- Page 1 Issue department：R&D Division Date： 2019-11-17 Product Function Author： Jarek instruction No：CB3433A CB.34.33.01 Version： Page 1 of 5 CB3433A Function instruction 1.Electrical configuration diagram：...
- Page 2 Issue department：R&D Division Date： 2019-11-17 Product Function Author： Jarek instruction No：CB3433A CB.34.33.01 Version： Page 2 of 5 2.Function Picture 3.Interface function description3.1.HEAD ACTUATOR Connect to head actuator,control by remote single: Click head up button on the remote, head actuator moves out, stop when released； Click head down button，head actuator moves in, stop when released；...
- Page 3 Issue department：R&D Division Date： 2019-11-17 Product Function Author： Jarek instruction No：CB3433A CB.34.33.01 Version： Page 3 of 5 3.3.LUMBAR ACTUATOR Connect to foot actuator,control by remote single: Click Lumber up button，foot actuator moves out，stop when released； Click Lumber down button，foot actuator moves in，stop when released； This function takes effect only by pressing the corresponding button on the remote.
- Page 4 Issue department：R&D Division Date： 2019-11-17 Product Function Author： Jarek instruction No：CB3433A CB.34.33.01 Version： Page 4 of 5 If fails, repeat all the processes above; 3.8.SYNC port Connect with the same other Control box or Other accessories; 3.9.underbed light-RGB Click button of underbed light, turns on(or change) the underbed light, switch the status once when click once； This function takes effect only by pressing the corresponding button on the remote.
- Page 5 Issue department：R&D Division Date： 2019-11-17 Product Function Author： Jarek instruction No：CB3433A CB.34.33.01 Version： Page 5 of 5 ISED RSS Warning: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
