
Page 4: Table Of Contents
B.1 Safety agency listings .................. 14 B.2 Fire protective signaling ................14 Appendix C: Warranty And Service ................15 C.1 Warranty period ..................15 C.2 Service ......................15 C.3 Contacting Bose ® ............... inside back cover AM177675-2_04_V.pdf • May 7, 2002... -
Page 5: Introduction
All Bose FreeSpace Model 8, Model 32, Model 25, and Bose 102 loudspeakers, except the 4Ω Model 32 and the 4Ω Model 25, require a Bose approved equalizer, such as this controller. Using the loudspeakers without an approved equalizer causes inferior acoustic performance and may damage the loudspeakers. -
Page 6: Controller Features
2.0 Introduction Controller features ® ® The Bose FreeSpace system controller, combined with the FreeSpace Model 8, Model 25, or Model 32 loudspeakers, provides a flexible sound system for single, multiple, or combination zone installations. Figures 2 and 3 describe the controller’s features. -
Page 7: Configurations
D.O.M. 100-120V/220-240V INPUT PAGE OUTPUT UN FUSIBLE DE RECHANGE Á 50-60Hz 7 WATTS LEVEL BOSE CORPORATION REACTION LENTE DE MÊME CH A CH B PAGE FRAMINGHAM, MA 01701-9168 MADE IN U.S.A. TYPE T 0.25 - 250V. MODEL 32 MODEL 32... -
Page 8: Signal Processing
3.0 Configurations Signal processing The block diagram in Figure 5 is on the top of the system controller. It illustrates the audio Figure 5 signal’s path through the controller. Block diagram. INPUT PAGE AC POWER CHANNEL A CHANNEL B CONNECTOR LINE 300mV 300mV... -
Page 9: Installation
4.0 Installation Electrical connections Although the FreeSpace ® system controller accepts balanced and unbalanced sources, CAUTION Unplug all components before balanced sources provide better audio performance. Observe proper polarity when making connections. making connections: • The positive terminal is usually the high, tip, or plus (+) terminal, or pin 2. •... - Page 10 CUT NORMAL CUT NORMAL 300mV 300mV 2V LINE MIKE ® FREESPACE ® SYSTEM CONTROLLER SER.NO. D.O.M. INPUT BOSE CORPORATION CH A CH B PAGE FRAMINGHAM, MA 01701-9168 MADE IN U.S.A. From balanced Note: Pin 2 – hot source convention assembled on XLR connector.
-
Page 11: Mechanical Installation
WITH SA SLOW BL SER.NO. ATTE D.O.M. PAGE OUTPUT UN FUSIB LEVEL BOSE CORPORATION REACTIO FRAMINGHAM, MA 01701-9168 MADE IN U.S.A. TYPE T 0 Note: Pin 2 – hot convention assembled on XLR connector. Tip (+) Ring (–) 3 (–) -
Page 12: Appendix A: Controller Specifications
Appendix A: Controller Specifications Electrical specifications and controls ® The FreeSpace system controller (Model 8/32) accepts AC supply voltages from 80 to 265, 50Hz or 60Hz. A.1.1 Balanced input terminals Balanced inputs with gain switches, protection diodes, and RFI/EMI noise suppression. A.1.2 Page input Gain is switchable for either microphone or line level inputs. -
Page 13: Mechanical Specifications
6V RMS maximum • Model 25, Model 32, or Bose 102 output impedance 600Ω, balanced • Model 25, Model 32, or Bose 102 frequency responseFlat power response with Model 25 or Model 32 loudspeakers • Model 25, Model 32, or Bose 102 paging Channel A –... -
Page 14: Appendix B: Safety Requirements
B.2 Fire protective signaling B.2.1 Signal processing equipment Bose offers 70V fire safety models of both FreeSpace Model 8 and Model 32 loudspeak- ers listed under UL 1480, category UUMW, as fire protective signaling devices. The Bose FreeSpace system controller (Model 8/32) is the only equalizer listed for use with these loudspeakers in fire protective signaling and warning systems. -
Page 15: Appendix C: Warranty And Service
For more information, please read the warranty card. Service If you have problems with your FreeSpace system controller, contact your authorized Bose Professional Products dealer. The dealer will verify any defects and arrange for service. AM177675-2_04_V.pdf • May 7, 2002... -
Page 16: Contacting Bose
Saturdays 9 a.m. to 3 p.m. ET (eastern time) 00147 Roma TEL 06-5127641 FAX 06-5115438 Canada Bose Ltd., 8-35 East Beaver Creek Road Japan Richmond Hill, Ontario L4B 1B3 Bose K.K., Shibuya YT Building, 28-3 1-800-444-BOSE (444-2673) Maruyama-cho, Shibuya-ku, Tokyo 150 Weekdays 9 a.m. - Page 17 ©1997 Bose Corporation, The Mountain, Framingham, MA 01701-9168 USA JN94777 PN177675-2 Rev.04 AM177675-2 Rev.04 2/97 AM177675-2_04_V.pdf • May 7, 2002...
