Digital/Analog Stereo Audio Amplifier
Quick Start Guide
This Digital/Analog Stereo Audio Amplifier is a compact, high performance,
Class-D amplifier which features both digital and analog inputs. Volume and input
selection can be controlled via front panel buttons or RS-232. LED indicators
provide selection and feature information. This unit is designed for both the
commercial and residential user who needs to output a high quality source to
local analog speakers.
This quick start guide will be going
through:

• Installation

• Product breakdown
• Troubleshooting
Installation
1. PLug in the dc 24v power supply
included with the AC-amp-2024
2. Connect the audio source (Dvd player, cable box, gaming
console) via Optical digital audio input or stereo analog audio
input.
3. Connect to unpowered speakers via the blue left/right
speaker connections.
4. control the system settings with the front panel
