- Page 1 OPERATING MANUAL ba75981e02 12/2017 MPP 910 IDS MPP 930 IDS MPP 910 IDS MPP 930 IDS MODULARE MULTIPARAMETERSONDE MIT TIEFENMESSUNG...
- Page 2 MPP 9x0 IDS © Copyright 2017 Xylem Analytics Germany GmbH Printed in Germany. ba75981e02 12/2017...
-
Page 3: Table Of Contents
MPP 9x0 IDS Contents MPP 9x0 IDS - Contents Overview ......... . 4 Operation . -
Page 4: Overview
Overview MPP 9x0 IDS Overview The MPP 9x0 IDS multi-parameter probe is a modular system, consisting of a basic module and various expansion options. System Basic module MPP 910 IDS with one sensor plug-in position components Basic module MPP 930 IDS with three sensor plug-in positions (figure see page on the right) AS/IDS-xx connection cable between basic module and meter or sen-... - Page 5 MPP 9x0 IDS Overview MPP 910 IDS MPP 930 IDS ba75981e02 12/2017...
- Page 6 Overview MPP 9x0 IDS IDS plug All plug connections of the basic module, sensors, connection cable and blind connection plug are of the same type. A lock protects the connections against being inad- vertently disconnected. With the connection cable, the individual sensors can also be directly connected to the meter if necessary (for calibration or firmware update).
-
Page 7: Operation
MPP 9x0 IDS Operation Operation Opening and closing the plug connections The following instructions apply to all actions where any components are con- nected or disconnected (e.g. exchange of blind plug ⇌ sensor): Plug connection closed and locked Guidance Groove Opening the plug ... -
Page 8: Commissioning
Operation MPP 9x0 IDS NOTE All plug-in positions have to be equipped with sensors or closed with blind plugs before the multi-parameter probe is immersed in the measuring medium. Commissioning Prepare the sensors for the measuring operation (see sensor operating manual). -
Page 9: Mounting The Holding Shackle
MPP 9x0 IDS Operation Mounting the holding shackle The holding shackle is screwed onto the sensor instead of the protective ring. To do so, proceed as follows (sample figure of MPP 930 IDS): Disconnect the connection cable from the basic module (see page 7) ... -
Page 10: Cleaning
Cleaning MPP 9x0 IDS Cleaning Please observe the instructions on cleaning the sensors given in the respective sensor operating manuals. If necessary, remove the sensor for cleaning and close its plug-in position with a blind plug. Exterior cleaning Remove water-soluble contamination by rinsing with deionized water. Other types of contamination have to be removed as follows while the contact time with the detergents should be kept as short as possible: Contamination... -
Page 11: Technical Data
MPP 9x0 IDS Technical data Technical data Dimensions, weights 4.1.1 MPP 910 Dimensions (in mm) Protective pipe long Protective pipe short Weights Basic module without cable, With short protective pipe sinker and sensors (all plug approx. 274 g connections closed with ... -
Page 12: Mpp 930
Technical data MPP 9x0 IDS 4.1.2 MPP 930 Dimensions (in mm) Protective pipe long Protective pipe short Weights Basic module without cable, With short protective pipe sinker and sensors (all plug approx. 929 g connections closed with With long protective pipe blind plugs) approx. -
Page 13: Application Characteristics
MPP 9x0 IDS Technical data Application characteristics The application range of a multi-parameter probe can be limited due to the sensors installed (see sensor operating manuals). The following specifications refer to the probe without any sensors installed. Measuring Allowed -5 ... 50 °C (23 ... 122 °F) medium temperature range Allowed pH range... -
Page 14: Measurement Characteristics
Technical data MPP 9x0 IDS Connection cable Diameter 4.3 mm Smallest allowed bend Permanent bend: 63 mm radius Single time or short time bend:21 mm Material of cable sheath TPE-U, aramid fiber reinforced Measurement characteristics Depth Measuring principle Piezo-resistive pressure sensor, calibration- measurement free Measuring ranges at 20 °C... -
Page 15: Wear Parts And Accessories
MPP 9x0 IDS Wear parts and accessories Wear parts and accessories Connection Description Model Order no. cableMPP 9x0 IDS IDS connection cable, 1.5 m AS/IDS-1.5 903 850 - meter IDS connection cable, 3 m AS/IDS-3 903 851 IDS connection cable, 6 m AS/IDS-6 903 852 IDS connection cable, 10 m... - Page 16 Wear parts and accessories MPP 9x0 IDS ba75981e02 12/2017...
- Page 18 For more information on how Xylem can help you, go to xyleminc.com. ® Service and Returns: Xylem Analytics Germany Sales GmbH &...
